12770_Bel Pro Remote_Manual 6/2/03 10:40 PM Page 1 Scale: 100%
5
7
X
R
L
E
D
O
M
BEL
BEL
Front Radar Receiver
• Miniature weather-proof Radar Receiver
• Universal mounting bracket with stainless steel hardware
• Built-in 6 foot shielded cable with waterproof connector
• 13 foot shielded cable with in-line grommet and waterproof
connector
• 12 nylon wire ties to secure cable
Front Laser Receiver
• Weather-proof sensor
• 13 foot shielded cable with in-line grommet
• Universal mounting bracket with stainless steel hardware
Miniature Display Controller
• User Display mounts easily to instrument pod, dashboard,
or console
• Velcro and adhesive pads provided for secure mounting
• Optional hidden display included
5442 West Chester Road, West Chester, Ohio 45069
TM
Sales/Service 800-341-2288 • www.beltronicspro.com
©2003 SWS
is a trademark of SWS LC. Features, specifications and prices subject to change without notice.
SYSTEM
SYSTEM
SAFETY
SAFETY
RADAR/LASER
RADAR/LASER
INSTALLED
INSTALLED
CUSTOM
CUSTOM
M O D E L
Interface
• Central module connects to switched 12-volt power and ground
• All components plug directly in using modular connections
• 3M connector taps into existing vehicle wiring
Rear Laser Receiver
• Weatherproof license plate mounted sensor
• 30-foot cable with modular connector
Documentation
• Comprehensive Owner's Manual
• Installation Manual
Built-in Diagnostics
• Confirms all components are operational
IMPORTANT NOTES
Read This First
Please read both sides of these instructions before starting your installation.
For the easiest trouble-free installation, install the Interface first, and wire it to a
12-volt switched circuit.
Then before installing the other components, plug all of them into the Interface
and power up the unit to confirm proper operation.
Important Installation Warnings
1
A professional installer must install your
new
BEL
this system requires experience and
expertise in automotive electronics. Car
Audio specialists and many car dealers
can install
R X 7 5
2
Attempting to install this product
without expertise in automotive
electronics installation can cause
personal injury, or damage to your
vehicle.
3
If your vehicle is damaged during
installation, its safety systems may be
compromised, which could cause
personal injury or property damage.
4
Improper installation may void
the warranty.
Performance Warning
To get the best performance possible, the
. Installation of
mounting location of the Radar Receiver is
critical. Although radar signals will pass
through some types of plastic, mounting
the Radar Receiver so that it has a clear
BEL
for you.
"view" of the road will ensure maximum
warning.
Since Laser signals will not pass through
any objects, including plastic, it is critical
that the Laser Receivers be mounted
perfectly level, and have an unobstructed
"view" of the road.
