PC and the SX8650. The right area is dedicated to the SX8650 and the touch screen connectors. The S_ON switch is the SX8650 power supply switch. A red led is lighted in the ON position. When it is switch off the SX8650 is not supplied but the interface circuitry is still powered on.
For maximum flexibility, the SX8650EVK is designed for easy interfacing to multiple analog-sources. The board is powered from the USB. The S_V switch allows the user to test the SX8650 to 3.3V (switch to the left) or 1.85V (switch to the right).
2.5. Digital Interface JP1 header also gives access to the digital control and serial data pins of the SX8650. If an external host is used to test the part, the jumpers JP1 (7-8), JP1 (9-10), JP1 (11-12), JP1 (13-14) should be removed and the SCL, SDA, NRST and NIRQ signals respectively connected to JP1 (8), JP1 (10), JP1 (12), JP1 (14).
