Smeg range instructions for installation and use
Hide thumbs
Table of Contents

Advertisement

Quick Links

1.
INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________4
2.
INSTALLATION OF THE APPLIANCE_________________________________________6
3.
ADAPTATION TO DIFFERENT TYPES OF GAS ________________________________8
4.
FINAL OPERATIONS_____________________________________________________11
5.
DESCRIPTION OF CONTROLS ____________________________________________13
6.
USE OF THE HOB _______________________________________________________15
7.
USE OF THE OVEN______________________________________________________17
8.
ELECTRONIC PROGRAMMER_____________________________________________19
9.
AVAILABLE ACCESSORIES _______________________________________________21
10. CLEANING AND MAINTENANCE ___________________________________________22
11. EXTRAORDINARY MAINTENANCE _________________________________________24
THESE INSTRUCTIONS ARE VALID ONLY FOR THE END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified technician who must
carry out a suitable check of the gas system, install the appliance, set it functioning and carry
out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands
and the correct procedures for cleaning and maintenance of the appliance.
Contents
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUK90MFX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg SUK90MFX

Summary of Contents for Smeg SUK90MFX

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________4 INSTALLATION OF THE APPLIANCE_________________________________________6 ADAPTATION TO DIFFERENT TYPES OF GAS ________________________________8 FINAL OPERATIONS_____________________________________________________11 DESCRIPTION OF CONTROLS ____________________________________________13 USE OF THE HOB _______________________________________________________15 USE OF THE OVEN______________________________________________________17 ELECTRONIC PROGRAMMER_____________________________________________19 AVAILABLE ACCESSORIES _______________________________________________21 10. CLEANING AND MAINTENANCE ___________________________________________22 11.

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER.
  • Page 3 Introduction DO NOT PUT PANS WITHOUT PERFECTLY SMOOTH AND FLAT BOTTOMS ON THE HOB GRIDS. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN. DO NOT USE CONTAINERS OR BROILERS THAT EXTEND BEYOND THE OUTER PERIMETER OF THE HOB.

  • Page 4: Instructions For The Installer

    Instructions for the installer 2. INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by competent persons. Corgi gas installers are approved to work to safe and satisfactory standards. All gas installation, servicing and repair work must be in accordance with the gas safety regulations 1984 (installation and use) as amended 1990.
  • Page 5 Instructions for the installer ∼ For operation on 220-240 V : use an H05RR-F or H05V2V2-F type three-core cable (3 x 2.5 mm on 90 cm models or 3 x 1.5 on 60 cm models). For operation on 380-415 V 2N H05RR-F or H05V2V2-F type four-core cable (4 x 1.5 mm For operation on 380-415 V 3N H05RR-F or H05V2V2-F type five-core cable (5 x 1.5 mm...

  • Page 6: Adaptation To Different Types Of Gas

    Instructions for the installer 3. ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, disconnect the appliance from the mains. The cooker hob is preset for natural gas G20 (2H) at a pressure of 20 mbar. In the case of operation with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.

  • Page 7: Burner And Nozzle Characteristics Table

    Instructions for the installer 3.2 Burner and nozzle characteristics table Rated Burner heating capacity (kW) Auxiliary Semi rapid 1.75 Rapid Triple crown Oven Maxi oven Grill Rated Burner heating capacity (kW) Auxiliary Semi rapid 1.75 Rapid Triple crown Oven Maxi oven 3.3 Arrangement of the burners on the hob LPG –...
  • Page 8 Instructions for the installer 3.4 Burner and nozzle characteristics table (Mod. 60 cm.) Portata termica Bruciatore nominale (kW) Auxiliary S Semi rapid 1.75 Rapid Triple crown Oven Grill Portata termica Bruciatore nominale (kW) Auxiliary Semi rapid 1.75 Rapid Triple crown Oven Grill Arrangement of the burners on the hob (Mod.

  • Page 9: Final Operations

    Instructions for the installer 4. FINAL OPERATIONS After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids. Following adjustment to a gas other than the preset one, replace the gas adjustment label fixed to the appliance with the one corresponding to the new gas. This label is in the packet together with the nozzles.
  • Page 10 Instructions for the installer 4.4 Wall fixing • Stretch out the chain attached to the cooker horizontally so that the other end touches the wall. • Mark the wall in the position where the hole is to be drilled. • Drill the hole, insert a wall plug and attach the chain.

  • Page 11: Front Control Panel

    Instructions for the user 5. DESCRIPTION OF CONTROLS 5.1 Front control panel All the cooker controls and commands are on the front panel. If the cooker is equipped with an electronic programmer, before using the oven make sure that the symbol ;...
  • Page 12 ELECTRIC OVEN CONTROL KNOB Each of the functions listed below can be used (except the oven light and the small grill) only together with the correct temperature thermostat regulation as described on page 13 of this manual. OVEN LIGHT UPPER AND LOWER HEATING ELEMENT GRILL ELEMENT Instructions for the user...

  • Page 13: Use Of The Hob

    Instructions for the user 6. USE OF THE HOB 6.1 Lighting of the hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.
  • Page 14 6.3 Diameter of the vessels to be used on each burner BURNERS Auxiliary Semi rapid Rapid Triple crown Instructions for the user Ø min. and max. (in cm) 12-14 16-24 18-26 18-26...

  • Page 15: Use Of The Oven

    Instructions for the user 7. USE OF THE OVEN For the models with electronic programmer, before using the oven make sure that the display shows the symbol 7.1 Warnings and general advice Using the oven and the grill for the first time, heat them to the maximum temperature (260°C) for as long as it takes to burn off any production oil residues which could give a nasty flavour to the food.

  • Page 16: Rotisserie In Cookers With Maxi Oven

    7.3.2 Using the rotisserie in cookers with maxi oven Fit the supporting frame onto the second runner up from the bottom so that the seat to take the rod projects outside the oven. Place the rod as shown in the diagram (1) and push the frame into the oven until the end of the rod reaches the hole in the rotisserie motor.

  • Page 17: Electronic Programmer

    Instructions for the user 8. ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 8.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates .
  • Page 18 Instructions for the user 8.4 End of cooking When cooking is over, the oven will automatically switch off and, at the same time, an intermittent alarm will sound. After switching off the alarm, the display will once again show the right time together with the symbol , indicating that the oven has returned to manual operation mode.

  • Page 19: Available Accessories

    Instructions for the user 9. AVAILABLE ACCESSORIES The oven has 4 support for positioning plates and racks at various heights. Oven grill: for cooking food on plates, small cakes, roasts or food requiring light grilling. Plate grill: for placing above plate for cooking foods that might drip.

  • Page 20: Cleaning And Maintenance

    10. CLEANING AND MAINTENANCE 10.1 Cleaning stainless steel and enamelled versions To maintain stainless steel in good condition clean it regularly after each use, once it has cooled down. 10.1.1 Ordinary daily cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids.
  • Page 21 Instructions for the user 10.2.4 The burners The burners can be left to soak in hot water and detergent. 10.3 Cleaning of oven For best oven upkeep clean regularly after having allowed to cool. Take out all removable parts. • Clean the oven grill with hot water and non-abrasive detergent.

  • Page 22: Extraordinary Maintenance

    11. EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 11.1 Replacement of light bulb Remove cover A by twisting anticlockwise, replace bulb B with another similar bulb (25 W).
