Page 1: User Manual Of
User Manual of CSL CS508 USB dongle... - Page 2 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 FCC RF Exposure Information (SAR) This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the United States. During SAR testing, this device is set to transmit at its highest certified power level and placed in positions that simulate RF exposure in usage near the body with the separation of 5 The exposure standard for wireless employs a unit of measurement known as the Specific Absorption Rate, or SAR.
-
Page 4: Table Of Contents
Installation ......................5 Power up : ....................5 CS508 takes power from the USB interface of an Andriod tablet as in the picture below. When CS508 is inserted into the tablet, the orange system LED will be light up....................... 5 Operation : .................... -
Page 5: Introduction
Introduction CS508 is a RTLS USB dongle to be used in a RTLS system. It can be used with other RTLS tag together for tag finding and range measurement. 1 Installation Power up : CS508 takes power from the USB interface of an Andriod tablet as in the picture below. -
Page 6: Cs508 Operation Modes
CS508 can be worked either as an Anchor or as a tag. 1.3.1 Tag Mode In tag mode, CS508 acts as a tag and can do normal RTLS ranging by putting it into a RTLS anchor installed environment. 1.3.2 Anchor Mode In anchor mode, CS508 acts as an anchor. -
Page 7: Product Specification
Besides, there is also a Geiger function to update the tag distance information regularly. 1.3.3 Product Specification Specifications: Physical Plastic sealed enclosure: 60 mm x 37 mm x 10 mm; Characteristics: Weight 30 g... -
Page 8: Antenna Properties
+5V+/-10% From external USB interface Order Code: CS508 1.3.4 Antenna Properties CS508 employs two antennas - an external monopole and an internal miniaturized SMD antenna for effective RF transmission and reception. Their properties are as below : Antenna 1 :... - Page 10 Antenna2 : Electrical Items Specifications Model C047-RF-002 Type of antenna Monopole with SMA male RP connector Frequency range 2400MHz – 2500MHz Nominal impedance 50 ohm Polarization Linear V.S.W.R 1.5 typically Gain +2.0dBi Mechanical Items Specifications Dimension in millimeter 108.5mm in length Weight 10gram...
