Owner's Operation and Instruction Manual

DO NOT use this appliance in a mobile home, manufactured home, trailer, or tent.

Please read this entire manual before you install and use your new heater. Failure to follow instruc-

tions may result in property damage, bodily injury, or even death.

SAFETY NOTICE:

If this heater is not properly installed, a house ﬁ re may result. For your safety, follow the installation

instructions. Contact local building or ﬁ re ofﬁ cials about restrictions and installation in your area.

THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO

ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.

French version is available for download from the U. S. Stove website: http://www.usstove.com/

Version française est disponible pour téléchargement à partir du site Web de la Poêle US: http://www.usstove.com

MODEL: TR004

Fireplace Insert

Masonry Fireplace Insert or Zero-Clearance (metal) Fireplace Insert

SAFETY TESTED TO UL 1482-2010

WASHINGTON STATE APPROVED

U.S. Environmental Protection Agency

Certiﬁed to comply with 2015 particulate emissions standards.

SAVE THESE INSTRUCTIONS

227 Industrial Park Road

South Pittsburg, TN 37380, USA

CAUTION!

U.S. STOVE

P.O. Box 151

1-800-750-2723

852137C-1904E

Table of Contents

Need help?

Do you have a question about the TR004 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vogelzang International TR004

Page 1 Owner’s Operation and Instruction Manual MODEL: TR004 Fireplace Insert Masonry Fireplace Insert or Zero-Clearance (metal) Fireplace Insert SAFETY TESTED TO UL 1482-2010 WASHINGTON STATE APPROVED U.S. Environmental Protection Agency Certiﬁed to comply with 2015 particulate emissions standards. DO NOT use this appliance in a mobile home, manufactured home, trailer, or tent.
Page 2: Safety Instructions
The instructions pertaining to the installation of your wood stove comply with UL-1482 and ULC-S628 standards. This manualde- scribes the installation and operation of the Vogelzang, TR004 wood heater. This heater meets the 2015 U.S. Environmental Protec- tion Agency’s crib wood emission limits for wood heaters sold after May 15, 2015. Under speciﬁ c test conditions this heater has been shown to deliver heat at rates ranging from 11,805 to 27,252 Btu/hr.
Page 3 TR004 DIMENSIONS 27 1/32 [686.6 mm] 26 11/32 [669.0 mm] 13 5/32 [334.5 mm] 44 7/32 [1123.0 mm] 6.00 INSIDE 22 1/4 [565.0 mm] 21 13/16 [554.0 mm] 4 11/16 [118.8 mm] 15 1/2 [394.0 mm]...
Page 4: Pre-Installation Requirements
PRE-INSTALLATION REQUIREMENTS 6. Fireplace Opening Dimensions. FIREPLACE CONDITION AND A. Minimum Width ....... 29˝ [737mm] ZERO CLEARANCE REQUIREMENTS B. Minimum Height ......23˝ [584mm] A masonry ﬁ replace must meet minimum code require- ments, National Fire Protection Association, (NFPA) 211, C.
Page 5: Floor Protector
PRE-INSTALLATION REQUIREMENTS a. Existing fuel-ﬁ red equipment shows evidence of The chimney must also meet minimum and maximum back pufﬁ ng, smoke roll-out, inefﬁ cient operation, cross sectional requirements. For that reason a continu- or excessive smell in the living area. ous 6˝...
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS TOOLS AND MATERIALS REQUIRED FOR INSTALLATION TOOLS MATERIALS • Pencil (NOTE: The following items are NOT included with your stove.) Flooring Protection: as speciﬁ ed herein. • 6 foot Folding Ruler or Measuring Tape Chimney Liner: Continuous stainless steel chimney liner (as •...
Page 7 ASSEMBLY INSTRUCTIONS 11. Bolt the top panel (1) to the side panels (2 and 14) so 15. The surround assembly is held in place with two the top surfaces are ﬂ ush to one another using items springs at the top of either corner of the appliance 3 and 4.
Page 8: Chimney Specifications
CHIMNEY SPECIFICATIONS This appliance must be connected to a listed Stainless mance. (Gauges to measure draft are readily available at Steel Liner, that meets UL1777, which extends from the stove stores and are economical to rent or purchase.) collar to the chimney cap according to the speciﬁ cations Factors such as wind, barometric pressure, trees, terrain listed on the previous pages.
