Summary of Contents for Mitsubishi MOTORS LANCER EVOLUTION

Page 1 LANCER EVOLUTION OWNER’S MANUAL LANCER EVOLUTION - ENGLISH - OCZE14E3...
Page 2 Throughout this owner’s manual the words WARNING and CAUTION appear. E09200104542 E09300101630 Thank you for selecting a LANCER EVOLUTION as your new vehicle. These serve as reminders to be especially careful. Failure to follow instruc- Fuel tank capacity 55 litres This owner’s manual will add to your understanding and full enjoyment of...
Page 3 Table of contents Overview General information Locking and unlocking Seat and seat belts Instruments and controls Starting and driving For pleasant driving For emergencies Vehicle care Maintenance Specifications OCZE14E3...
Page 4 Overview Instruments and Controls (Driver’s area) E00100107145 1. Multi-information meter switch p. 3-05 2. Instruments p. 3-02 3. Shift paddles* p. 4-21, 4-22 4. Wiper and washer switch p. 3-44 5. Cruise control switches* p. 4-38 6. Ignition switch p. 1-11, 1-16, 4-09 7.
Page 5 Overview 1. Shift paddles p. 4-21, 4-22 2. Instruments p. 3-02 3. Multi-information meter switch p. 3-05 4. Wiper and washer switch p. 3-44 5. Cruise control switches p. 4-38 6. ASC OFF switch p. 4-34 7. Trunk lid opener switch p. 1-26 8.
Page 6 Overview Instruments and Controls (Instrument panel) E00100107158 1. Ventilators p. 5-02 2. Gearshift lever p. 4-14, 4-17 3. Supplemental restraint system - airbag (for front passenger’s seat) p. 2-18, 2-22 4. Front passenger’s airbag ON-OFF switch p. 2-18, 2-21 5. Glove box p. 5-63 USB input terminal* p.
Page 7 Overview 1. Supplemental restraint system - airbag (for front passenger’s seat) p. 2-18, 2-22 2. Gearshift lever p. 4-14, 4-17 3. Ventilators p. 5-02 4. Fuel tank filler door release lever p. 03 5. AWC switch p. 4-29 6. Cup holder p. 5-64 7.
Page 8 Overview Centre panel E00100600590 1. Audio* p. 5-09 DISPLAY AUDIO* MITSUBISHI Multi-Communication System* Refer to the separate owner’s manual 2. Hazard warning flasher switch p. 3-43 3. Front passenger seat belt warning lamp p. 2-08 4. Rear window demister switch p. 3-47 5.
Page 9 Overview Interior E00100205096 1. Electric window control switches p. 1-34 2. Lock switch p. 1-35 3. Electric remote-controlled outside rear-view mirrors switch p. 4-07 4. Central door lock switch p. 1-23 5. Front room & map lamp p. 5-60, 8-23, 8-28 6.
Page 10 Overview 1. Front room & map lamp p. 5-60, 8-23, 8-28 2. Microphone (for Bluetooth ® 2.0 interface)* p. 5-41 3. Lock switch p. 1-35 4. Electric remote-controlled outside rear-view mirrors switch p. 4-07 5. Electric window control switches p. 1-34 6.
Page 11 Overview Interior E00100205100 1. Assist grip p. 5-65 2. Coat hook p. 5-66 3. Supplemental restraint system - curtain airbag p. 2-26 4. Rear room lamp p. 5-61, 8-23, 8-28 5. Rear seat p. 2-05 6. Cup holder p. 5-65 7.
Page 12 Overview 1. Rear room lamp p. 5-61, 8-23, 8-28 2. Supplemental restraint system - curtain airbag p. 2-26 3. Coat hook p. 5-66 4. Assist grip p. 5-65 5. AWC control fluid tank p. 8-06, 9-11 6. Tether anchorages for child restraint system p. 2-16 7.
Page 13 Overview Trunk area (Except for vehicle with spare wheel) E00100300467 1. Trunk room lamp p. 8-23, 8-29 2. Tyre repair kit p. 6-05 3. Battery p. 6-02, 8-08 4. Tools p. 6-06 5. Jack p. 6-06 6. Front washer fluid reservoir p. 8-07 OCZE14E3...
Page 14 Overview Trunk area (Vehicle with full size spare wheel) E00100300760 1. Trunk room lamp p. 8-23, 8-29 2. Battery p. 6-02, 8-08 3. Tools p. 6-06 4. Jack p. 6-06 5. Spare wheel p. 6-12, 6-13 6. Front washer fluid reservoir p. 8-07 OCZE14E3...
Page 15 Overview Trunk area (Vehicle with compact spare wheel) E00100300483 1. Trunk room lamp p. 8-23, 8-29 2. Battery p. 6-02, 8-08 3. Tools p. 6-06 4. Jack p. 6-06 5. Spare wheel p. 6-12, 6-13 6. Front washer fluid reservoir p. 8-07 OCZE14E3...
Page 16 Overview Outside (Front) E00100505738 1. Windscreen wipers and washer p. 3-44, 8-14 2. Keyless entry system* p. 1-04 Keyless operation system* p. 1-07 Locking and unlocking p. 1-22 3. Fuel tank filler p. 03 4. Outside rear-view mirrors p. 4-07 5.
Page 17 Overview Outside (Rear) E00100505174 1. Rear-view camera* p. 4-43 2. High-mounted stop lamp p. 8-22 3. Antenna p. 5-39 4. Tyre inflation pressures p. 8-10 Changing tyres p. 6-12 Tyre rotation p. 8-11 Tyre chains p. 8-12 5. Rear turn-signal lamps p. 3-41, 8-22, 8-26 6.
