PARAMETER
Optical – All Units
Fiber type
Maximum fiber length
for guaranteed
performance
Optical output power
Optical wavelength
Environmental
Operating temperature
Storage temperature
Humidity
Weather resistance
Airborne contaminants
(DRU only)
RF Forward Path
System bandwidth
800 MHz (A and B bands)
Output power
Gain
Gain variation
OIP3
CDMA ACPR1
Spurious Output
Maximum RF input
signal level (composite)
RF Reverse Path
System bandwidth
800 MHz (A and B bands)
Gain
Gain Variation
Automatic Gain Limiting
Page 14
© 2006, ADC Telecommunications, Inc.
Table 5. System Specifications
SPECIFICATION
Multi-mode: 50 or 62.5 micron core
Single-mode: 9 micron core
500 m (1,641 ft)
750 m (2461 ft)
10 km (32,808 ft)
–10 to –3 dBm
850 nm for multi-mode use
1310 nm for single-mode use
0º to 50º C (32º to 122º F)
–30º to +70º C (–22 to 158º F)
No condensation
NEMA 1, IEC 529 IP30
At or below levels established in Telecordia Standard, GR-63-CORE,
Network Equipment-Building System (NEBS) Requirements: Physical
Protection, Section 4.5 Airborne Contaminants, Table 4-11, Indoor
Contaminant Levels.
25 MHz
US Cellular 869 to 894 MHz
See Table 6
+33 dB nominal
< 6 dB
< 1.5 dB variation per 1.25 MHz
CDMA channel
+35 dBm typical
< –45 dBc
< –40 dBm
Approximately –10 dBm
25 MHz
US Cellular 824 to 849 MHz
+10 dB nominal
< 6 dB
< 1.5 dB variation per 1.25 MHz
CDMA channel
Enabled for composite RF input
> –40 dBm
REMARKS
Two fibers per transport link
With 62.5 micron core MM fiber
With 50 micron core MM fiber
With 9 micron core SM fiber
Indoor installation only
Maximum composite output signal
requires maximum input signal
At room temperature
Over frequency, temperature, and
unit to unit. May have up to 2 dB
variation at upper band edge.
At max. composite output power
Will vary depending on access protocol
and number of carriers
Over frequency, temperature, and
unit to unit.
Prevents A/D saturation with large
inputs.
(continued)
