4. Product specifications

4.1. Mini PCI Express Pin Assignment

PIN#
Table 1. Mini PCI Express Pin Assignment
Pin Name
1 WAKE#
3 RESERVED
5 RESERVED
7 CLKREQ#
9 GND
11 REFCLK+
13 REFCLK-
15 GND
17 RESERVED
19 RESERVED
21 GND
23 PERn0
25 PERp0
27 GND
29 GND
31 PETn0
33 PETp0
35 GND
37 RESERVED
39 RESERVED
41 RESERVED
43 RESERVED
45 RESERVED
47 RESERVED
49 RESERVED
51 RESERVED
PIN# Pin Name
YES 2 3.3V
NC 4 GND
NC 6 1.5V
YES 8 RESERVED
RESERVED
YES 10
RESERVED
YES 12
RESERVED
YES 14
RESERVED
YES 16
NC 18 GND
NC 20 W_DISABLE#
YES 22 PERST#
YES 24 +3.3Vaux
YES 26 GND
YES 28 +1.5V
YES 30 SMB_CLK
YES 32 SMB_DATA
YES 34 GND
YES 36 USB_D-
NC 38 USB_D+
NC 40 GND
NC 42 LED_WWAN#
NC
44 LED_WLAN#
NC 46 LED_WPAN#
NC 48 +1.5V
NC 50 GND
NC 52 +3.3V
8
RTL8192SE
User's Manual
YES
YES
NC
NC
NC
NC
NC
NC
YES
YES
YES
YES
YES
NC
NC
NC
YES
NC
NC
YES
NC
YES
NC
NC
YES
YES
