TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 1
TP755 Rapide Slide &
TP769 Rapide Stepset
INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE
PLE SE RET IN FOR FUTURE REFERENCE.
Important!
These instructions must be followed for safe assembly and use. Please retain for future reference.
Important!
Vous devez suivre ces instructions pour que le montage et l'utilisation se fassent en toute sécurité.
Veuillez conserver pour référence ultérieure.
Importante!
Per garantire sicurezza di montaggio ed uso, seguire queste istruzioni e conservarle per futuro riferimento.
Importante!
Debe seguirse estas instrucciones para un armado y uso seguros. Sírvase conservarlas para consultarlas en el futuro.
Wichtig!
Diese nweisung ist für sicheren ufbau und Gebrauch zu befolgen. Für künftigen Gebrauch aufbewahren.
Importante!
Para assegurar uma montagem e uma utilização seguras, têm de ser seguidas estas instruções. Guardar para referência futura.
WARNING!
TOY MUST BE SSEMBLED BY N DULT BEFORE USE.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INST LLED.
REMOVE LL P CK GING BEFORE GIVING TO YOUR CHILDREN.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE. DULT SUPERVISION IS REQUIRED.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM GES 3 TO 14 YE RS.
M XIMUM COMBINED USER WEIGHT 100KGS
Build
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TP Toys Active Fun Rapide Slide
Summary of Contents for TP Toys Active Fun Rapide Slide
- Page 1 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 1 TP755 Rapide Slide & TP769 Rapide Stepset INSTRUCTIONS FOR ASSEMBLY MAINTENANCE AND USE PLE SE RET IN FOR FUTURE REFERENCE. Important! These instructions must be followed for safe assembly and use. Please retain for future reference. Important! Vous devez suivre ces instructions pour que le montage et l’utilisation se fassent en toute sécurité.
- Page 2 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 2 INSTRUCTIONS CONCERNANT L’ASSEMBLAGE, L’ENTRETIEN ET L’UTILISATION DE MATÉRIEL TP Veuillez lire attentivement les instructions suivantes et les conserver à des fins de référence future. 1. ASSEMBLAGE ET SÉCURITÉ L’assemblage des équipements/jouets TP doit être uniquement effectué...
- Page 3 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 3 INSTRUCCIONES DE MONTAJE, MANTENIMIENTO Y USO DE LOS JUGUETES TP Lea detenidamente toda la información adjunta y consérvela para futuras consultas. 1. INFORMACIÓN SOBRE MONTAJE Y SEGURIDAD Los juguetes TP deben ser montados por un adulto.
- Page 4 3. USAGE TP toys are designed and made for use only by children aged between 3 and 14 years, unless otherwise stated, and must not be used by anybody else. Misuse can result in injury. Warning only for Domestic use. For outdoor use only.
- Page 5 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 5 Contents - Please check Bolt Tightening Guide Contenu - Veuillez vérifier ✘ Siete pregati di controllare il contenuto ✘ Verifique el contenido Inhalt - Bitte Überprüfen TP SLIDE BODY 754/755 MT 0239 PV 8447 (green) FA 8581...
- Page 6 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 6 Preparation FA 7111 FA 7624 MT 0060 Préparation Preparazione Preparación Vorbereitung Note orientation Prenez note de l'orientation Observar la orientación Notare l'orientamento Bitte usrichtung Assembly PV 8447 (green) Montage MT 0059...
- Page 7 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 7 PM 7381 FA 7244 PM 7623 40mm MT 0239 Note orientation of the block Prenez note de l'orientation de l'entretoise Observar la orientación del bloque Notare l'orientamento del blocco Bitte usrichtung des Blocks beachten If attaching to a frame please go to stage 7 En cas de fixation sur un cadre existant, veuillez vous référer à...
- Page 8 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 8 Fitting to TP Step set FA 5175 FA 7253 35mm Installation sun un série d’étape Montaggio all’camminare la serie MT 0388 Fijación en un paso el conjunto Montage am Tritten Stellen Please note hole s'il vous plaît noter le trou...
- Page 9 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 9 Stepset FA 5172 PM 7616 Série d’étape Camminare la serie El paso conjunto Tritten Stellen Assembly Montage MT 0242 Montaggio PM 7378 32mm Montaje Montage Rapide Slide...
- Page 10 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 10 FA 7245 55mm PM 7616 pply lubrication (e.g. washing up liquid) in the bores of the steps to ease assembly. Enduisez les trous des marches de lubrifiant (liquide à laver la vaisselle, par exemple) pour faciliter le montage.
- Page 11 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 11 7559 7111 25mm ✘ ✘ MT 0240 FA 5192 FA 7253 FA 7254 35mm 45mm 45mm 45mm 35mm 35mm Rapide Slide...
- Page 12 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 12 FA 5175 PM 7381 PM 7623 FA 7255 60mm Note orientation of the block Prenez note de l'orientation de l'entretoise Observar la orientación del bloque Notare l'orientamento del blocco Bitte usrichtung des Blocks beachten Line all holes up lignez tous les trous...
- Page 13 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 13 Fitting to TP Climbing Frames Installation sur un cadre d’escalade PR 7380 Montaggio all’intelaiatura per arrampicarsi Fijación en una estructura para trepar FA 5175 FA 7381 FA 7255 PM 7623 Montage am Kletterrahmen 60mm...
- Page 14 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 14 Attachment Locations Explorer Low height Hauteur basse ltezza bassa ltura baja Tief Höhe Full height Hauteur pleine ltezza pieni ltura repleta Volle Höhe For attachment to a wooden frame see frame, or attachment kit instructions. Pour fixation sur un support en bois, veuillez vous référer à...
- Page 15 TP755-769 Rapide IN8286-E 07 15.qxp_TP755-769 Rapide IN8286-E 07 15 09/07/2015 15:54 Page 15 Rapide Slide Body off a frame Rapide Slide Rapide Slide Rapide Slide Body and Stepset Recommended safe play area: The Safe Play rea refers to the zone extending 2m beyond the play set on all sides, including the space above the apparatus. dditional accessories may increase the size of the Safe Play rea.
- Page 16 We want to give you the very best service. By registering your purchase now, we will be able to deal with any guarantee issues very quickly and efficiently in the future. Thank you. Your TP Guarantee Number/Product Batch No is Designed in the UK by Robovision Ltd t/as TP Toys Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX. www.tptoys.com...
