Ref No.; Part No.; Qty.; Description - Simplicity 2415 Illustrated Parts List

Triple Catcher, Hitch & Tube Group

REF NO.

PART NO.

1 1717025
2
3 1960241
4 1717067
5 925160
6 1910531
7 1667248
8 1704405
9 1716970
10 1717041
11 1717524
12 1716968
13 1716972
14 1921176
15 1916966
16 1916951
17 1720948
18 1717085
19 1960033
20 1921333
21 1919326
22 1717037
23 1925003
24 1919438
25 1716973
26 1716966
27 1720945
28 1917372
29 1917356
30 1717039
31 1717038
32 1720875
33 1672344
34 1960074
35 928707
36 1960223
37 1717027
38 1931333
39 1921319
40 1921319
41 1920397
42 1672689
43 172744
44 1686761
45 1717071
46 1717082
47 1703764
48 1703807
49 1672023

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1693204 Triple Catcher W/ Hitch & Tube
TP 400-2415-00-AT-SMA

QTY.

1 COVER & SCREEN ASSEMBLY (Inc. Ref. No. 2,3,4,5,6,9,10,11,12,13)
1 COVER, GRASS CATCHER, See Ref. #1
9 RIVET
3 PLATE ASSEMBLY
25 RIVET
16 WASHER
6 CLIP, Canoe
1 DECAL, Safety
1 CLAMP
1 SCREEN
1 CLAMP, Seal
1 SEAL
1 ANGLE, Screen
6 CAPSCREW, Hex Head, 1/2-13 x 2
6 LOCKWASHER, 1/2
6 NUT, Hex, 1/2-13
1 HITCH ASSEMBLY
1 ROD
1 HAIR PIN
8 CAPSCREW, Hex Head, 5/16-18 x 1
8 WASHER, 5/16
1 COVER
3 CAPSCREW, Taptite, 1/4-20 x 1/2
8 LOCKNUT, 5/16-18
1 CHANNEL & BRACKET ASSEMBLY
1 PLATE & BRACE ASSEMBLY
1 HINGE
10 NUT, 5/16-18
10 LOCKWASHER, 5/16
1 DEFLECTOR
1 DUCT INLET
2 HINGE
3 PIN, 3/8 x 2-3/4
3 PIN, Hair
16 RIVET
2 CARRIAGE BOLT, 5/16-18 x 1-1/4
1 SUPPORT ASSEMBLY
10 CARRIAGE BOLT, 5/16-18 x 3/4
3 CAPSCREW, Hex Head, 1/4-20 x 1-1/4
6 WASHER, 1/4
3 LOCKNUT, 1/4-20
3 HOOK, "S"
2 STRAP
1 TUBE, Lower
1 TUBE, Upper
1 SEAL
3 BAG, Grass
3 HANGER
3 CLIP

DESCRIPTION

3