Page 18 OCZE14E3...
Page 19: Table Of Contents
General information Fuel selection................... 02 Filling the fuel tank................03 Installation of accessories..............04 Modification/alterations to the electrical or fuel systems....05 Genuine parts................... 05 Used engine oils safety instructions and disposal information..05 Disposal information for used batteries........... 06 OCZE14E3...
Page 20: Fuel Selection
If the check engine warning lamp flashes, NOTE have the system checked as soon as possible at a MITSUBISHI MOTORS Authorized Your vehicles have the knock control system Service Point. so that you can use unleaded petrol 95 RON...
Page 21: Filling The Fuel Tank
If the tank cap must be replaced, use only a MITSUBISHI MOTORS original part. 3. Open the fuel tank filler tube by slowly turn- ing the cap anticlockwise. Fuel tank capacity...
Page 22: Installation Of Accessories
Only in sories. the case of parts (MITSUBISHI MOTORS original Improper installation of electrical compo- replacement or exchange parts as well as nents may cause an electrical fire if incor- MITSUBISHI MOTORS genuine accessories) that rectly fitted.
Page 23: Modification/Alterations To The Electrical Or Fuel Systems
Genuine parts Used engine oils safety electrical or fuel systems instructions and disposal E00200500545 MITSUBISHI MOTORS has gone to great lengths information E00200400195 to bring you a superbly crafted automobile offering MITSUBISHI MOTORS has always manufactured the highest quality and dependability.
Page 24: Disposal Information For Used Batteries
General information Disposal information for used batteries E00201300016 Your vehicle contains batteries and/or accumulators. Do not be mixed with general household waste. For proper treatment, recovery and recycling of used batteries, please take them to applicable collection points, in accordance with your national legislation and the Directives 2006/66/EC.
Page 25 Locking and unlocking Keys....................1-02 Electronic immobilizer (Anti-theft starting system).....1-03 Keyless entry system*..............1-04 Keyless operation system*............1-07 Doors.................... 1-22 Central door locks.................1-23 Dead Lock System*..............1-24 “Child-protection” rear doors............1-26 Trunk lid..................1-26 Security alarm system (except for vehicles for Israel)....1-28 Electric window control..............1-34 OCZE14E3...
Page 26: Keys
Locking and unlocking Keys Type 2 NOTE The key number is stamped on the tag as in- The emergency key fits all locks. E00300102360 dicated in the illustration. Type 1 Make a record of the key number and store the key and key number tag in separate pla- The key fits all locks.
Page 27: Electronic Immobilizer (Anti-Theft Starting System)
“Keyless operation system: Electronic immobilizer central door lock switch (vehicles equip- contact your MITSUBISHI MOTORS (Anti-theft starting system)” on pages 1-11, ped with the central door lock switch). Authorized Service Point.
Page 28: Keyless Entry System
E00300302737 lock switch, the door unlock function can be Press the remote control switch to lock or unlock MITSUBISHI MOTORS Authorized Service set so that only the driver’s door unlocks the doors and to open the trunk lid. Point as soon as possible.
Page 29 If you wish to add a remote control switch, electricity from your body by touching a locking or unlocking of the doors with please contact your MITSUBISHI MOTORS metal grounded object. the blink of the turn-signal lamps) can be Authorized Service Point. A maximum of 8 2.
Page 30 3. NOTE You may purchase a replacement battery at an electric appliance store. A MITSUBISHI MOTORS Authorized Service Point can replace the battery for you if you prefer. CAUTION When the remote control switch case is...
Page 31: Keyless Operation System
(The keyless operation system can be nearby. used as a keyless entry system.) Please con- • When the keyless operation key battery is sult a MITSUBISHI MOTORS Authorized worn out. Service Point. • You can limit operations to locking and unlocking of the doors and to opening of the trunk lid.
Page 32 The battery life is 1 to 3 years, depending on usage conditions. When the battery wears out, have it replaced at your MITSUBISHI MOTORS Authorized Service Point. Because the keyless operation key continual- ly receives signals, strong radio wave recep- NOTE tion could affect battery wear.
Page 33 Locking and unlocking If the keyless operation key is within the op- If you are too close to the door or door win- With a vehicle that has a Dead Lock System, erating range, even someone not carrying the dow, the engine may be able to be started pressing the driver’s or front passenger’s key can lock and unlock the doors or open even though the keyless operation key is out-...
Page 34 With a vehicle that has a Dead Lock System, it is locking adjusted. Consult possible to set the Dead Lock System using the MITSUBISHI MOTORS Authorized Service Point. driver’s or front passenger’s door lock/open switch. Operation confirmation when locking and un- (Refer to “Dead Lock System”...
Page 35 LOCK (PUSH OFF) If you lose one of the keyless operation keys, The position in which the steering wheel is locked. contact a MITSUBISHI MOTORS Author- ized Service Point as soon as possible. LOCK (PUSH ON) To obtain a replacement or extra spare key,...
Page 36 1-13. system. If any of the following warnings are activated, CAUTION please contact a MITSUBISHI MOTORS Author- Keyless operation key take-out monitoring system ized Service Point. E00308000286 Do not turn the ignition switch to the “LOCK”...
