- Page 1 NDC-F18 Access Control Panel Installation Manual ® NDC-F18 A C C C E S S C O N T R O L P A N E L...
- Page 2 Integrated Technical Vision http://www.itvsystems.com.ua...
- Page 3 ITV reserves the right to change product design any time, which may subsequently affect the contents of this manual. ITV assumes no responsibility for any errors that may appear in this manual. ITV will make every reasonable effort to ensure that this Installation/Programming Manual is up to date and corresponds with your shipped unit.
- Page 4 Integrated Technical Vision http://www.itvsystems.com.ua...
-
Page 5: Table Of Contents
Contents Preface ..................6 Features ....................6 Specifications ..................7 Terms ....................8 What's inside ................10 Wiring diagram ................... 11 Controls and connections on the board ..........12 Control Panel Operation ............13 Mounting ................... 15 Wiring ..................16 Readers' connection ................ -
Page 6: Preface
Preface Preface NDC-F18 access control panel is designed for use in access control systems. Primary goals of Access Control System are: identification of a person, confirmation or not confirmation of access, control of movements in a necessary zone. It can provide time and attendance logging, in addition to the usual task of restricting individuals' access to certain areas. -
Page 7: Specifications
Preface Specifications Primary power supply ~220 V, 50 hertz --44 Power consumption of alternate current net 25 VA Secondary power supply: 10.8 V... 38 V of continuous current 11V... 24 V of alternating current Peak current 100 mA @ 12 V Voltage ripple 500 mV @ 12 V Inputs... -
Page 8: Terms
ID to another person after passing to the premises. If this function is on, NDC-F18 tracks an ID position – Inside or Outside the premises. On any attempt to pass in the same direction twice NDC- F18 denies access and stores “Access Denied, Antipassback”... -
Page 9: Time Zone
To access the high security premises the presence of more than one person may be required . NDC-F18 allows assigning of up to 15 groups of people with the access rights. The access is granted only in case when one person from each group is present. -
Page 10: What's Inside
What's inside What's inside The layout of NDC-F18 is shown on picture below. Figure 1 View of the Panel inside the box: 1 - Mains power connection terminal with fuse 2 - Transformer 3 - Power supply plate 4 - Box... -
Page 11: Wiring Diagram
What's inside Wiring diagram Figure 2 NDC-F18 access control panel wiring Future used Up to two Wiegand readers Free Pass buttons Blocking buttons Door contacts RTE buttons Locks/latch Bell Output of power supply with direct or alternate current protected against... -
Page 12: Controls And Connections On The Board
What's inside Controls and connections on the board y l l y l l y l l e t l n i l y l l y l l y l l... -
Page 13: Control Panel Operation
Control Panel Operation Terminal assignment Connectors X5 - Not Used - for future use X4 - RS-232 communication port Jumpers and LED RST - Reset jumper S2 - Address of the control panel S3, S4, S6 Jumpers for RS-485 load selection BAT - Real-time clock’... - Page 14 Control Panel Operation Outputs’ use and operation modes All outputs of the panel can be programmed at will one of the use variants: lock, bell, alarm or programmed output. Moreover every output is set an operational mode: start-stop (an output is activated whilst the proper command is present, for example, during the time of control panel Alarm mode), impulse (an output is activated for the programmed time), trigger (at first event an output is activated, at the next event it is switched off), and continuous.
-
Page 15: Mounting
Mounting NDC-F18 is delivered in the rugged metal box with rechargeable battery. Mount the panel in place, convenient for service. To mount the panel on a wall proceeds as follows: - Open box cover, place the box in the required position on a wall and mark the holes for mounting screws, using backplate as a template;... -
Page 16: Wiring
Wiring Wiring Readers' connection NDC-F18 has two sets of terminals for Wiegand readers' connection. The wiring is shown on Figure 3 Reader connection. Figure 3 Readers’ connection blue blue orange orange brown brown white white green green black black Wire colors’ correspondence:... -
Page 17: Rte Button
Wiring After reset to factory defaults all inputs become unassigned and not supervised. All inputs supervise shortage and break. The EOL usage is mandatory. Input normal state is from 1,4 kOm up to 3 kOm. Input short circuit is less than 1,4 kOm and input break is more than 3 kOm. -
Page 18: Free Pass And Blocking
Power all cards, except those with "Security service" mark. Executive devices Relay 4 Relay 2 NDC-F18 has four relay outputs to loading loading control operation of executive devices, that can be electric locks, turnpike, turnstile, bell, and so on. Relay 1 and 2 have normally open and normally closed contacts rating 5 A @ 24 V. -
Page 19: Sirens, Bells And Agents
Wiring Sirens, Bells and agents When connecting a bell study carefully user manual of the bell. Consumption power of the bell should not exceed 1A. Some sirens require polarity observing. Bell Often Electric bells are the inductive load for up to +24V,1А power supply. -
Page 20: Rs-485 Interface
Wiring RS-485 Interface RS-485 Interface is used for networking of the system components - PC and panels. The range of RS-485 bus is up to 1200 meters. The number of devices in one bus segment is up to 32. RS-485 port is protected against overvoltage (60 V) and crosspolarity. The unshielded four-wire cable may be used for RS-485 wiring. -
Page 21: Address Settings
Address settings Address settings Each panel on RS-485 dropline must have the unique address from 0 to 31. To adjust the panel address, use the S2 jumpers set. "+" - jumper is shorted; "-" - Jumper is open http://www.itvsystems.com.ua Integrated Technical Vision Ltd... -
Page 22: Limited Warranty
Limited Warranty Limited Warranty Integrated Technical Vision Ltd. warrants that for a period of eighteen months from the date of purchase, the product shall be free of defect in materials and workman- ship under normal use and that in fulfillment of any breach of such warranty, Integrated Technical Vision ltd. - Page 23 http://www.itvsystems.com.ua Integrated Technical Vision Ltd...
