5.
Adjust the set points for the climate zone by updating the display.
NOTE: The adjusted temperature for the climate zone will be displayed inside a radius with a white dot on
it (Figs. 11 and 12).
A. Press and hold the white dot, then drag it around the radius (Figs. 11 and 12) to set the climate
zone's temperature set point.
I. Dragging the dot counterclockwise will lower (cooler) (Fig. 11) the set temperature.
II. Dragging the dot clockwise around the radius will raise (hotter) (Fig. 12) the set temperature.
B. Once the desired set point is reached, release pressure on the white dot.
C. Two white dots will appear (Fig. 13) when in Heat/Cool mode (Fig. 13A).
I.
Set the low end (cool) of the temperature range by moving the left dot counterclockwise.
II. Set the high end (heat) of the temperature range by moving the right dot clockwise.
Rev: 03.06.19
Fig. 11
Counterclockwise
Cool
A
Fig.13
Heat
Page 6
Fig. 12
Clockwise
CCD-0001540
