Lighting

1. Press the Lighting icon to access the
Lighting screen (Fig. 14).
NOTE: Individual light status is displayed by
a light bulb to the left of the light's
name (Fig. 14A). The light icon will
display a lit bulb if the light is on or a
dim bulb if the light is off.
2.
Pressing the individual light buttons will
turn that light on or off.
3. Pressing the highlighted ALL ON or ALL
OFF icons (Fig. 14B) will turn all lights on
or off.

Monitor Panel

1.
Press the Monitor Panel icon to access the
Tank Monitor screen (Fig. 15).
2.
The monitored systems (Fig. 15A) will
display the status of the various tanks.
3. Press the buttons on the right to turn on
or off a specific component (Fig. 15B).
NOTE: The icons will light up when the
corresponding device is in use.

Slides

1.
Press the Slides icon to access the Slides
screen (Fig. 16).
2. Select a slide-out to operate.
A. Press the OUT (+) button (Fig. 16A) to
extend the slide-out.
B. Press the IN (-) button (Fig. 16B) to
retract the slide-out.
Rev: 03.06.19
Fig. 16
A
B
A
A

Stabilizers

1.
Press the Stabilizers icon to access the
Stabilizers screen (Fig. 17).
2. Select a stabilizer to operate.
A. Press EXTEND (Fig. 17A) to extend the
stabilizer.
B. Press RETRACT (Fig. 17B) to retract the
stabilizer.
Page 7
Fig. 14
B
Fig. 15
B
Fig. 17
A
B
