- Page 1 SX1211SK868/915 User Guide TN1211.01 SX1211 Low Power ISM Transceiver Evaluation Kit User Guide Rev1.1 1 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor...
-
Page 2: Table Of Contents
Highlights ..........................15 SX1211SK – Basic PC-GUI Screen Layouts............... 15 SX1211SK PC-GUI Screen Areas..................16 5.4.1 Menu Bar ......................... 16 5.4.2 Binary Registers ......................17 5.4.3 Register Status ........................ 18 Rev1.1 2 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... - Page 3 Packet Handler Tx ....................... 26 Packet Handler Rx....................... 28 Ping – Pong Test and Communication quality..............29 Troubleshooting ..........................29 Introduction .......................... 29 Highlights ..........................29 Common problems ......................30 Rev1.1 3 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor...
-
Page 4: General Introduction
This document has been written with the courtesy of Ylynx www.y-lynx.com referred as official Semtech Partner. This first chapter contains general information that will be useful to know before using the SX1211 Starter Kit environment. HIGHLIGHTS The information you will gain from this chapter: •... -
Page 5: Introduction
Installing SX1211SK “Graphical User Interface” software WHAT THE SX1211SK IS The SX1211 Starter Kit is an environment for the SEMTECH SX1211 transceiver. The SX1211SK allows the demonstration of a two way communication between two radio boards, to perform practical "demonstration", "range" and "site survey" testing but also to evaluate the RF transceiver. -
Page 6: Sx1211Sk - "Graphical User Interface" Software
Locate and click on the ‘Control Panel’ button d) Within the Control Panel window, locate and double-click on the ‘Add/Remove Programs’ ICON. e) Locate and select the SX1211SK ICON and follow the removal procedures. Rev1.1 6 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 7: Sx1211Sk - Tutorial
One objective of this Starter Kit is to demonstrate a two way communication between two radio modules, but also to evaluate the SEMTECH transceiver SX1211. In order to have a high flexibility, the Starter Kit board has been developed in order to support all the SX1211 RF modules and so few buttons have been added to the board (see Figure 3.1). -
Page 8: Default Ping Pong Test Overview
The Manual mode is the same as Automatic mode. The main difference is the selection of the frequency. In this case a user selects the frequency by pushing on the "Frequency Selection" button. Rev1.1 8 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... - Page 9 Change Frequency Figure 3.2: Ping. Pong Test Flowchart overview Note: The user can change the frequency of the receiver (Slave) at anytime by pushing on the "Frequency Selection” button. Rev1.1 9 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor...
-
Page 10: Ping-Pong Test Procedure
Refer to paragraph 3.6.5 and 3.6.5 TX LED is blinking Ping Pong Test RX LED in On End Settings Auto jump mode Refer to paragraph 3.6.7 Figure 3.3: Ping-Pong Settings flowchart Rev1.1 10 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 11: Frequency Band Selection
Automatic Mode. C1 is still down. The board is now in automatic mode; the user can not change the frequency manually but can still modify the output power. Rev1.1 11 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 12: Configuration Switch Buttons
After using the Ping Pong Demo, you are ready to start using the kit. HIGHLIGHTS • SX1211SK - Functional flow chart • Default Ping Pong Test • User Ping Pong Test • Stand Alone Evaluation Mode • PC – GUI command Rev1.1 12 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 13: Sx1211Sk - Functional Flow Chart
A Default Ping Pong Test program is embedded within a SEMTECH RISC microcontroller chip (XE88LC05) on the board. The Ping Pong Test (Default or User) is automatically started after the power up if no PC is attached to the board’s RS232 connector and if the option has not been disabled... -
Page 14: Equipment Required
“Save Config” button. The RESET operation will erase all the user parameters. To start the User Ping Pong test the user needs to click on the “User Ping-Pong” button on the PC-GUI interface before disconnecting the RS232 cable from the board. Rev1.1 14 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 15: Read Back The Configuration
The SX1211SK PC-GUI consists of a single fixed screen. The screen is presented to easily allow the user to manipulate the SX1211 radio module at the binary level. The PC-GUI screen is divided into seven primary areas as shown in the diagram below. Rev1.1 15 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 16: Sx1211Sk Pc-Gui Screen Areas
