Owner's Operation and Instruction Manual
Masonry Fireplace Insert or Zero-Clearance (metal) Fireplace Insert
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY NOTICE:
If this heater is not properly installed, a house fire
may result. For your safety, follow the installation
instructions. Contact local building or fire officials
about restrictions and installation in your area.
CAUTION!
Please read this entire manual before you
install and use your new heater. Failure to
follow instructions may result in property
damage, bodily injury, or even death.
MODEL: TR004
Fireplace Insert
SAVE THESE INSTRUCTIONS
U.S. STOVE
227 Industrial Park Road
South Pittsburg, TN 37380, USA
1-800-750-2723
Certified to: UL1482 and Certified to: ULC S628
DO NOT use this appliance in a mobile
home, manufactured home, trailer, or tent.
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate
emissions standards.
852137E-1203H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR004 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vogelzang International TR004

Summary of Contents for Vogelzang International TR004

  • Page 1 Owner’s Operation and Instruction Manual MODEL: TR004 Fireplace Insert Masonry Fireplace Insert or Zero-Clearance (metal) Fireplace Insert SAVE THESE INSTRUCTIONS THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.

  • Page 2: Safety Instructions

    The instructions pertaining to the installation of your wood stove comply with UL-1482 and ULC-S628 standards. This manual describes the installation and operation of the Vogelzang, TR004 wood heater. This heater meets the 2015 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters sold after May 15, 2015. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 11,805 to 27,252 Btu/hr.
  • Page 3 22. DO NOT ROUTE THE blower power SUPPLY CORD 26. U.S. Stove Company requires installing smoke NEAR OR ACROSS HOT SURFACES! detectors in the same room as the heater if not 23. Canada Installations requires that this fireplace already installed. Smoke expelled from the unit by must be installed with a continuous chimney liner either paint curing, opening the fuel loading door, of 6 inch diameter extending from the fireplace...

  • Page 4: Pre-Installation Requirements

    Pre-Installation Requirements FIREPLACE CONDITION AND ZERO CLEARANCE REQUIREMENTS A masonry fireplace must meet minimum code requirements, National Fire Protection Association, (NFPA) 211, or the equivalent for a safe installation. Contact a professional, licensed installer, your local building inspector or the local fire authority for the requirements in your area. Your insurance company should be able to recommend a qualified inspector.
  • Page 5 a. Existing fuel-fired equipment shows evidence of back puffing, smoke roll-out, inefficient operation, or excessive smell in the living area. b. Opening a window or door alleviates any of the above problems or symptoms. c. The building is constructed with a well-sealed vapor barrier, tight fitting windows, or has powered exhaust fans.

  • Page 6: Tools And Materials Required For Installation

    Assembly Instructions TOOLS AND MATERIALS REQUIRED FOR INSTALLATION (NOTE: The following items are NOT included with your stove.) • Pencil • Chimney Liner: Continuous stainless steel chimney • 6 foot Folding Ruler or Measuring Tape liner (as required) • Tin Snips •...
  • Page 7 11. Assemble the trim frame. The trim consists of a left (6) and right (5) side piece and a split top piece (left #8, right #7). These are joined by corner connectors (11-13) and two straight center connectors (9-10). These slide into the channel on the back of the frame and are secured with two set screws (13) in each piece.

  • Page 8: Chimney Specifications

    Chimney Specifications This appliance must be connected to a listed Stainless Steel Liner, that meets UL1777, which extends from the collar to the chimney cap according to the specifications listed on the previous pages. Take into account the chimney’s location to insure it is not too close to neighbors or in a valley which may cause unhealthy or nuisance conditions.

  • Page 9: Fuel Recommendations

    Fuel Recommendations WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others.

  • Page 10: Operating Safety Precautions

    Operating Instructions CAUTIONS: HOUSE FIRE HAZARDS • Do not store wood on floor protector, underneath stovepipe(s) if applicable, or anywhere within clearances to combustible surfaces specified for this appliance. • Never operate with secondary tubes, fiber board, or insulation removed. OPERATING SAFETY PRECAUTIONS •...

  • Page 11: Optimal Fuel Consumption

    Do not burn manufactured logs made of wax impregnated sawdust or logs with any chemical additives. Manufactured logs made of 100% compressed sawdust can be burned, but be careful burning too much of these logs at the same time. Start with one manufactured log and see how the stove reacts.

  • Page 12: Starting A Fire

    NOTICE - INITIAL BURNS TO CURE PAINT BECAUSE OF THE HIGH OPERATING TEMPERATURES, THIS APPLIANCE IS COATED WITH A SPECIAL HIGH TEMP PAINT WHICH REQUIRES A SERIES OF LOW TO MEDIUM BURNS TO FULLY CURE FOR DURABILITY AND A LIFETIME OF SERVICE. Proper curing of the high-temp paint requires a series of three initial burns.

  • Page 13: Chimney Maintenance

    AIR TUBES The air tubes assembled in this unit are designed to provide an accurate mix of secondary air to insure the highest efficiency. Any damage or deterioration of these tubes may reduce the efficiency of combustion. The air tubes are held in position by either screws or snap pins. Locate these to either side of the tube and remove to allow the tube to be removed and replaced.

  • Page 14: Chimney Draft

    CHIMNEY DRAFT NOTE: A DRAFT READING OF 0.05[12.45] to 0.06[14.94] (Water Column[Pascals]) IS REQUIRED FOR PROPER BURNING OF THIS APPLIANCE. Draft is a function of the chimney, NOT THE APPLIANCE — Do not expect the appliance to draw. Smoke spillage into the house or excess buildup of condensation or creosote in the chimney are warnings that the chimney is NOT functioning properly.

  • Page 15: Service Hints

    Service Hints ASH REMOVAL AND DISPOSAL Whenever ashes get 3 to 4 inches deep in your firebox or ash pan, and when the fire has burned down and cooled, remove excess ashes. Leave an ash bed approximately 1 inch deep on the firebox bottom to help maintain a hot charcoal bed.

  • Page 16: Floor Protector

    REMOVING THE INSERT FOR PURPOSE OF INSPECTION If for any reason you must remove the insert for inspection of the appliance or fireplace, follow these rules. 1. Ensure appliance is not in operation and is thoroughly cooled. 2. Remove the surround by removing the springs retaining it to the appliance. 3.

  • Page 17: Repair Parts

    Repair Parts Part No. Description Qty. Part No. Description Qty. 69660 Complete Door Assembly 891990 Retainer, Tube 88066 5/8” Rope Gasket 6 ft. 88158 Fiber Board, Front 891813 Door Glass 88159 Fiber Board, Rear Gasket-Flat, Glass (3/16T x 88160 Fiber Blanket 88174 6 ft.

  • Page 18: Limitations Of Liability

    Limited Warranty The operation of this unit in a manner inconsistent with the owner’s manual instructions; (7) installation or use of components not supplied with appliance will void the warranty and is also against federal regulations. United States or any other components not expressly authorized and approved by USSC; (8) Stove Company warrants this product to be free from defects in material and modification of the appliance not expressly authorized and approved by USSC workmanship, to the original retail purchaser only, for the time period identified...

  • Page 19: Service Record

    Service Record Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider: Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.

  • Page 20: How To Order Repair Parts

    How To Order Repair Parts / Comment Commander Les Pièces De Rechange This manual will help you obtain efficient, dependable service from your heater, and enable you to order repair parts correctly. Keep this manual in a safe place for future reference. When writing, always give the full model number which is on the nameplate attached to the heater.