Page 37 E00308200448 information, please contact your To lock MITSUBISHI MOTORS Authorized Service Turn the steering wheel until it is locked. Point. Even if you have the keyless operation key To unlock within the engine start operating range, if the Turn the ignition switch to the “ACC” position...
Page 38 Locking and unlocking CAUTION WARNING Carry the key with you when leaving the Never run the engine in a closed or poor- ly ventilated area any longer than is nee- vehicle. ded to move your vehicle in or out of the If your vehicle needs to be towed, turn area.
Page 39 Locking and unlocking To operate without using the keyless 2. While depressing the brake pedal, press the Locking and unlocking the door accelerator pedal halfway and hold it there, Turning the emergency key in the forward direc- operation function then crank the engine. Release the accelera- tion locks the door, and turning it in the rear direc- E00306000077 tor pedal, immediately after the engine starts.
Page 40 (A). If you lose one of the keyless operation keys, such as the audio system, accessory socket and cig- contact your MITSUBISHI MOTORS Au- arette lighter can be operated. thorized Service Point as soon as possible.
Page 41 Locking and unlocking To turn from “ACC” to “LOCK” CAUTION CAUTION 1. First, set the gearshift lever to the “P” (PARK) position, and then push the emer- Do not turn the ignition switch to the Remove the emergency key when leaving gency key in at the “ACC”...
Page 42 Locking and unlocking 6. Insert the emergency key into the ignition WARNING switch. Never run the engine in a closed or poor- ly ventilated area any longer than is nee- ded to move your vehicle in or out of the area.
Page 43 Locking and unlocking 9. Turn the emergency key with the keyless op- 2. While depressing the brake pedal, press the (Vehicles equipped with the mirror retractor eration key to the “START” position without accelerator pedal halfway and hold it there, switch) depressing the accelerator pedal, and release then crank the engine.
Page 44 To extend For further information, please contact your about 30 seconds. Within 30 seconds of unlocking the doors using the MITSUBISHI MOTORS Authorized Service Refer to “Instruments and controls: Welcome UNLOCK switch (2), press the UNLOCK switch Point. light” on page 3-39.
Page 45 If you wish to add a remote control switch, metal grounded object. please contact your MITSUBISHI MOTORS 2. With the MITSUBISHI mark facing you, in- Authorized Service Point. A maximum of 4 - side...
Page 46: Doors
Locking and unlocking Doors NOTE NOTE On LHD vehicles, when locking or unlock- The driver’s door can be opened without us- E00300402161 ing with the key, only the driver’s door will ing the inside lock knob by pulling on the in- be locked or unlocked.
Page 47: Central Door Locks
Locking and unlocking Central door locks Ignition switch on reminder system* To lock and unlock the doors E00311500054 E00310100356 E00300801517 Type 1 (LHD vehicles) Using the central door lock switch When the engine was started using the keyless op- E00311400082 All of the doors can be locked or unlocked by eration function pressing the central door lock switch on the driv-...
Page 48: Dead Lock System
To activate or de- activate these functions, please contact a CAUTION MITSUBISHI MOTORS Authorized Service Point. Do not set the Dead Lock System when someone is inside the vehicle. With the...
Page 49 Locking and unlocking 4. Press the LOCK switch (A) on the keyless NOTE operation key, or the driver or front passen- Pressing the LOCK switch (A) once while ger’s door lock/unlock switch (B) again the Dead Lock System is set causes the turn- within two seconds.
Page 50: Child-Protection" Rear Doors
LOCK switch (A), or the driver’s or front passenger’s door lock/ WARNING unlock switch (B). For details, please contact a MITSUBISHI MOTORS Authorized Serv- The trunk cannot be opened from the in- ice Point. side. Do not allow children to get inside the trunk.
Page 51 Locking and unlocking To close 2. Press the trunk lid opener switch to open the trunk lid. The trunk lid will pop up slightly. Pull the trunk lid downward as illustrated. Gently Lift it to open the trunk. slam the trunk lid from the outside so that it is completely closed.
Page 52: Security Alarm System (Except For Vehicles For Israel)
Have vehicle inspected Attempt an unlawful moving of the vehicle. MITSUBISHI MOTORS Authorized Service (the vehicle inclination detection function) Point. Detect a motion in the vehicle. (the interior If the confirmation function (blinking of the intrusion detection function) turn-signal lamps by locking and unlocking Disconnect the battery terminal.
Page 53 MITSUBISHI MOTORS Authorized Service Once the system preparation mode has ended, the Refer to “Cancelling the system” on page 1-32, Point. system armed mode starts. “Cancelling the alarm” on page 1-33.
Page 54 Locking and unlocking (Since the ignition switch is in the “LOCK” Except for vehicles with the keyless operation system position, washer fluid will not be sprayed.) Vehicles equipped with the keyless operation system 4. After approximately 10 seconds, the buzzer will make a sound.
Page 55 MITSUBISHI MOTORS Authorized Service Point. Avoid leaving valuable items inside the vehi- cle even when the security alarm system has been set to the “active” mode. Setting the system...
Page 56 Locking and unlocking NOTE To deactivate the vehicle inclination detection NOTE The system preparation mode is not activated function and the interior intrusion detection The function will be activated again if the when the doors have been locked using a function* following operation is performed.
Page 57 When it is closed, the system will be tails. rearmed. The time for the vehicle inside alarm can be Cancelling the alarm adjusted. Consult a MITSUBISHI MOTORS E00302000532 Authorized Service Point. It is possible to halt the activation of an alarm us- ing the following methods:...
