- Page 1 TRIGNO EMG System Spring Contact Adapter User’s Guide Copyright © Delsys Incorporated Delsys Logo and EMGworks are Registered Trademarks of Delsys Inc. MAN-015-1-3...
-
Page 3: Table Of Contents
Technical Service and Support Warnings and Precautions Device Information Disclaimer System Requirements Spring Contact Adpater Overview Using the Sensors Charging the Sensors Sensor Pairing Smart Sensor Features Applying the Spring Contact Adapters Maintenance and Care Specifications Trigno Spring Contact Adapter User’s Guide... -
Page 4: Important Information
DO NOT USE on Patients with allergies to Silver. DO NOT USE in critical care applications. Technical Service and Support For information and assistance visit our web site at: www.delsys.com Contact us at: telephone: (508) 545 8200 email: support@delsys.com Trigno Spring Contact Adapter User’s Guide... -
Page 5: Warnings And Precautions
Connect only to Delsys-approved devices. Connecting a patient to high-frequency surgical equipment while using Delsys EMG systems may result in burns at the site of the EMG sensor contacts. Immediately discontinue device use if skin irritation or discomfort occurs. -
Page 6: Device Information
Trigno Systems should be stored and operated between 5 and 40 degrees Celsius due to the presence of an internal Lithium Poly- mer rechargeable cell. Storing or operating the device, and conse- quently the cell, outside of this temperature range may compro- mise the integrity and the safety features of the cell. - Page 7 Pursuant to Part 15.21 of the FCC Rules, any changes or modi- fications to this product not expressly approved by Delsys Inc. might cause harmful interference and void the FCC authorization to operate this product.
-
Page 8: Disclaimer
This responsibility befalls the electrode manufacturer, the Client performing the study and the Institutional Review Board overseeing the study. System Requirements The Trigno Spring Contact Adapter is designed to be used with Trigno Wireless EMG Systems. Trigno Spring Contact Adapter User’s Guide... -
Page 9: Spring Contact Adpater Overview
Spring Contact Adpater Overview The Trigno Spring Contact Adapter is an accessory to the Trigno EMG System for these Researchers wishing to detect EMG sig- nals with alternative methods to those provided by the Trigno standard contact approach. The main sensor body uses the 4 silver contacts to establish a local electrical reference from which to measure the EMG signals detected by the spring contacts. -
Page 10: Using The Sensors
Using the Sensors Charging the Sensors Connect the Trigno power supply to the circular DC jack lo- cated on the side of the Trigno Base/Recharge Station. Energize the power supply by connecting it to a Mains outlet. Be sure to use the appropriate plug adapter for your location. -
Page 11: Sensor Pairing
Sensor Pairing Trigno sensors communicate with a custom wireless protocol that links each sensor to the active Trigno network This linking process is known as sensor “pairing”, and is initiated through the “Pair” command in EMGworks. 1. Turn sensor on by depressing the sensor button. -
Page 12: Smart Sensor Features
Figure 5: The calibration can be auto-detected, or manually re- trieve.. Smart Sensor Features After pairing, the association of sensors to the Trigno System is retained for all future uses. Any configuration in EMGworks can be made to reflect the last paired set of sensors by clicking the “Refresh Smart Sensors”... -
Page 13: Applying The Spring Contact Adapters
“B” device. (Note that the icon may appear different than shown. Pair Please refer the Trigno EMG System User Guide for further de- tails on system and sensor operation. Applying the Spring Contact Adapters 2-slot interface... - Page 14 Adhesive Sensor Interfaces are for single use only. Immediately discontinue use if skin irritation or discomfort occurs. All Adhesive Sensor Interfaces are for single use only. Discard after using. Reseal storage bag to maintain freshness. Trigno Spring Contact Adapter User’s Guide...
-
Page 15: Maintenance And Care
Maintenance and Care Trigno sensors are encased in a sealed polycarbonate enclosure. The following points should be kept in mind when handling the sensors. • All sensors should be visually inspected before each use to en- sure that no mechanical deterioration has occurred. - Page 16 Do not submerge the sensors in any liquid under any cir- cumstance. The sensors contain sensitive electronic circuitry. Static dis- charges and intense magnetic fields should be avoided to pre- vent the risk of irreparable damage to the sensors. Trigno Spring Contact Adapter User’s Guide...
-
Page 17: Specifications
Actual performance will vary depending on usage conditions. Operation beyond these temperature limits may damage the rechargeable battery. Input-referred noise is calculated as a root mean square over a 3 second window sampled at 1926 kHz. Trigno EMG System... - Page 18 This page has been intentionally left blank. Trigno Spring Contact Adapter User’s Guide...
