1
INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________26
2
INSTALLATION OF THE APPLIANCE_________________________________________28
3
ADAPTATION TO DIFFERENT TYPES OF GAS ________________________________31
4
FINAL OPERATIONS ______________________________________________________36
5
DESCRIPTION OF FRONT PANEL CONTROLS ________________________________37
6
USE OF THE COOKING HOB _______________________________________________39
7
USE OF THE OVEN _______________________________________________________42
8
ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) __________________46
9
DIGITAL TIMER (CERTAIN MODELS ONLY) ___________________________________48
10
ANALOGUE CLOCK (ONLY ON EQUIPPED MODELS) _________________________48
11
CLEANING AND MAINTENANCE ___________________________________________49
12
EXTRAORDINARY MAINTENANCE _________________________________________51
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified technician who must carry out a
suitable check of the gas system, install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice, description of the commands and the
correct procedures for cleaning and maintenance of the appliance.
25
Contents
Advertisement
Table of Contents
Related Manuals for Smeg JGB92XD1W
Summary of Contents for Smeg JGB92XD1W
-
Page 1: Table Of Contents
INSTRUCTIONS FOR SAFE AND PROPER USE _______________________________26 INSTALLATION OF THE APPLIANCE_________________________________________28 ADAPTATION TO DIFFERENT TYPES OF GAS ________________________________31 FINAL OPERATIONS ______________________________________________________36 DESCRIPTION OF FRONT PANEL CONTROLS ________________________________37 USE OF THE COOKING HOB _______________________________________________39 USE OF THE OVEN _______________________________________________________42 ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) __________________46 DIGITAL TIMER (CERTAIN MODELS ONLY) ___________________________________48 ANALOGUE CLOCK (ONLY ON EQUIPPED MODELS) _________________________48 CLEANING AND MAINTENANCE ___________________________________________49... -
Page 2: Instructions For Safe And Proper Use
Introduction 1 INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER. - Page 3 Introduction LOWER THE GLASS COVER SLOWLY AND BY HAND. WARNING: THE GLASS COVER MAY SHATTER IF IT OVERHEATS. SWITCH OFF ALL RINGS AND WAIT FOR THEM TO COOL DOWN BEFORE CLOSING THE COVER. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.
-
Page 4: Installation Of The Appliance
Instruction for the installer 2 INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by competent persons. Corgi gas installers are approved to work to safe and satisfactory standards. All gas installation, servicing and repair work must be in accordance with the gas safety regulations 1984 (installation and use) as amended 1990. -
Page 5: Instruction For The Installer
2.1 Electrical connection Make sure that the power line voltage matches the specifications indicated on the rating plate located inside the storage compartment. This rating plate must never be removed. If the appliance is hooked-up to the supply by means of a fixed connection, install a multipolar cut-out device on the line, with contact opening distance equal to or greater than 3 mm, located near the appliance and in an easily reachable position. - Page 6 Instruction for the installer 2.3 Connecting to natural and LPG gas (Please see connection diagram) Make the connection to the appliance using flexible bayonet style hose in accordance to B.S. 669. The hose connection at the rear of the appliance has a ½” BSP internal thread.
-
Page 7: Adaptation To Different Types Of Gas
Instruction for the installer 3 ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooker hob is set for natural gas G20 (2H) at a pressure of 20 mbar for cookers with maxi oven, and for LPG G30/G31 (3+) at a pressure of 28/37 mbar for cookers with gas-bottle compartments. - Page 8 3.2 Burner and nozzle characteristics table (60 cm. models) Rated heating Burner capacity (kW) Auxiliary Semi-rapid 1.75 Rapid (3) Rapid (5) Triple crown Oven Rated heating Burner capacity (kW) Auxiliary Semi-rapid 1.75 Rapid (3) Rapid (5) Triple crown Oven Instruction for the installer LPG –...
- Page 9 3.3 Burner and nozzle characteristics table (90 cm. models) Rated Burner heating capacity (kW) Auxiliary Semi-rapid 1.75 Rapid Triple crown Fish pan Oven Maxi oven Grill Maxi grill Rated Burner heating capacity (kW) Auxiliary Semi-rapid 1.75 Rapid Triple crown (4) Triple crown (8) Fish pan Oven...
- Page 10 Instruction for the installer 3.4 Arrangement of burners on cooking hob 3.5 Arrangement of burners on cooking hob BURNERS 1. Auxiliary 2. Semi-rapid 3. Rapid (60 X 60) 4. Triple crown Rapid (60 X 50) BURNERS 1. Auxiliary 2. Semi-rapid 3.
- Page 11 3.6 Adjustment of the oven burner (only for gas oven models) To adjust the oven burners follow the procedure described below from inside the oven: • Open the oven door; • Remove the oven dish and shelf. • Lift up the oven floor and remove. 3.6.1 Replacement of the oven burner nozzle •...