Page 58: Electric Window Control
Locking and unlocking Electric window control Pressing one of the switches on the remote WARNING control switch. (After pressing the LOCK E00302200390 switch, the vehicle will lock if all the doors The electric windows can only be operated with the Before operating the electric window con- are closed, after which the system prepara- ignition switch in the “ON”...
Page 59 Locking and unlocking Press the switch down for opening the window, To unlock, press it once again. WARNING and pull up the switch for closing. WARNING If the safety mechanism is activated three or more times successively, the safety mechanism will be temporarily cancelled. A child may tamper with the switch at If a hand or head got trapped, a serious the risk of its hands or head being trap-...
Page 60 Locking and unlocking If the safety mechanism is activated three or more times in a row, the safety mechanism will be cancelled and the door window will not close correctly. In such a case, the following procedure should be implemented to rectify this situa- tion.
Page 61 Seat and seat belts Seat....................2-02 Seat adjustment................2-03 Front seat..................2-03 Rear seat..................2-05 Head restraints (Rear seat only)............2-05 Seat belts..................2-06 Pregnant women restraint............. 2-08 Seat belt pretensioner system and force limiter system....2-09 Child restraint................2-09 Seat belt inspection............... 2-18 Supplemental restraint system (SRS) - airbag......
Page 62: Seat
Seat and seat belts Seat E00400101074 1-Front seat To adjust forward or backward ® p. 2-03 To recline the seatback ® p. 2-04 Heated seats* ® p. 2-04 2-Rear seat Armrest ® p. 2-05 2-02 OCZE14E3...
Page 63: Seat Adjustment
Seat and seat belts Seat adjustment Front seat CAUTION E00400300428 E00400400012 To adjust forward or backward Adjust the driver’s seat so that you are comfortable Make sure the seat is adjusted by an and that you can reach the pedals, steering wheel, E00400500589 adult or with adult supervision for cor- Pull the seat adjusting lever and adjust the seat for-...
Page 64 Seat and seat belts To recline the seatback 1 (HI)- Heater high (for quick heating). CAUTION E00400600708 Heater off. Adjust the seatback angle by turning the knob. When cleaning the seat, do not use ben- 3 (LO)- Heater low (to keep the seat warm). zine, kerosene, petrol, alcohol, or other organic solvents;...
Page 65: Rear Seat
Seat and seat belts Rear seat Head restraints (Rear seat only) To raise the head restraint, move it upward. To lower the restraint, move it downward while push- E00401300018 E00403301035 Armrest ing the height adjusting knob (A) in the direction of the arrow.
Page 66: Seat Belts
Seat and seat belts Seat belts To install WARNING Confirm that the head restraint is facing the correct E00404800577 To protect you and your passengers in the event of direction, and then insert it into the seatback while No modifications or additions should be an accident, it is the most important that the seat pressing the height adjusting knob (A) in the direc- made by the user which will either pre-...
Page 67 Seat and seat belts Driver’s seat belt reminder/warning NOTE WARNING lamp and display You can check if the belt locks by pulling it forward quickly. The seat belts must not be twisted when E00409800686 worn. Warning lamp To fasten 1. Pull the seat belt out slowly while holding 3.
Page 68: Pregnant Women Restraint
Seat and seat belts Pregnant women restraint Adjustable seat belt anchor (front NOTE seats) At the same time, “FASTEN SEAT BELT” E00405600064 will be displayed on the information screen E00405000420 The seat belt anchor height can be adjusted. in the multi-information display. WARNING Move the seat belt anchor down with the lock knob (A) depressed.
Page 69: Seat Belt Pretensioner System And Force Limiter System
If you need to scrap the vehicle, please E00405700081 type of child restraint system should always be consult a MITSUBISHI MOTORS Au- The driver’s seat and front passenger’s seat each used according to the size of the child. This is re- thorized Service Point.
Page 70 Seat and seat belts Caution for installing the child re- Use rearward facing child restraints in the rear seat or turn off the front passenger’s airbag ON-OFF straint on vehicles with a front passen- switch. (Refer to “To turn an airbag off” on page ger airbag 2-22.) E00406500549...
Page 71 Seat and seat belts The child restraint system should be appro- WARNING priate for your child’s weight and height and properly fit the vehicle. For a higher degree When the child restraint system is not in of safety: THE CHILD RESTRAINT SYS- use, keep your child restraint system se- TEM SHOULD BE INSTALLED IN THE cured with the seat belt or remove it from...
Page 72 IUF- Suitable for ISOFIX forward child restraints systems of universal category approved for use in the mass group. IL- Suitable for particular ISOFIX child restraint systems given in the following list (MITSUBISHI MOTORS GENUINE parts). X- ISOFIX position not suitable for ISOFIX child restraint systems in this mass group.
Page 73 UN-R44 Approval No. MZ314393 (Child restraint system), E1-04301146 MZ314394 (ISOFIX base) MZ313045 E1-04301133 NOTE MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For further information, please contact a MITSUBISHI MOTORS Authorized Service Point. 2-13 OCZE14E3...
Page 74 U- Suitable for “universal” category restraints approved for use in this mass group. UF- Suitable for forward-facing “universal” category restraints approved for use in this mass group. L- Suitable for particular child restraints in the following list (MITSUBISHI MOTORS genuine parts). X- Seat position not suitable for children in this mass group.
