Chapter 4: Web configuration
The page includes the following fields:
Object
Port Select
Priority
Timeout
Buttons
• Click Apply to apply changes.
LACP configuration
LACP LAG negotiates aggregated port links with other LACP ports located on a
different device. LACP allows switches connected to each other to discover
automatically whether any ports are member of the same LAG.
This page allows the user to inspect and change the current LACP port configurations.
The LACP port settings relate to the current device, as reflected by the page header.
74
Description
Select the port number from this drop-down menu to set the LACP
port.
The Priority controls the priority of the port.
If the LACP partner wants to form a larger group than is supported by
this device, then this parameter will control which ports will be active
and which ports will be in a backup role. Lower number means
greater priority.
The Timeout controls the period between BPDU transmissions.
Short transmits LACP packets each second, while
seconds before sending an LACP packet.
Long waits for 30
