Simplicity 2438 Illustrated Parts List

Snapper lawn aerator parts list
Hide thumbs


Advertisement

Attachment
Illustrated

Parts List

M A N U F A C T U R I N G , I N C .
500 N Spring Street / PO Box 997
Rev. 10/2000
Port Washington, WI 53074-0997 USA
TP 400-2438-00-AT-SMA
© Copyright 2000 Simplicity Manufacturing, Inc.All Rights Reserved.

Advertisement

Table of Contents
loading

  Related Manuals for Simplicity 2438

  Summary of Contents for Simplicity 2438

  • Page 1: Parts List

    M A N U F A C T U R I N G , I N C . 500 N Spring Street / PO Box 997 Rev. 10/2000 Port Washington, WI 53074-0997 USA TP 400-2438-00-AT-SMA © Copyright 2000 Simplicity Manufacturing, Inc.All Rights Reserved.
  • Page 2 Turbo Clean Sweep Twin Catcher - Cover & Bag Group NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher © Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2438-00-AT-SMA 983952...
  • Page 3 1704056 Footnotes: The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher TP 400-2438-00-AT-SMA DESCRIPTION TUBE ASSEMBLY Support (Incl. Ref. Nos. 2, 3, 4, 5, 6, 8, 9 & 11) RIVET, Pop SUPPORT, Tube...
  • Page 4 Turbo Clean Sweep Twin Catcher - Hitch Group 984020 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher © Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2438-00-AT-SMA...
  • Page 5 1916965 1703846 1931335 Footnotes: The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher TP 400-2438-00-AT-SMA DESCRIPTION CAPSCREW, Hex Head, 5/1 6-18 x 1-1/4 BRACE, Bar CAPSCREW, Hex Head, 3/8-16 x 1 BRACKET, Lower...
  • Page 6 Turbo Clean Sweep Twin Catcher - Adapter, Blade & Tube Group 984017 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher © Copyright 2000 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-2438-00-AT-SMA...
  • Page 7 1910531 1705063 910542 1705112 Footnotes: The above parts group applies to the following Mfg. Nos.: 1691792 Turbo Clean Sweep Twin Catcher TP 400-2438-00-AT-SMA DESCRIPTION TUBE, Upper NUT, Hex, Nylock #10-24 WASHER, Flat TUBE, Middle SCREW, Truss Head, #10-24 x 3/4...
  • Page 8: Hardware Identification & Torque Specifications

    Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
