Bill of Materials

Reference
C1, C2
C3
J1
J2
JP1, JP2, JP3, JP4
R1, R2, R3, R4
TP1
TP3
TP5
TP8
TP9
TP2, TP4, TP6, TP7
U1
Value Footprint
10μF
no-pop
banana jack pair
banana jack pair
3 pos. jumper 0.100 (in)
no-pop
test point 0.040 (in)
test point 0.040 (in)
test point 0.040 (in)
no-pop 0.040 (in)
no-pop 0.040 (in)
test point 0.040 (in)
SC202A 2.5 x 3.0 (mm)
0603
Pads are included to add a feed-forward capacitor when
external resistors are used.
IN
OUT
Jumpers are used to set the CTL pins in either a high or low
state.
External pads included for adding external feedback, measur-
0603
ing loop stability.
IN
OUT
LX
BODE- (used for measuring loop stability)
BODE+ (used for measuring loop stability)
Ground
Semtech integrated circuit
SC202A EVB
Hardware Notes
