LANCER
WORKSHOP MANUAL
SUPPLEMENT
FOREWORD
This Workshop manual contains procedures for
service mechanics, including removal, disassembly,
inspection, adjustment, reassembly and installation.
Use the following manuals in combination with this
manual as required.
TECHNICAL INFORMATION MANUAL
WORKSHOP MANUAL
CHASSIS GROUP
BODY REPAIR MANUAL
PARTS CATALOGUE
All information, illustrations and product descriptions
contained in this manual are current as at the time of
publication. We, however, reserve the right to make
changes at any time without prior notice or obligation.
©Mitsubishi Motors Corporation

GROUP INDEX

General . . . . . . . . . . . . . . . . . . . . . . . .
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . .
PYME0302
PYME0302-A
PYME0302-B
PWME0302
PWME0302-A
PWME0302-B
PBME0302
PBME0302-A
PBME0302-B
B606K006A_
Oct. 2005
00
13
