TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 7
5
2
If attaching to a frame please go to stage 7
En cas de fixation sur un cadre existant, veuillez vous référer à l'étape 7.
Se si fissa l'unità ad un telaio, passare al punto 7.
Si lo sujeta a un armazón, vaya a la fase 7.
Bei nbringung an einem Rahmen bitte jetzt Punkt 7 beachten.
PM 7381
x 1
MT 0239
FA 7244
PM 7623
40mm
2
2
Note orientation of the block
Prenez note de l'orientation de l'entretoise
Observar la orientación del bloque
Notare l'orientamento del blocco
Bitte usrichtung des Blocks beachten
7
2