The MENU Bar allows the user to select the Com_Port that the board is attached to. Reset registers, Band, Pre-Defined SX1211 Settings, Ping Pong, Sync Word, Data Handler and Help are included in the menu. Rev1.1 16 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 17: Binary Registers
The RSSI measurement button is available only if the RSSI is enabled and then the PC-GUI displays the result of the measurement. The RSSI output is available in two formats, in binary and in Hexadecimal. Rev1.1 17 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 18: Register Status
FSK modulation has been enabled. If the OOK modulation has been selected, the polyphase filter is automatically enabled. The Tx window displays the information used by the transmitter and set in the SX1211 Registers window. Rev1.1 18 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 19: Sx1211Sk Control Window
Config”. It is also possible to save a configuration in a file (extension .sk) using the FILE menu. The file can be loaded afterwards using the FILE in the menu. Semtech provides example of most configurations. Rev1.1 19 of 30 www.semtech.com... -
Page 20: Application Selection Window
This mode allows the user to evaluate the SX1211 performances but also to program other parameters for the User Ping-Pong test. For more information about SX1211 registers, please refer to the SEMTECH SX1211 Datasheet. When the board is connected to the PC, the user can evaluate the performance of the SX1211 transceiver by connecting a spectrum analyzer or an FM generator. -
Page 21: Sx1211Sk Menu Bar And Sub-Menu Option
SX1211 RF module being tested is designed for. Note: The 915MHz band is subdivided in two bands, 902-915MHz and 915-928MHz but can be address with the same hardware (RF module). Rev1.1 21 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 22: Pre-Defined
“User Ping Pong” before removing the PC connection to the board. By clicking on “OK” the new frequencies will be automatically transferred to the SX1211, do not click on “Send configuration” Rev1.1 22 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 23: Sync Word
The GUI interface for the SX1211SK offers the advantage to program a pattern generator (Transmitter FIFO Handler). This mode is available only if the SX1211 RF module has been set in transmitter mode with the Buffered mode enabled (MCParam, Address 1, bit 5). Rev1.1 23 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 24: Buffered Hanlder Rx
SX1211SK is in receiver mode and if the Buffered mode has been selected. The interrupt configuration (IRQ0 and IRQ1) will affect the way to fill the FIFO. For more information about the SX1211 interrupts, please refer to the SEMTECH Datasheet SX1211. Rev1.1 24 of 30 www.semtech.com... - Page 25 D: Fifo_size: The size of the packet can be selected from 16 bytes to 64 bytes. E: Single Fifo Reception: the fill of the FIFO will be stop after receiving the latest byte (16 , 32 , 48 or 64 Rev1.1 25 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor...
-
Page 26: Packet Handler Tx
SX1211SK868/915 User Guide PACKET HANDLER TX The Semtech transceiver SX1211 embeds a packet handling mode, useful to reduce the software complexity and microcontroller tasks. For more information, please refer to SX1211 Datasheet. The SX1211 Starter Kit from Y-Lynx, allows the user to play with the packet handler in transmitter as well as in receiver. - Page 27 F: DC Free Encoding: Two methods of en coding are available with the SX1211, the Manchester encoding and the Withering encoding. For more information, please refer to the Semtech SX1211 Datasheet.
-
Page 28: Packet Handler Rx
LED on the screen called CRC_status. F: DC Free Encoding: Two methods of en coding are available with the SX1211, the Manchester encoding and the Withering encoding. For more information, please refer to the Semtech SX1211 Datasheet. G: Fifo_size: The Fifo-size can not be modified and is hard-coded to 64bytes. -
Page 29: Ping - Pong Test And Communication Quality
This section describes some common problems associated with using SX1211 Starter Kit and steps to follow to solve those problems. HIGHLIGHTS This section discusses the following: • Communications cannot be established with the Starter Kit • Data Handler menu not enabled Rev1.1 29 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor... -
Page 30: Common Problems
Buffered mode / Packet mode is enabled for the Buffered Handler Tx / Packet Hanlder Tx. To activate on of these mode, click on Predefined>Data mode>… END OF DOCUMENT Rev1.1 30 of 30 www.semtech.com Downloaded from Elcodis.com electronic components distributor...
