Setting Parameters

Parameters are entered using the membrane keys on the front panel of the micro4.
the
position. the
output channels on the rear of the instrument). the
key are used to change parameters.
Fig. 4 — Micro4
front panel
Lights: When a
pump is running,
the correspond-
ing light is on. For
example, the light
next to output 1 will
be on when pump
one is operating.
Arrow keys:
Move the cursor
around the display.
World Precision instruments
and
left right arrow
and
up down arrow
Data Save: Saves all parameters on LCD display
to memory. Next time the Ultra Microsyringe Pump
controller is turned on, the last paramaters saved will
be displayed.
DATA
SAVE
MicroSyringe Pump Controller
Output 1
Output 2
Output 3
Output 4
VOLUME
SET
I = Infuse
(nl)
W = Withdraw
World Precision
Instruments
Numeric keypad: Use these keys to
enter settings for infusion and withdrawal
rates and volumes.
keys move the cursor on the lcd display to the desired
keys select the channel (corresponding to the
TM
G = Grouped
N = Non-grouped
D = Disabled
VOLUME RATE
COUNTER
DEVICE TYPE
(nl)
1 2 3
S = nl/sec
M = nl/min
4 5 6
7 8 9
UltraMicroPump II
keys and the
number select
Run/Stop: Starts
and stops the
pump(s).
RUN
STOP
SELECT
.
Select: Toggles
the selected
0
parameters: Infuse/
Withdraw, Syringe
Size, Rate Units
(nL/sec or nL/min),
and mode (Grouped,
Non-grouped and
Disabled).