Page 75 Seat and seat belts NOTE There is no applicable MITSUBISHI MOTORS Genuine Parts to the Mass Group “0-Up to 10 kg”. MITSUBISHI MOTORS Europe B.V. reserves the right to changes without any prior announcement. For further information, please contact a MITSUBISHI MOTORS Authorized Service Point.
Page 76 Seat and seat belts Installing a child restraint system to Tether anchorage locations It is not necessary to retain the child restraint sys- There are 2 attachment points on the rear shelf, lo- tem using the vehicle’s seat belts. the lower anchorage (ISOFIX child re- cated behind the top of your rear seat.
Page 77 Seat and seat belts Installing a child restraint system to a 5. Latch the top tether strap hook (F) of the child restraint system to the tether anchorage 3-point type seat belt (with emergency bracket (G) and tighten the top tether strap so locking mechanism) that it is securely fastened.
Page 78: Seat Belt Inspection
Seat and seat belts Seat belt inspection Supplemental restraint system WARNING (SRS) - airbag E00406300475 Check the belts for cuts, worn or frayed web- For some types of child restraint, the E00407201843 bing and for cracked or deformed metallic locking clip (A) should be used to help The information written in this Supplemental Re- parts.
Page 79 Seat and seat belts 5- Front passenger’s airbag ON-OFF switch CAUTION The SRS is NOT a substitute for the seat belts; for maximum protection in all types of crashes and ac- Airbags inflate at an extremely rapid cidents, seat belts should ALWAYS be worn by speed.
Page 80 Seat and seat belts Use rearward facing child restraints in the rear seat or turn off the front passenger’s airbag ON-OFF switch. (Refer to “To turn an airbag off” on page 2-22.) Front passenger’s airbag ON WARNING WARNING Infants and small children should never Older children should be seated in the be unrestrained, stand up against the in- rear seat, properly wearing the seat belt,...
Page 81 Seat and seat belts Caution for installing the child re- Front passenger’s airbag ON-OFF Front passenger’s airbag OFF indication lamp straint on vehicles with a front passen- switch E00411500172 The front passenger’s airbag OFF indication lamp ger airbag E00410100302 is located in the instrument panel. The front passenger’s airbag ON-OFF switch can E00408800823 be used to disable the front passenger’s airbag.
Page 82 We tion switch before operating a front recommend you to have the system in- passenger’s airbag ON-OFF switch. spected by a MITSUBISHI MOTORS Failure to do so could adversely affect Authorized Service Point. the airbag performance.
Page 83 Seat and seat belts Deployment of front airbags and driv- The front passenger’s airbag deploys at the same The front airbags and driver’s knee airbag will de- time as the driver’s airbag, even if the passenger ploy if the severity of the impact is above the de- er’s knee airbag seat is not occupied, and inflates at two different signed threshold level, comparable to an approxi-...
Page 84 Seat and seat belts Examples of some typical conditions are shown in Such conditions are shown in the illustration. Examples of some typical conditions are shown in the illustration. the illustration. 1- Rear end collisions 1- Collision with a utility pole, tree or other 2- Side collisions 1- Collision with an elevated median/island or narrow objects...
Page 85 Seat and seat belts WARNING WARNING WARNING Do not set anything on, or attach any- Do not attach accessories to the lower The airbag system is designed to work thing to, the instrument panel above the portion of the driver’s side instrument only once.
Page 86 Seat and seat belts Deployment of side airbags and cur- The label shown here is attached to the seatbacks The side airbags and curtain airbags MAY NOT with a side airbag. DEPLOY when… tain airbags With certain types of side collisions, the vehicle’s E00407701327 body structure is designed to absorb the shock to The side airbags and curtain airbags ARE DE-...
Page 87 Seat and seat belts Examples of some typical conditions are shown in Because the side airbags and curtain airbags do not WARNING the illustration. protect the occupant in all types of side collisions, be sure to always properly wear your seat belts. The side airbags and curtain airbags are designed to supplement the driver and The side airbags and curtain airbags ARE NOT...
Page 88 Do not put a hanger or any heavy or bag inflation. to be done by a MITSUBISHI MOTORS pointed object on the coat hook. Do not install seat covers on seats with Authorized Service Point.
Page 89 SRS inspec- ted by a MITSUBISHI MOTORS Au- thorized Service Point. 2-29 OCZE14E3...
Page 90 OCZE14E3...
Page 91 Instruments and controls Instruments................... 3-02 Multi-information display.............3-03 Indication lamp, warning lamp, and information screen display list.................3-21 Indication lamps................3-33 Warning lamps................3-33 Information screen display............3-35 Combination headlamps and dipper switch........3-37 Headlamp levelling...............3-40 Turn-signal lever................3-41 Adaptive Front lighting System (AFS).........3-41 Hazard warning flasher switch............. 3-43 Fog lamp switch................3-43 Wiper and washer switch..............3-44 Headlamp washer switch..............
Page 92: Instruments
Instruments and controls Instruments Tachometer NOTE You can adjust to 8 different levels for when E00500300605 E00500101466 The tachometer indicates the engine speed (r/min). the position lamps are illuminated and 8 for The tachometer can help you obtain more econom- when they are not.
Page 93: Multi-Information Display
Instruments and controls Multi-information display E00519900812 The following information is included on the multi-information display: warnings, odometer, tripmeter,service reminder, engine coolant temperature, fuel remain- ing, outside temperature, Twin Clutch SST control mode, S-AWC (Super-All Wheel Control) control mode, shift lever position, average and momentary fuel con- sumption, driving range, average speed, S-AWC (Super-All Wheel Control) operation display, and meter illumination.
