TP164

Pirate Galleon

Instructions for assembly, maintenance and safe use.

Please retain for future reference.

WARNINGS!

THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT

SUITABLE FOR CHILDREN UNDER 36 MONTHS.

SMALL PARTS ARE A CHOKING HAZARD.

THIS PRODUCT IS INTENDED FOR USE BY CHILDREN AGED

3-10 YEARS.

ONLY FOR DOMESTIC USE. FOR OUTDOOR USE ONLY.

TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.

CHILDREN MUST NOT USE THIS PRODUCT UNTIL PROPERLY

INSTALLED. ADULT SUPERVISION REQUIRED.

Draft_2

Hrs

Build Time

Robovision Ltd t/a TP Toys

Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England

www.tptoys.com

REMOVE ALL PACKAGING BEFORE GIVING TO YOUR

CHILDREN.

RETAIN PACKAGING FOR FUTURE REFERENCE.

ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST

BE FITTED BEFORE USE.

WARNING: MAXIMUM COMBINED USER WEIGHT 150KGS

Need help?

Do you have a question about the active fun Pirate Galleon and is the answer not in the manual?

Questions and answers

Summary of Contents for TP Toys active fun Pirate Galleon

Page 1 WARNING: MAXIMUM COMBINED USER WEIGHT 150KGS TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE. CHILDREN MUST NOT USE THIS PRODUCT UNTIL PROPERLY INSTALLED. ADULT SUPERVISION REQUIRED. Build Time Robovision Ltd t/a TP Toys Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England www.tptoys.com...
Page 2 Important advice for assembly, maintenance and safe use Toy must be assembled by an adult before use exactly in accordance with the instructions. Children must not use this product until properly installed. Check all parts are present before you start to assemble the product. Place small parts on a tray or similar to ensure they are not lost.
Page 3 272cm Height to front platform: 68cm Height to rear platform: 88cm Height to rear guardrail: 140cm Maxiumum height of this set: 206cm Know About Wood Unlike steel, wood is a natural, organic material and each piece will be unique, bearing its own knots, cracks and variations in colour and, unlike steel, wood will react significantly to changes in atmospheric conditions.
Page 4 Also Required: Tools - You will need: Post mix concrete Béton Beton Hormigón 10mm Calcestruzzo Concreto Supplied Contents - Please check Pack - 1 MW2406 MW2410 MW2420 MW2424 MW2423 MW2425 MW2416 MW2413 245mm 193mm 264mm 288mm 285mm 146mm 350mm 511mm MW2399 MW2402 MW2414...
Page 5 Pack - 2 SP3010 MW2403 MW2418 MW2404 MW2407 MW2415 1240mm 994mm FB3033 FB3035 994mm 1000mm 644mm Half Main Sail Spinika Sail FA8414 FA6396 FA7381 PM0072 PM2085 PM2086 Cabin Window Anchor Window FA8441 PM0071 PM0070 PM2001 MW2400 MW2421 MW2422 MW2426 MW2408 MW2409 Ground Peg 1397mm...
Page 6 MW2400 MW2404 FA9767 5x40mm MW2403 FA9768 5x60mm Pirate Galleon...
Page 7 MW2400 MW2407 FA9768 1397mm 1000mm 5x60mm MW2414 FA9767 5x40mm Assembly Tip Fix end boards first Space boards evenly Pirate Galleon...
Page 8 MW2403 MW2408 FA9767 5x40mm MW2409 FA9767 5x40mm Pirate Galleon...
Page 9 MW2421 MW2411 FA9784 6x150mm Drill pilot hole x4 MW2421 MW2421 MW2411 MW2411 Pirate Galleon...
Page 10 MW2415 MW2412 MW2416 FA9784 FA9768 FA9767 6x150mm 5x60mm 5x40mm 5x60mm 6x150mm MW2415 5x40mm 5x40mm MW2416 5x60mm MW2412 Pirate Galleon...
Page 11 MW2407 FA9767 5x40mm MW2405 FA9767 5x40mm Pirate Galleon...
Page 12 MW2413 FA9767 5x40mm MW2413 FA9767 5x40mm Pirate Galleon...
Page 13 MW2418 MW2425 MW2426 FA9767 5x40mm Pirate Galleon...
Page 14 MW2401 2000mm FA9767 5x40mm MW2401 2000mm FA9767 5x40mm Pirate Galleon...
Page 15 MW2399 MW2410 FA9767 5x40mm Assembly Tip MW2399 Cabin Equal Window spacing MW2399 MW2399 Fix MW2399 boards first. Space MW2410 boards with Use window for spacing. equal gaps. Use window for spacing. Pirate Galleon...
Page 16 PM2085 FA8274 Cabin Window 5x15mm Pirate Galleon...
Page 17 MW2399 MW2410 FA9767 5x40mm Assembly Tip MW2399 Cabin MW2410 Equal Window spacing MW2410 MW2399 MW2399 Fix MW2399 boards first. Space MW 2410 boards with Use window for spacing. equal gaps. Use window for spacing. Pirate Galleon...
Page 18 PM2085 FA8274 Cabin Window 5x15mm Pirate Galleon...
Page 19 FA9767 MW2399 MW2406 MW2402 5x40mm Assembly Tip MW2402 MW2399 Equal Anchor spacing MW2406 MW2406 Window MW2399 MW2399 Fix MW2399 boards first. Space MW2406 boards Use window for spacing. with equal gaps. Use window for spacing. PM2086 Anchor Window FA8274 5x15mm Pirate Galleon...
Page 20 MW2399 MW2402 MW2406 FA9767 5x40mm Assembly Tip MW2402 MW2399 Equal Anchor spacing MW2406 MW2406 Window MW2399 MW2399 Fix MW2399 boards first. Space MW2406 boards Use window for spacing. with equal gaps. Use window for spacing. PM2086 FA8274 Anchor Window 5x15mm Pirate Galleon...
Page 21 MW2427 MW2428 MW2429 MW2430 MW2431 FA9767 5x40mm Assembly Tip Fit the 2 ends boards first. Fit rest of boards now with Use rest of boards for equal spacing between boards. spacing. Pirate Galleon...
Page 22 MW2419 MW2420 FA9767 5x40mm MW2419 MW2420 FA9767 5x40mm MW2423 FA4521 5x80mm Pirate Galleon...
Page 23 MW2422 MW2424 FA9767 5x40mm FA9767 5x40mm MW2417 FA9768 FB3033 5x60mm Half Main Sail Pirate Galleon...
Page 24 FB3035 Spinika Sail FA8414 FA7381 FA8441 PM0071 PM0072 FA6396 PM0070 Pirate Galleon...
Page 25 FA9768 PM2001 5x60mm Ground Peg TP164 Mark base/ staking position then move Pirate Galleon. Locate position of Pirate Galleon Dig holes: with Safe Play area around. 300mm x 300mm x 300mm deep. Date 08 17 Supplied. Fill holes with Post-Mix concrete.
Page 26 Pirate Galleon...
Page 27 Pirate Galleon...
Page 28 Thank you Thank you for purchasing this product. Please register your new product on line at tptoys.com www.tptoys.com/customer/productregistration Find out about the guarantee for this product, visit www.tptoys.com/customer/pages/guaranteeinformation For customer services and help with your product, visit www.tptoys.com/customer/help Your TP Guarantee Number/Product Batch No is...
