TP415P
Children's Wooden Playhouse
Instructions for assembly, maintenance and safe use.
We constantly strive to improve our assembly instructions. To see the most current version of this instruction
for assembly, maintenance and safe use. Please visit the product page at tptoys.com
WARNING!
THIS PRODUCT IS NOT SUITABLE FOR CHILDREN UNDER
36 MONTHS.
CONTAINS SMALL PARTS. CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
ADULT SUPERVISION IS REQUIRED.
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL
PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR
CHILDREN.
TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 1
TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 1
2 Hrs
x1
Build Time
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
IMPORTANT
INFORMATION
A suitable wood stain
or preservative must be
applied before use.
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST
BE FITTED BEFORE USE.
PLEASE RETAIN INSTRUCTIONS AS IT CONTAINS
IMPORTANT SAFETY INFORMATION.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM
AGES 3 YEARS +.
PLAYHOUSE COMBINED USER WEIGHT: 150KGS
SLIDE MAX COMBINED USER WEIGHT: 50KGS
14/05/2020 14:58
14/05/2020 14:58

Advertisement

loading
Need help?

Need help?

Do you have a question about the TP415P and is the answer not in the manual?

Questions and answers

Related Manuals for TP Toys TP415P

Summary of Contents for TP Toys TP415P

  • Page 1 REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN. 2 Hrs Build Time Robovision Ltd t/a TP Toys Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England www.tptoys.com TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 1 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 1...
  • Page 2 Important advice for assembly, maintenance and safe use. Please retain this information for future reference. Toys must be assembled by an adult before use exactly in accordance with the instructions. Check all parts are present before you start to assemble the product. Place small parts on a tray or similar, to ensure they are not lost.
  • Page 3 IMPORTANT WARNING This product is made with untreated wood. A suitable wood stain or preservative must be applied before use. This treatment will protect against wood rot and warping but does not guarantee the product will be 100% waterproof. The tongue and groove construction of this product means there may be small gaps that change slightly due to atmospheric conditions.
  • Page 4 Also required: Tools - You will need: Screwdriver Tape Measure Pozi #2 #3 Pozi #2 #3 Screwdriver Tape Measure Combi Drill 2mm 3mm Combi Drill 2mm 3mm Not Supplied Shovel Spirit Level Sandpaper Not Supplied Shovel Spirit Level Sandpaper Wood Treatment Not Supplied Pack 1...
  • Page 5 Pack 2 MW2438 1755mm MW2439 814mm MW2441 1069mm MW2443 294mm MW2446 455mm MW2447 340mm MW2448 915mm MW2457 160mm MW2449 1300mm MW2451 996mm MW2452 414mm MW2459 795mm MW2460 1135mm Subpack - SP3030 Pack 3 3 x 25mm FA4530 FB9985 x131 3 x 40mm FA4540 PM9751 4 x 45mm...
  • Page 6 MW2438 1755mm 3 x 40mm MW2439 814mm FA4540 MW2440 902mm 5 x 100mm FA9761 90° 90° 850mm 850mm 850mm 90° TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 6 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 6 14/05/2020 14:58 14/05/2020 14:58...
  • Page 7 MW2441 1069mm 5 x 100mm FA9761 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 7 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 7 14/05/2020 14:58 14/05/2020 14:58...
  • Page 8 MW2442 1159mm 3 x 40mm FA4540 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 8 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 8 14/05/2020 14:58 14/05/2020 14:58...
  • Page 9 MW2439 814mm 5 x 100mm FA9761 MW2443 294mm 4 x 45mm FA4539 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 9 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 9 14/05/2020 14:58 14/05/2020 14:58...
  • Page 10 MW2444 1159mm 3 x 40mm FA4540 MW2445 1159mm MW2444 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2445 MW2444 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 10 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 10 14/05/2020 14:58 14/05/2020 14:58...
  • Page 11 MW2446 455mm MW2447 340mm 4 x 45mm FA4539 MW2446 MW2447 MW2446 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 11 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 11 14/05/2020 14:58 14/05/2020 14:58...
  • Page 12 MW2449 1300mm MW2448 915mm 4 x 45mm FA4539 MW2449 MW2449 MW2448 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 12 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 12 14/05/2020 14:58 14/05/2020 14:58...
  • Page 13 MW2451 996mm 4 x 45mm FA4539 MW2452 414mm 160mm 250mm 250mm 4 x 45mm FA4539 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 13 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 13 14/05/2020 14:58 14/05/2020 14:58...
  • Page 14 MW2440 902mm 3 x 40mm FA4540 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 14 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 14 14/05/2020 14:58 14/05/2020 14:58...
  • Page 15 3 x 40mm MW2453 530mm FA4540 90° TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 15 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 15 14/05/2020 14:58 14/05/2020 14:58...
  • Page 16 3 x 40mm MW2453 530mm FA4540 MW2456 1172mm ASSEMBLY TIP Slide position option Board MW2456 or MW2455 will need to be cut during Stage 20. 90° TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 16 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 16 14/05/2020 14:58 14/05/2020 14:58...
  • Page 17 3 x 40mm MW2454 428mm FA4540 MW2455 928mm ASSEMBLY TIP Slide position option Board MW2456 or MW2455 will need to be cut during Stage 20. TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 17 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 17 14/05/2020 14:58 14/05/2020 14:58...
  • Page 18 MW2459 795mm MW2457 160mm 3 x 40mm FA4540 MW2460 1135mm MW2459 MW2459 MW2460 MW2460 IMPORTANT ASSEMBLY TIP ø Drill 3mm Locating hole Approx 25mm 22.5mm TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 18 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 18 14/05/2020 14:58 14/05/2020 14:58...
  • Page 19 4 x 45mm FA4539 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 19 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 19 14/05/2020 14:58 14/05/2020 14:58...
  • Page 20 MW2458 966mm 3 x 25mm FA4530 TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 20 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 20 14/05/2020 14:58 14/05/2020 14:58...
  • Page 21 MW2458 966mm 3 x 25mm FA4530 ø TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 21 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 21 14/05/2020 14:58 14/05/2020 14:58...
  • Page 22 4 x 45mm 3 x 40mm FA4539 FA4540 PM9751 Select your preferred Select your preferred Slide position Slide position 4 x 45mm 3 x 40mm TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 22 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 22 14/05/2020 14:58 14/05/2020 14:58...
  • Page 23 4 x 45mm PM2001 FA4539 300mm 300mm 300mm Ensure the stakes are positioned into the setting Post-Mix concrete. Warning: Never set the base of the Supplied. playset in concrete. FB9985 Sand not supplied TP Children’s Wooden Playhouse TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 23 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 23 14/05/2020 14:58 14/05/2020 14:58...
  • Page 24 Thank you Thank you for purchasing this product. Please register your new product on line at tptoys.com www.tptoys.com/customer/productregistration Find out about the guarantee for this product, visit www.tptoys.com/customer/pages/guaranteeinformation For customer services and help with your product, visit www.tptoys.com/customer/help Your TP Guarantee Number/Product Batch No is TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 24 TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 24 14/05/2020 14:58...