Page 94 Instruments and controls NOTE The trip computer function fuel units, temperature units, display language, and other settings can be changed. Refer to “Changing the function settings (when the ignition switch is “ON”)” on page 3-15. The display screen is different depending on whether the ignition switch is “OFF” or “ON”. Refer to “Information screen (when the ignition switch is “OFF”)”...
Page 95 Instruments and controls Multi-information meter switch Information screen (when the ignition This mark is also displayed if there is another warning other than the one dis- switch is “OFF”) E00520000480 Each time the multi-information meter switch is played. When the cause of the warning E00520200671 operated, a sound is emitted and the multi-informa- display is eliminated, the “!”...
Page 96 Instruments and controls NOTE Odometer Refer to “Warning display list (when the ignition The odometer indicates the distance travelled. If there is no warning display, the switching switch is “OFF”)” on page 3-23. sequence is: Odometer/Tripmeter → Od- Tripmeter ometer/Tripmeter →...
Page 97 Instruments and controls NOTE Information screen (when the ignition Refer to “Warning display list (when the ignition switch is “ON”)” on page 3-25. Warning display screens with a “ ” or “ ” switch is turned from “OFF” to mark displayed in the upper right of the “ON”) screen can be switched.
Page 98 Instruments and controls S-AWC (Super-All Wheel Active Stability Control (ASC) 4- Driving range display, momentary fuel con- sumption display Control) control mode display OFF display screen 5- Average fuel consumption display, momen- screen E00521000474 tary fuel consumption display This is displayed when the Active Sta- E00526100018 6- Average speed display, momentary fuel con- bility Control (ASC) is turned off with...
Page 99 Instruments and controls Odometer/Tripmeter Pay careful attention to the engine cool- When you refuel, the driving ant temperature display while you are range display is updated. E00524500148 driving. However, if you only add a small amount of fuel, the correct value will not be displayed.
Page 100 Instruments and controls When the ignition switch is display setting The “ ” mark (A) in the momentary fuel gauge switched from “ACC” or “LOCK” changed to the preferred units shows the average fuel consumption. to “ON”, the mode setting is auto- (km/h or mph).
Page 101 Instruments and controls The average fuel consumption will depend When the value of momentary fuel consumption WARNING on the driving conditions (road conditions, surpasses the value of average fuel consumption, how you drive, etc.). The displayed fuel con- the momentary fuel consumption is displayed with Always concentrate on your sumption may vary from the actual fuel con- a white bar graph.
Page 102 Instruments and controls Twin Clutch SST control To return to the screen displayed before the Other interrupt displays warning display The operation status of each system is displayed on mode display screen* Even if the cause of the warning display is not the information screen.
Page 103 To modify the display settings, have it adjus- NOTE ted at a MITSUBISHI MOTORS Authorized Service Point. It may take several seconds to stabilise the For more details, consult a MITSUBISHI display after refilling the tank.
Page 104 3. After your vehicle is inspected at a switch for about 2 seconds or more to dis- CAUTION MITSUBISHI MOTORS Authorized Service play “ ” and make it flash. (If there is no Point, it displays the time until the next peri-...
Page 105 Instruments and controls Door ajar warning display screen Changing the function settings (when from the setting mode screen to the menu screen. (when the ignition switch is “ON”) the ignition switch is “ON”) E00522600477 E00522700670 If any of the doors or the trunk lid is not complete- 1.
Page 106 Instruments and controls 4. Select the item to change on the menu screen 2. Lightly press the multi-information meter Auto reset mode and change to the desired setting. Refer to switch to select “AVG (average fuel con- When the average fuel consumption and the following items for further details on the sumption and average speed setting)”.
Page 107 Instruments and controls 2. Lightly press the multi-information meter 5. Press and hold the multi-information meter 2. Lightly press the multi-information meter switch to select “AVG UNIT (fuel consump- switch for about 2 seconds or more to change switch to select “ ” (temperature unit set- tion display setting)”.
Page 108 Instruments and controls 2. Lightly press the multi-information meter 1. Press and hold the multi-information meter The operation sound setting only deactivates switch to select “LANGUAGE” (language switch for about 2 seconds or more to switch the operation sound of the multi-information setting).
Page 109 Instruments and controls 3. Press and hold the multi-information meter 2. Lightly press the multi-information meter 2. Lightly press the multi-information meter switch for about 2 seconds or more to dis- switch to select (changing the turn-sig- switch to select (changing the momenta- play “ALARM”...
Page 110 Instruments and controls 2. Lightly press the multi-information meter switch to select “RESET” (returning to the factory settings). 3. When you press and hold the multi-informa- tion meter switch for about 5 seconds or more, the buzzer sounds and all of the func- tion settings are returned to the factory set- tings.
Page 111: Indication Lamp, Warning Lamp, And Information Screen Display List
Instruments and controls Indication lamp, warning lamp, and information screen display list E00523700013 Indication and warning lamp list E00523800913 1- Adaptive Front lighting System (AFS) warning lamp ® p. 3-42 8- Anti-lock brake system (ABS) warning lamp ® p. 4-32 2- Position lamp indication lamp ®...
Page 112 • An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a radar station. • Abnormal voltage or a static electricity discharge is generated by the operation of installed electrical equipment (including after-market parts). If the warning display appears many times, we recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. 3-22...