-
Page 12: Final Operations
For best cooking the appliance must be perfectly level. Depending on the model you have purchased, the foot height adjustment range may vary from 70 to 95 mm and from 110 to 160 mm. These heights refer to the distance between the highest point of the foot (fixed part) and the lowest point (movable part which rests on the floor). -
Page 13: Description Of Front Panel Controls
5 DESCRIPTION OF FRONT PANEL CONTROLS All the oven controls are grouped together on the front panel. The table below provides a description of the symbols used. FRONT RIGHT BURNER BACK RIGHT BURNER BACK LEFT BURNER FRONT LEFT BURNER CENTRAL BURNER If the cooker is equipped with an electronic programmer, before using the oven make sure that the symbol COOKING HOB BURNER COMMAND KNOB... - Page 14 Instruction for the user OVEN LIGHT SWITCH (CERTAIN MODELS ONLY) This switch allows the light inside the oven to be switched on at any moment. Tramite questo tasto è anche possibile far partire il motorino girarrosto.. MINUTE COUNTER KNOB (CERTAIN MODELS ONLY) Turn clockwise to wind up the alarm and set to the desired time.
-
Page 15: Use Of The Cooking Hob
Instruction for the user 6 USE OF THE COOKING HOB 6.1 Lighting of the cooking hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples. - Page 16 Instruction for the user 6.3 Diameter of containers (60 cm. models) 6.4 Diameter of containers (90 cm. models) BURNERS Ø min. and (60 X 50) max. (in cm.) 1. Auxiliary 12 – 14 2. Semi-rapid 16 – 22 5. Rapid 18 –...
-
Page 17: Instruction For The User
6.5 Switching on the electric hob 6.5.1 Switching on the electric hobs The cookers are equipped with hobs of different diameters. These are controlled by a switch and are turned on by turning the knob to the desired position. On the front panel above each knob a small drawing shows which hob corresponds to each knob. -
Page 18: Use Of The Oven
Instruction for the user 7 USE OF THE OVEN For those models with electronic programmer, before using the oven make sure that the display shows the symbol For those models with analogue clock and timer, place on the symbol 7.1 Warnings and general advice Using the oven and the grill for the first time, heat them to the maximum temperature (260°C for electric oven and 275°C for gas oven) for as long as it takes to burn off any production oil residues which could give a nasty flavour to the food. -
Page 19: Use Of The Electric Grill
7.4 Use of the electric grill 7.4.1 Using the grill in cookers with electric oven Having opened the oven door, press the knob and turn it clockwise to the grill match to the burner on the roof of the oven. Once the burner is lit, hold the knob down for about 10 seconds. - Page 20 Instruction for the user How to use the grill Once the grill is lit, the red warning light will come on. Leave the oven to heat up for five minutes before placing the food inside. Food should be flavoured and basted with oil or melted butter before cooking. An oven dish should be used to contain the sauces.
-
Page 21: Storage Compartment
Never store flammable materials such as rags, paper or the like. The compartment is intended only for holding the metal accessories of the range. Never open the storage compartment when the oven is on and still hot. The temperature inside may be very high. -
Page 22: Electronic Programmer (Only On Equipped Models)
Instruction for the user 8 ELECTRONIC PROGRAMMER (ONLY ON EQUIPPED MODELS) LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 8.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates . - Page 23 Instruction for the user 8.4 End of cooking When cooking is over, the oven will automatically switch off and, at the same time, an intermittent alarm will sound. After switching off the alarm, the display will once again show the right time together with the symbol , indicating that the oven has returned to manual operation mode.
-
Page 24: Digital Timer (Certain Models Only)
Instruction for the user 9 DIGITAL TIMER (CERTAIN MODELS ONLY) This component allows an on-off beeper to be set to indicate the end of the cooking time. It is therefore just a timer, with no programming functions. LIST OF FUNCTIONS TIME-SETTING BUTTON VALUE DECREASE BUTTON VALUE INCREASE BUTTON... -
Page 25: Cleaning And Maintenance
11 CLEANING AND MAINTENANCE 11.1 Cleaning stainless steel and enamelled versions To maintain stainless steel in good condition it must be cleaned regularly after each use, once it has cooled down. 11.1.1 Ordinary Daily Cleaning To clean and preserve the stainless steel surfaces, always use only specific products that do not contain abrasives or chlorine-based acids. -
Page 26: Cleaning Of Oven
Instruction for the user 11.2.2 Grids Remove the grids and clean them in warm water with a non-abrasive detergent, taking care to remove any incrustations. Replace them on the cooking hob. Continuous contact of the grids with the flame can cause the paint near the hot areas to be altered. This is completely natural and does not compromise the functionality of the component. -
Page 27: Extraordinary Maintenance
Instruction for the user 12 EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. Before any intervention, disconnect the power supply of the device. 12.1 Lubrication of the taps and gas oven thermostat In time the taps and gas oven thermostat may be difficult to turn or may be blocked.
