Sterling III - LED Luminaires (Ex ec)
ATEX, IECEx
INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
Please read these instructions carefully before installing or maintaining this equipment.
Important:
Good electrical practices should be followed at all times and this data should be used
as a guide only.
Technical Drawing:
I-ST3N-01.doc
IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec)
GRP Standard body
Issue 8
December 2018
The
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Chalmit Sterling III
Summary of Contents for Chalmit Sterling III
- Page 1 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) Sterling III - LED Luminaires (Ex ec) ATEX, IECEx INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS GRP Standard body Please read these instructions carefully before installing or maintaining this equipment.
-
Page 2: Special Conditions For Safe Use
IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) 0.0 Specification Type Of Protection Ex ec, (non-sparking). Ex tc, Protection Standards EN/IEC 60079-0, EN/IEC 60079-7, EN/IEC 60079-31 Area Classification Zone 2 areas to EN/IEC 60079-10-1, Zone 22 areas to EN/IEC 60079-10-2. - Page 3 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) 3.0 Installation and Safety 3.1 General There is no health hazards associated with this product whilst in normal use. However, care should be exercised during the following operations. Installation should be carried out in accordance with relevant EN / IEC standard or the local hazardous area code of practice, whichever is appropriate.
- Page 4 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) 3.2 Tools Suitable spanners for installing cable glands. 3mm flat blade screwdriver. 12mm flat blade screwdriver. No. 6 pozidrive Pliers, knife, wire strippers/cutters. 3.3 Electrical Supplies The supply voltage and frequency should be specified when ordering. A maximum voltage variation of +6%/-6% on the nominal is expected.
-
Page 5: Replacing Led's
IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) 3.6.4 Cabling Access for cabling is via diffuser cover; care is to be taken, as there is no suspension of diffuser cover. The diffuser clip screws are removed and the diffuser clips are undone and the diffuser laid aside. The gear tray is dropped down after unclipping the steel mounting clips. - Page 6 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) Overhaul (Refer EN / IEC 60079-19) Components to be incorporated into or used as replacement parts of the equipment shall be fitted by suitably trained personnel and other than the fuse are to be purchased from the manufacturer as to ensure that certification is not invalidated.
- Page 7 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) Tables A and B TABLE A - SCHEDULE – LED CONTROL GEAR – NON EMERGENCY – 120 to 277Vac – 127 to 300Vdc Note: for Dust Ratings Refer to Max Surface Temperatures.
- Page 8 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) EU-Declaration of conformity UE-Déclaration de conformité EU-Konformitätserklärung Manufacturer Chalmit Address 388 Hillington Road, Glasgow. G52 4BL Scotland UK Product Sterling lIl LED Type Examination Certificate CML 16ATEX 4101X...
- Page 9 IOM – STERLING III - ZONE 2 LED (ATEX, IECEx, Ex ec) On behalf of the Chalmit, I declare that, on the date the equipment accompanied by this declaration is placed on the market, the equipment conforms to all technical and regulatory requirements of the above listed directives.