Page 113 Instruments and controls Warning display list (when the ignition switch is “OFF”) E00524000707 Screen Cause Solution (Reference) You have forgotten to turn off the lamps. Refer to “Lamps (headlamps, fog lamp, etc.) auto- cutout function” on page 3-38. The security alarm system is operating. Refer to “Security alarm system”...
Page 114 Instruments and controls Screen Cause Solution (Reference) There is a fault in the keyless operation system. Refer to “Keyless operation system” on page 1-07. 3-24 OCZE14E3...
Page 115 Instruments and controls Warning display list (when the ignition switch is “ON”) E00524101167 Screen Cause Solution (Reference) There is a fault in the keyless operation system. Refer to “Keyless operation system” on page 1-07. 3-25 OCZE14E3...
Page 116 Instruments and controls Screen Cause Solution (Reference) The brake fluid level in the reservoir has fallen to Immediately stop the vehicle in a safe place. a low level. We recommend you to consult a MITSUBISHI There is a fault in the brake system. MOTORS Authorized Service Point.
Page 117 Instruments and controls Screen Cause Solution (Reference) Twin Clutch SST fluid temperature is too high. Refer to “Twin Clutch SST” on page 4-17. You turned the ignition switch to the “ON” posi- Fasten your seat belt properly. Refer to “Driv- tion without fastening your seat belt.
Page 118 Instruments and controls Screen Cause Solution (Reference) There is a fault in the charging system. Immediately stop the vehicle in a safe place. We recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. Refer to “Charge warning display” on page 3-36.
Page 119 Instruments and controls Screen Cause Solution (Reference) There is a fault in the S-AWC (Super- All Wheel We recommend you to have it checked. Control) system. Refer to “S-AWC (Super-All Wheel Control)” on page 4-29. A safety device in the Twin Clutch SST has been We recommend you to have it checked.
Page 120 Instruments and controls Screen Cause Solution (Reference) The timing chain may be worn. Have the vehicle inspected at a MITSUBISHI MOTORS Authorized Service Point. 3-30 OCZE14E3...
Page 121 Instruments and controls Other interrupt displays (when the ignition switch is “ON”) E00524200608 The operation status of each system is displayed on the information screen. Refer to the appropriate page for the system for further details. Screen System operation status Reference When the Active stability control (ASC) and the Refer to “Active stability control (ASC)”...
Page 122 Instruments and controls Screen Solution Stop the vehicle in a safe place, turn off the engine, and take a rest. Use this display as rough guide for taking rests during a long drive. The interval from the start of your trip until this message is displayed can be set. Refer to “Changing the function settings (when the ignition switch is “ON”)”...
Page 123: Indication Lamps
Instruments and controls Indication lamps Warning lamps Position lamp indication lamp E00508900160 E00501600100 E00502400147 This indication lamp illuminates while Turn-signal indication lamps/ Brake warning lamp the position lamps are on. Hazard warning indication E00502502100 This lamp illuminates when the ignition lamps switch is turned to the “ON”...
Page 124 Instruments and controls NOTE CAUTION CAUTION Under conditions such as sporty driving, the brake fluid in the tank • The brake warning lamp If the lamp does not illuminate may move and the warning lamp does not illuminate when when the ignition switch is may come on temporarily.
Page 125: Information Screen Display
Instruments and controls Information screen display A warning is also displayed on the mul- CAUTION ti-information display. E00524600022 Brake warning display If this warning stays illuminated and E00524700238 CAUTION does not go out while driving, there is a danger of ineffective braking. If this hap- pens, immediately park your vehicle in a If it illuminates while the en- safe place and we recommend you to...
Page 126 Instruments and controls Oil pressure warning display NOTE When the ignition switch is “ON”, if the engine oil level is below the specified limit, the warning dis- Under conditions such as sporty driving, the E00524900171 play is displayed on the information screen in the brake fluid in the tank may move and the multi-information display.
Page 127: Combination Headlamps And Dipper Switch
For further information, we recommend you fog lamps also come on but the rear fog lamp to consult a MITSUBISHI MOTORS Au- stays off. If you wish to turn the rear fog thorized Service Point.
Page 128 For further information, we recommend you E00532700497 If the driver’s door is opened when the key is in the to consult a MITSUBISHI MOTORS Au- If, while the lamp switch is in the “ ” posi- “LOCK” or “ACC” position or removed from the thorized Service Point.
Page 129 • The welcome light function can be deac- tivated. Headlamp flasher For further information, please contact your E00506300199 MITSUBISHI MOTORS Authorized Service The high-beams flash when the lever is pulled NOTE Point. slightly (2), and will go off when it is released.
Page 130: Headlamp Levelling
While the coming home light function is op- may be malfunctioning. Have the vehicle erating, perform one of the following opera- inspected by a MITSUBISHI MOTORS tions to cancel the function. Authorized Service Point. • Pull the lever towards you.
Page 131: Turn-Signal Lever
For further information, we recommend you matically come on and illuminate the road in the to consult a MITSUBISHI MOTORS Au- direction in which the vehicle is being turned, thorized Service Point.
Page 132 Instruments and controls When the steering wheel is turned (on a curve, for NOTE CAUTION example), the road ahead in the direction in which The amount of steering wheel operation nec- the vehicle is being turned is illuminated. (The left essary to illuminate the bending lamps If the warning display is displayed, the bending lamp comes on when the vehicle is turned...
