Total weight capacity per drawer.
2.5"
(64 mm)
888-97-284-G-01 rev. C • 04/13
< 2 lbs (1 kg)
10.5"
(267 mm)
12.5"
(315 mm)
StyleView® Storage Drawer
or
Total weight capacity per drawer.
User Guide
www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Nederlands
Benutzerhandbuch - Deutsch
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
<0.25 lbs (0.1 kg)
10.5"
(267 mm)
3.75"
(96 mm)
1/5
Advertisement
Table of Contents
Related Manuals for Ergotron 97-796 StyleView
Summary of Contents for Ergotron 97-796 StyleView
- Page 1 User Guide StyleView® Storage Drawer www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français Gebruikersgids - Nederlands Benutzerhandbuch - Deutsch Guida per l’utente - Italiano Användarhandbok - svenska ユーザーガイ ド : 日本語 用户指南 : 汉语...
- Page 2 (Adjustment may require 40-60 revolutions). Failure to heed this warning may result in serious personal injury or property damage! For More information and instructions refer to product guide at http://4support.ergotron.com or contact Ergotron Customer Care at 1-800-888-8458. 822-052 1 Drawer...
- Page 3 Attach the Travel Stop bracket to the M3 x 22mm lift engine to keep the drawer from hitting the base. Slide the drawer onto the bottom tracks of the last drawer. 888-97-284-G-01 rev. C • 04/13...
- Page 4 Remove the top drawer(s). Secure the bottom drawer by attaching the two screws. M4 x 12mm Replace the top drawer(s). To unlock the storage drawer, turn key counter clockwise 1/4 turn. 888-97-284-G-01 rev. C • 04/13...
- Page 5 Adjustment It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation.
