INSTALLATION INSTRUCTIONS
SUPERPLANE 2.5
TGrid | ATZ | Slot
A
1035 22nd Avenue, Unit 1
Oakland, CA 94606
P
510.489.2530
E
TalkToUs@alwusa.com
W
alwusa.com
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPERPLANE2.5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ALW SUPERPLANE2.5

  • Page 1 INSTALLATION INSTRUCTIONS SUPERPLANE 2.5 TGrid | ATZ | Slot 1035 22nd Avenue, Unit 1 Oakland, CA 94606 510.489.2530 TalkToUs@alwusa.com alwusa.com...
  • Page 2 SP2.5 - Safety & Warnings! 1. Read all instructions. 2. Install in accordance with national and local electrical code regulations. 3. This product is intended to be installed and serviced by a qualified, licensed electrician. 4. Do not install in wet locations. For dry and damp use only. 5.
  • Page 3: Table Of Contents

    Table of Contents Luminaire Overview Diagram Included Parts Tools required Quick Specs Installation Mounting Joining Straight Sections Joining Mitered Corners ControlRoll Lens Wiring Diagram Traditional On/Off 0-10V Dimming DALI Lutron EcoSystem Troubleshooting SP2.5R Installation Guide | TGrid | ATZ | Slot 3 of 10 102-000011 - IG110218-B.0...
  • Page 4: Luminaire Overview

    Luminaire Overview Diagram Approx. distance of ceiling rod to ⁄ " bottom of grid to allow insertion of fixture in grid Included Parts ControlRoll Lens Suspension Mount Bracket SP2.5R Fixture Diffuser Shim Mounting kit Joiner kit (lengths > 8ft) Quick Specs Tools Required Input voltage/Frequency: #2 phillips bit...
  • Page 5: Installation

    Installation: Mounting Place fixture in grid Align fixture with grid Ensure grid spacing as per spec sheet and final drawing. Check fixture for flushness and alignment. Adjust side Insert fixture into appropriate spot and rest it on grid. hooks or nuts on ceiling rod if necessary. Check for alignment.
  • Page 6: Joining Straight Sections

    Installation: Joining Straight Sections If joining straight sections, continue with steps 7-10. If joining miter sections, continue with steps 11-14. If installing single sections, go to step 15. Connect brackets Slide fixtures together aligning connector brackets to slots on other section. Tighten set screws on connector brack- ets and attach both fixtures with provided 8-32 screws.
  • Page 7: Joining Mitered Corners

    Installation: Joining Mitered Corners Connect wiring Insert diffuser shim Connect wiring quick-connects between fixture sections. Insert provided diffuser shim into slots in heat sink. SHOCK HAZARD! May result in serious injury or death. Turn power OFF at circuit breaker prior to installation or servicing.
  • Page 8: Lens

    Installation: ControlRoll Lens Press lens into lens channel Bring lens to fixture With first edge of lens in lens channel, press other side Raise ControlRoll lens to fixture. For longer fixture lengths, two people may be needed. Always wear protective of lens up toward opposite channel.
  • Page 9: Wiring Diagram

    Wiring diagram Traditional On/Off Black Line Voltage White Line Voltage Neutral Green Ground Ground AC 50/60Hz 0-10V Dimming Black Line Voltage White Line Voltage Neutral Green Ground Ground AC 50/60Hz Grey 0-10V DC Dimming - DIM- Purple DIM+ 0-10V DC Dimming + Black Line Voltage...
  • Page 10: Troubleshooting

    Troubleshooting Only a certified electrician can service and troubleshoot product field issues. Always turn main power off before servicing fixture. • Ensure fixture is wired correctly and power is on. Full Fixture does not illuminate • Check that circuit breaker is on and not off or tripped. •...
