Simplicity 2385 Illustrated Parts List

Snapper lawn aerator parts list
Hide thumbs


Advertisement

Attachment
Illustrated

Parts List

M A N U F A C T U R I N G , I N C .
500 N Spring Street / PO Box 997
Rev. 11/2000
Port Washington, WI 53074-0997 USA
TP 400-2385-00-AT-SMA
© Copyright 2000 Simplicity Manufacturing, Inc.All Rights Reserved.

Advertisement

Table of Contents
loading

  Related Manuals for Simplicity 2385

  Summary of Contents for Simplicity 2385

  • Page 1: Parts List

    M A N U F A C T U R I N G , I N C . 500 N Spring Street / PO Box 997 Rev. 11/2000 Port Washington, WI 53074-0997 USA TP 400-2385-00-AT-SMA © Copyright 2000 Simplicity Manufacturing, Inc.All Rights Reserved.
  • Page 2 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. 2 2 2 2 6 The above parts group applies to the following Mfg. Nos.: 1692623 Lift Lever - Regent © Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2385-00-AT-SMA...
  • Page 3 1919438 1704716 1921977 1675795 1665591 1921719 1927609 Footnotes: The above parts group applies to the following Mfg. Nos.: 1692623 Lift Lever - Regent TP 400-2385-00-AT-SMA DESCRIPTION BUTTON GRIP LEVER ASSEMBLY PUSH NUT, 5/16 SPRING LATCH, Lift Lever BRACKET SPACER LOCKNUT, 5/16-18...
  • Page 4 Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
