- Page 1 EB-GS3471-00 Evaluation Board User Guide GS3471 www.semtech.com 1 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
-
Page 2: Table Of Contents
1.7 JTAG Header ............................11 1.8 Status LED’s ............................11 1.9 Modes of Operation ........................12 2. EB-GS3471-00 Schematics......................... 13 3. EB-GS3471-00 Board Layout........................17 4. EB-GS3471-00 Bill of Materials (BOM)....................19 GS3471 www.semtech.com 2 of 22 Evaluation Board User Guide Rev.3... - Page 3 Together with the EB-GS3471-00 Evaluation Board, this document serves as a guide for evaluating the GS3471. The GS3471 is a Semtech 3Gb/s, HD, SD SDI Receiver. For more information on the GS3471, please refer to the Product Data Sheet (PDS-060500). This document is partitioned into the following sections: •...
- Page 4 GSPI STAT4 WCLK TERM1 STAT5 AMCLK AUDIO FTDI AUDIO JTAG LEDs SWITCH RCA x2 RCA x2 RESET PB Power Figure A: Block Diagram GS3471 www.semtech.com 4 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
-
Page 5: Eb-Gs3471-00 User Guide
Figure 1-1: GS3471 Evaluation Board (EB-GS3471-00) 1.1 Power (J5 or J13) The EB-GS3471-00 board is powered by a +5V supply through a Micro-B USB connector (J5) or through the auxiliary power connector (J13). Not all USB ports are capable of supplying enough current to power the board. -
Page 6: Sdi Input (J6 And J7)
1.2 SDI Input (J6 and J7) The EB-GS3471-00 includes two 3G-SDI inputs DC-coupled to the GS3471. The applied video stream will first pass through Semtech's GS3140 Cable Equalizer (PDS-060939) before entering the DDI input pin of the GS3471. The pin J6 provides a DC path to the GS3471 through the GS3140, while the pin J7 provides a direct AC path to the GS3471. -
Page 7: Gs2988 Switch Settings (Sw2)
SMPTE 259M rise/fall time specification. SW1.3 SD_HDN When LOW, the serial output will meet the SMPTE 292M and SMPTE 424M rise/fall time specification. GS3471 www.semtech.com 7 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential... -
Page 8: Sdi Loop Through (J10)
• SMPTE 292M • SMPTE 259M The EB-GS3471-00 evaluation board supports DVB-ASI at 270Mb/s and data rates from 270Mb/s to 2.97Gb/s. The output is configured for a single ended coaxial cable terminated with a BNC connection. 1.5 Video Header (J1) Parallel video data with the PCLK and timing signals H, V, and F are available on a 60-pin connector (J1). -
Page 9: Audio Header (H1, J4 And J12)
(H1) and AES mode (J4 and J12). 1.6.1 Audio Header (H1) This connector provides extracted 8-channel audio in conjunction with AMCLK, ACLK, and WCLK. GS3471 www.semtech.com 9 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018... -
Page 10: Aes Model - Rca Connectors (J4 And J12)
H1.19 IO_VDD H1.20 This pin-out takes precedence over the silk-screening on the EB-GS3471-00. 1.6.2 AES Model — RCA Connectors (J4 and J12) For AES mode, AES-encoded CMOS-level signals are distributed through line drivers, and supplied to two RCA connectors (J4 and J12). -
Page 11: Jtag Header
J2.4 IO_VDD J2.5 JTAG_TMS J2.6, J2.7, J2.8 J2.9 JTAG_TDI 1.8 Status LED’s The functions for the LEDs found on the EB-GS3471-00 are described in Table 1-6. Table 1-6: Status LEDs Description Colour Device Description Programmable When active, input Serial Data CH0 signal loss GS3140 detected. -
Page 12: Modes Of Operation
Green — When internal +2.5V is good, LED is active. Reset indicator, When LED active Green — EB-GS3471-00 is not in reset. Green — When internal +1.8V is good, LED is active. Green — When internal +1.2V is good, LED is active. -
Page 13: Eb-Gs3471-00 Schematics
2. EB-GS3471-00 Schematics Figure 2-1: EB-GS3471-00 Schematic GS3471 www.semtech.com 13 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential... - Page 14 R115 GREEN R110 GREEN TP23 TP25 TP27 TP29 LABEL LABEL LABEL LABEL TP24 TP26 TP28 LABEL LABEL LABEL Figure 2-2: EB-GS3471-00 Schematic 2 GS3471 www.semtech.com 14 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
- Page 15 GREEN GREEN GREEN LABEL Figure 2-3: EB-GS3471-00 Schematic 3 GS3471 www.semtech.com 15 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
- Page 16 TP10 Figure 2-4: EB-GS3471-00 Schematic 4 GS3471 www.semtech.com 16 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
-
Page 17: Eb-Gs3471-00 Board Layout
3. EB-GS3471-00 Board Layout Figure 3-1: Layer 1 (TOP) Figure 3-2: Layer 2 (GND1) Figure 3-3: Layer 3 (PWR1) Figure 3-4: Layer 4 (GND2) GS3471 www.semtech.com 17 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential... - Page 18 Figure 3-5: Layer 5 (SIG1) Figure 3-6: Layer 6 (SIG2) Figure 3-7: Layer 7 (GND3) Figure 3-8: Layer 8 (BOT) GS3471 www.semtech.com 18 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018 Proprietary & Confidential...
-
Page 19: Eb-Gs3471-00 Bill Of Materials (Bom)
4. EB-GS3471-00 Bill of Materials (BOM) Table 4-1: Bill of Materials Quantity Ref Description Description C2, C3, C4, C5 Capacitor; Ceramic 1.0μF 10V 10% X5R 0402 C6, C7 Capacitor; Ceramic 0.47μF 10V 10% X5R 0402 C8, C12 Capacitor; Ceramic RF 18pF 50V 5% C0G 0402 C9, C10, C13, C14, C15, C16, C41, C54, C77, Capacitor;... - Page 20 R69, R70 Resistor; 27.0Ω 1/10W 1% 0402 SMD Resistor; 12.0kΩ 1/10W 1% 0402 SMD Resistor; 15.0kΩ 1/16W 1% 0402 SMD Resistor; 56.0kΩ 1/10W 1% 0402 SMD GS3471 www.semtech.com 20 of 22 Evaluation Board User Guide Rev.3 Semtech PDS-061243 March 2018...
- Page 21 Test Point; PC Multi-purpose Red TP17, TP18, TP19, TP20 Test Point; PC Multi-purpose Black IC; EEPROM 1kBIT 2MHz SOT23-6 IC; Multi-Rate Adaptive 3G SDI Equalizer (Semtech GS3140) IC; 3G, HD, SD SDI Receiver, with Integrated Adaptive Cable Equalizer (Semtech GS3471) IC;...
- Page 22 Information relating to this product and the application or design described herein is believed to be reliable, however such information is provided as a guide only and Semtech assumes no liability for any errors in this document, or for the application or design described herein.
