Snapper 216518B Parts Manual page 5

HANDLES & CONTROLS
Item Part No Qty
1 7074411 1
2 7074156 1
3 7033985 1
4 7033986 1
5 7074418 1
6 7034872 1
7 7034608 1
7 7078078 1
7 7074141 1
8 7074473 1
9 7028407 1
10 7034604 1
11 7012121 1
12 7012122 1
13 7074003 1
14 7024641 2
15 7073822 1
16 7013849 1
17 7073913 1
18 7073826 1
18 7074140 1
18 7074469 1
19 7091200 4
20 7091130 1
21 7091904 1
22 7090895 1
23 7012114 1
24 7090595 3
25 7091601 2
26 7091575 1
27 7074113 1
28 7091606 1
29 7023813 1
30 7091740 4
31 7035744 4
32 7079577 2
33 7090053 3
Footnotes:
Note* used on 216518B, P216518B, P217018BV, RP217018BV, EP217018BV & ERP217018BV
Note** used on P217018BV, P216518B, P216018KWV, RP217018BV, RP216018KWV, EP217018BV & ERP217018BV
Note* See also Throttle Control Page
ref Decal Page
21" STEEL DECK
SERIES 18
Description
HANDLE, Upper
HANDLE, Middle
HANDLE, Lower LH (Adjustable)
HANDLE, Lower RH (Adjustable)
BAIL, OPC Control
CLIP, Zone Control
*CABLE, Zone Control (52-63/64" Long)
CABLE, Zone Control (50-31/64" Long)
CABLE, Zone Control (56-5/16" Long)
HANDLE, Clutch
GRIP, International Symbol
CABLE, Clutch Control (41-1/4" Long)
COVER, Vinyl
SPRING, Clutch- 21S
BRACKET, Shift
TIE, Wire, 1.29 long, black
BRACKET, Bell Crank
SPACER, .33 x .63 x .156
BELL CRANK
CONTROL PANEL (w/o Ground Drive Slot)
**CONTROL PANEL (w/o Electrical Switch Hole)
CONTROL PANEL (w/Electrical Switch Hole)
SCREW, 1/4-20 x 1/2" Pan Head Self-Tap (Torx)
WASHER, .33 x .88 x .09 Flat
SCREW, 5/16-18 x 7/8" Hex Head Cap, GR 5
TEENUT, 5/16-18
BUSHING, Differential, .328 x .625 x .41
BOLT, 5/16-18 x 3/4" Hex Flange Lock GR 5
NUT, 5/16-18 Hex Flange Lock, GR 5
NUT, 5/16-18 Hex Center Lock
LEVER, Shift
NUT, 5/16-24 Hex Center Lock GR 5
CLIP, Wiring Harness
SCREW, 5/16-18 x 1-7/8" Curved Head GR 2
KNOB, 5/16-18 Wing (Black)
SCREW, 1/4-20 x 1-1/2 Hex Head Cap GR 5
WASHER, 1/4" Internal Tooth Lock
5
Note
All
All
All
All
All
All
P217018BVE & RP217018BVE
P216018KWV & RP216018KWV
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
All
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
216518B
P217018BVE & RP217018BVE
All
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
Self-Propelled Models
All
was 7090585 (All)
was 7091067 (S-P Models)
Self-Propelled Models
was 7091074 (All)
All
was 7091189 (All)
All
All
was (All)
Manual No. 7006139
TP 400-5047-1-WB-N
