- Page 1 RTL8192SE 802.11 b/g/n RTL8192SE miniCard User’s Manual Rev. 1.0 21 Apr 2009 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw...
- Page 2 User’s Manual COPYRIGHT ©2009 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp.
-
Page 3: Table Of Contents
Industry Canada Statement……………………………………………………………………………………….12 4.5.3 NCC警語…………………………………………………………………………………………………………13 List of Tables 1. M PCI E ..........................8 ABLE XPRESS SSIGNMENT 2. F ............................9 ABLE UNCTIONAL PECIFICATIONS List of Figures 1. S .........................7 IGURE INGLE PPLICATION IAGRAM 2. RTL8192SE ....................9 IGURE MINI ECHANICAL PECIFICATION Rev.1.0... -
Page 4: General Description
RTL8192SE User’s Manual 1. General Description The Realtek RTL8192SE miniCard is a highly integrated MIMO wireless LAN (WLAN) used for high speed wireless local network access. The card is built with a MAC and 2T2R capable RF/baseband single chip RTL8192SE. -
Page 5: General Features
• MIMO power saving mechanism • Channel management and co-existence • Multiple BSSID feature allowing RTL8192SE to assume multiple MAC identity when used as wireless bridge • Supports Wake-On-WLAN via Magic Packet and wake-up frame • TXOP SIFS bursting guarantees multimedia bandwidth. - Page 6 RTL8192SE User’s Manual PHY Features • IEEE 802.11n draft 2.0 MIMO OFDM 2 transmitter and 2 receivers (2T2R). 20MHz and 40MHz bandwidth transmission. Long Guard Interval (800ns). 1 spatial stream STBC transmission for extended coverage. Sounding packet. • DSSS with DBPSK and DQPSK, CCK modulations with long and short preamble.
-
Page 7: Block Diagram
RTL8192SE User’s Manual 3. Block Diagram Figure 1. Single Band 11n Application Diagram Rev.1.0... -
Page 8: Product Specifications
RTL8192SE User’s Manual 4. Product specifications 4.1. Mini PCI Express Pin Assignment Table 1. Mini PCI Express Pin Assignment PIN# Pin Name PIN# Pin Name WAKE# 3.3V RESERVED RESERVED 1.5V CLKREQ# RESERVED RESERVED RESERVED REFCLK+ RESERVED REFCLK- RESERVED RESERVED RESERVED... -
Page 9: Mechanical
RTL8192SE User’s Manual 4.2. Mechanical Figure 2. RTL8192SE miniCard Mechanical Specification 4.3. Environmental 4.3.1. Operating 0 to 70 °C Operating Temperature: Relative Humidity: 5-90% (non-condensing) 4.3.2. Storage -55 to 125 °C Temperature: Relevant Humidity: 5-95% (non-condensing) 4.4. Functional Specifications Table 2. Functional Specifications DC 3.0~3.6V from host equipment... -
Page 10: Warning
RTL8192SE User’s Manual Transfer rate 802.11b: 11 / 5.5 / 2 / 1Mbps 802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6Mbps Draft 802.11n (20MHz, 800ns GI): 130 / 117 / 104 / 78 / 65 / 58.5 / 52 / 39 / 26 / 19.5 / 13 / 6.5Mbps... - Page 11 This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: “Contains FCC ID: TX2-RTL8192SE”. Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
-
Page 12: Industry Canada Statement
RTL8192SE User’s Manual the EIRP is not more than required for successful communication. IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. -
Page 13: Ncc警語
4.5.3 NCC 警語 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功 率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並 改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電 機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本產品內含射頻模 組：ID編號」 Realtek Semiconductor Corp. Headquarters No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu, 300, Taiwan, R.O.C. Tel: 886-3-5780211 Fax: 886-3-5776047 www.realtek.com.tw Rev.1.0...