Page 9: Fuel Recommendations
FUEL RECOMMENDATIONS WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other ﬂ am- mable materials should not be burned in your stove. Any type of wood may be used in your stove, but speciﬁ c varieties have better energy yields than others.
Page 10: Operating Instructions
OPERATING INSTRUCTIONS This appliance is designed to burn CAUTIONS: HOUSE FIRE HAZARDS Natural WOOD FUEL ONLY! • DO NOT STORE WOOD ON FLOOR PROTECTOR, Hardwood, 17” to 19”, should be split and air dried (seasoned) UNDERNEATH STOVEPIPE(S) IF APPLICABLE, for 6 months to obtain maximum burning efﬁ ciency. Wood OR ANYWHERE WITHIN CLEARANCES TO should be stored in a dry, well ventilated area.
Page 11 OPTIMAL FUEL CONSUMPTION TAMPER WARNING This appliance is designed to get the most efﬁ cient transfer of This wood heater has a manufacturer-set minimum low burn heat energy from the wood fuel and radiate it into your living rate that must not be altered. It is against federal regulations environment.
Page 12: Starting A Fire
OPERATING INSTRUCTIONS STARTING A FIRE ing causing smoke and ﬂ ame spillage. 2. Add fuel being careful not to overload or overﬁ re the appliance. DO NOT LEAVE APPLIANCE UNATTENDED WITH DOOR OPEN! The top down method of ﬁ re building is recommended for this 3.
Page 13: Chimney Maintenance
CHIMNEY MAINTENANCE allows wood to achieve the charcoal stage faster and CAUTION: burns wood vapors which might otherwise be depos- DO NOT OVERFIRE APPLIANCE. YOU ARE ited within the heating system. OVERFIRING IF ANY PART OF THE APPLIANCE 3. BURN ONLY SEASONED WOOD. Avoid burning wet GLOWS RED.
Page 14: Service Hints
SERVICE HINTS ASH REMOVAL AND DISPOSAL Gasket and Glass cleaning products are available at local retail home centers. Manufacturers of cleaning products Whenever ashes get 3 to 4 inches deep in your ﬁ rebox or for wood stoves include, A.W. Perkins Co. (www.awper- ash pan, and when the ﬁ...
Page 15: Repair Parts
REPAIR PARTS Part No. Description Qty. Part No. Description Qty. 69660 Complete Door Assembly 88158 Fiber Board, Front 88066 5/8” Rope Gasket 6 ft. 88159 Fiber Board, Rear 891813 Door Glass 88160 Fiber Blanket 88174 Gasket-Flat, Glass (3/16T x 3/8W) 6 ft.
Page 16: Floor Protector
FLOOR PROTECTOR The stove must be placed on solid concrete, solid masonry, or when installed on a combustible ﬂ oor, on a Type 2 ﬂ oor protector listed to standard UL 1618 with a minimum R value of 1.2 or equivalent. The ﬂ oor protector is required to provide heat, live ember, and ash protection and must be of a non-combustible, continuous solid surface to protect against inﬁ...
Page 17 NOTES...
Page 18 HOW TO ORDER REPAIR PARTS THIS MANUAL WILL HELP YOU OBTAIN EFFICIENT, DEPENDABLE SER- VICE FROM YOUR HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. WHEN WRITING, ALWAYS GIVE THE FULL MODEL NUMBER WHICH IS ON THE NAMEPLATE ATTACHED TO THE HEATER.
Page 19 WARRANTY INFORMATION CARD Name______________________________________ Telephone #: (_____)_____________ City______________________________________ State_______ Zip_________________ Email Address ____________________________________________________________ Model # of Unit_____________________________ Serial #___________________________ Fuel Type: Wood Coal Pellet Gas Other ______________________ Place of Purchase (Retailer)___________________________________________________ City__________________________________________ State_______ Zip_________________ If internet purchase, please list website address___________________________________ Date of Purchase __________________________________________________________ Reason for Purchase: Alternative Heat...
Page 20   Fold Here Fold Here Fold Here PLACE STAMP HERE U. S. STOVE P.O. Box 151 South Pittsburg, TN 37380...
