Chapter 4: Web configuration
The page includes the following fields:
Object
Port
Type
Chaddr Check
Buttons
• Click Apply to apply changes.
Statistics
The page includes the following fields:
Object
Port
Forwarded
Chaddr Check Dropped
Untrusted Port Dropped
Untrusted Port with Option82
Dropped
Invalid Dropped
160
Description
Select a port from this drop-down menu.
Indicates the DHCP snooping port mode. Possible port modes are:
Trusted: Configures the port as trusted sources of the DHCP message.
Untrusted: Configures the port as untrusted sources of the DHCP message.
Indicates that the Chaddr check function is enabled on selected port.
Chaddr: Client hardware address.
Description
Select a port from this drop-down menu.
The current forwarded packets.
Dropped chaddr checks.
Untrusted ports dropped.
Untrusted ports with option82 dropped.
Invalid dropped packets.
