ALW MoonRing OnePointFive MR1.5 Installation Instructions Manual

Suspended, ceiling
Hide thumbs Also See for MoonRing OnePointFive MR1.5:

Advertisement

Table of Contents

MoonRing OnePointFive

IMPORTANT SAFETY INSTRUCTIONS

When installing or using this fixtures basic safety precautions must be
followed. Read all instructions before installing fixture. Always follow
applicable building codes when installing any light fixture. Due to product
variations and configurations, these instructions serve only as a general guide. Refer to
factory provided submittals for details.
• This fixture is intended for installation in accordance with the National Electric Code
and Local and State Codes and must be installed by a licensed electrical contractor.
• Do not install this fixture in damp locations.
• Do not install less than four (4) inches from the ceiling (not including ceiling mount).
• This fixture is for installation in non insulated ceilings only.
• To prevent electrical shock, turn off electricity at fuse box before installing the fixture.
INSTALLATION INSTRUCTIONS
MR1.5 | Suspended, Ceiling

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MoonRing OnePointFive MR1.5 and is the answer not in the manual?

Questions and answers

Related Manuals for ALW MoonRing OnePointFive MR1.5

Summary of Contents for ALW MoonRing OnePointFive MR1.5

  • Page 1: Installation Instructions

    INSTALLATION INSTRUCTIONS MoonRing OnePointFive MR1.5 | Suspended, Ceiling IMPORTANT SAFETY INSTRUCTIONS When installing or using this fixtures basic safety precautions must be followed. Read all instructions before installing fixture. Always follow applicable building codes when installing any light fixture. Due to product variations and configurations, these instructions serve only as a general guide.
  • Page 2 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling INSTALLATION A – STANDARD SUSPENSION A1. Turn off power at the circuit breaker before A1-10. To Building proceeding. Power A2. Remove remote driver enclosure, lenses and suspension kit parts from the packaging and set J-Box aside for next steps.
  • Page 3 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling A9. Install the downlight lenses (white with rabbets) A10. by inserting them inside the fixture in such a way that the rabbets overlap. A10. Install the uplight lenses, if the uplight option was selected for the fixture, by screwing them on the suspension brackets with the provided 6-32 screws.
  • Page 4 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling INSTALLATION C – CAS & CCS SUSPENSIONS C1 to C3. Follow steps A1 to A3. C4. Install the round wedge plate onto the J-Box with #8 screws, nuts and washers (by G.C.). The J-Box mounts to the structure and must be rated for J-Box 50lbs or more.
  • Page 5 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling INSTALLATION D – CEILING MOUNT D1 to D3. Follow Steps A1 to A3. D4. The three cleat boss assemblies must be mounted to the ceiling per submittal drawing cordinates. Pre-drill 5/8” holes in the ceiling at the mounting positions.
  • Page 6 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling INSTALLATION E – ENLIGHTED SENSOR INTEGRATION E1. If Enlighted Remote Sensors are included with the fixture, they connect with a 30' wire connected to the driver box. E2. The sensors can be mounted in the ceiling by threading the spring arms around the sensor and inserting them through a 15/16”...
  • Page 7 MoonRing OnePointFive – MR1.5 INSTALLATION INSTRUCTIONS | Suspended & Ceiling INSTALLATION G – EMERGENCY BATTERY POWER G1. For EMB is specifications, one of the driver boxes will house an emergency driver with a built-in battery backup and will be indicated by the labeling on the driver box.