Page 133: Hazard Warning Flasher Switch
Instruments and controls Hazard warning flasher switch Fog lamp switch In case of vehicles with Daytime Running Lamp, the front fog lamps can be operated E00506600596 E00506700034 Front fog lamp switch even if the lamp switch is set to the “OFF” Use the hazard warning flasher switch when the position.
Page 134: Wiper And Washer Switch
Instruments and controls Wiper and washer switch NOTE AUTO- Auto-wiper control The rear fog lamp is automatically turned off Rain sensor E00507101726 when the headlamps or front fog lamps are The wipers will automatically operate turned off. depending on the degree of wetness on CAUTION To turn the rear fog lamp on again, turn the the windscreen.
Page 135 • When using an automatic car wash. “-”- Lower sensitivity to rain lever to the “OFF” position. • A physical shock is applied to the Contact a MITSUBISHI MOTORS Author- windscreen. ized Service Point when replacing the wind- NOTE • A physical shock is applied to the rain...
Page 136 • Vehicles for Russia and Ukraine, the the “ON” position. ation of the lever. wipers can be set to operate again after about 6 seconds. For further information, we recommend you to consult a MITSUBISHI MOTORS Au- thorized Service Point. 3-46 OCZE14E3...
Page 137: Headlamp Washer Switch
Instruments and controls Headlamp washer switch Rear window demister switch Precautions to observe when using wipers and washers E00507800205 E00507901115 The headlamp washer can be operated with the ig- The rear window demister switch can be operated E00510000025 nition switch in the “ON” or “ACC” position and If the moving wipers become blocked by ice when the engine is running.
Page 138: Horn Switch
Instruments and controls Horn switch When cleaning the inside of the rear win- dow, use a soft cloth and wipe lightly along E00508000448 the heater wires, being careful not to damage Press the steering wheel on or around the “ ”...
Page 139 Starting and driving Economical driving...............4-02 Driving, alcohol and drugs............4-02 Safe driving techniques..............4-03 Running-in recommendations............4-03 Parking brake................4-04 Parking..................4-05 Steering wheel height adjustment..........4-06 Inside rear-view mirror..............4-06 Outside rear-view mirrors.............4-07 Ignition switch................4-09 Steering wheel lock..............4-10 Starting and stopping the engine..........4-11 Turbocharger operation..............
Page 140: Economical Driving
Starting and driving Economical driving Driving, alcohol and drugs Speed At higher the vehicle speed, more fuel is con- E00600100819 E00600200067 For economical driving, there are some technical Driving after drinking alcohol is one of the most sumed. Avoid driving at full speed. Even a slight requirements that have to be met.
Page 141: Safe Driving Techniques
Starting and driving Safe driving techniques Running-in recommendations E00600300433 E00600401343 Driving safety and protection against injury cannot For future performance and economy of your vehi- be fully ensured. However, we recommend that cle, we recommend that you carry out the follow- you pay extra attention to the following: ing precautions.
Page 142: Parking Brake
Starting and driving Parking brake NOTE CAUTION Apply sufficient force to the parking brake E00600501344 lever to hold the vehicle stationary after the To park the vehicle, first bring it to a complete Before driving, be sure that the parking foot brake is released.
Page 143: Parking
Starting and driving Parking NOTE When leaving the vehicle If your vehicle is equipped with Twin Clutch Always carry the key and lock all doors when leav- E00600601390 SST, be sure to apply the parking brake be- To park the vehicle, fully engage the parking ing the vehicle unattended.
Page 144: Steering Wheel Height Adjustment
Starting and driving Steering wheel height adjustment Inside rear-view mirror To adjust the vertical mirror position It is possible to move the mirror up and down to E00600700378 E00600800861 1. Release the tilt lock lever while holding the Adjust the rear-view mirror only after making any adjust its position.
Page 145: Outside Rear-View Mirrors
Starting and driving Outside rear-view mirrors To reduce the glare Except for vehicles equipped with the mirror retractor switch The lever (A) at the bottom of the mirror can be E00600900501 used to adjust the mirror to reduce the glare from To adjust the mirror position the headlamps of vehicles behind you during night driving.
Page 146 NOTE tor switch] while you are driving, taking away your Functions can be modified as stated below. rearward visibility. Consult a MITSUBISHI MOTORS Author- Retracting and extending the mirrors using the mirror retractor switch ized Service Point. NOTE With the ignition switch in the “ON” or “ACC” po-...
Page 147: Ignition Switch
The engine is stopped, but the electric devices such be deactivated. as the radio and cigarette lighter can be operated. For details, we recommend you to consult a MITSUBISHI MOTORS Authorized Service Point. The engine is running, and all the vehicle’s electric devices can be operated.
Page 148: Steering Wheel Lock
Starting and driving Steering wheel lock To remove the key CAUTION E00620400094 E00601500490 For vehicles with a M/T, when removing the key, [For vehicles equipped with the keyless opera- Do not remove the ignition key from the push the key in at the “ACC” position and keep it tion system] ignition switch while driving.
Page 149: Starting And Stopping The Engine
Starting and driving Starting and stopping the engine CAUTION WARNING E00620600155 Remove the key when leaving the vehicle. Never run the engine in a closed or poor- Tips for starting ly ventilated area any longer than is nee- In some countries, it is prohibited to leave Do not operate the starter motor continuous- ded to move your vehicle in or out of the the key on the vehicle when parked.
Page 150 Starting and driving On vehicles with Twin Clutch SST, make 1. Make sure that all electric devices, such as 2. Fully engage the parking brake while de- sure the gearshift lever is in the “P” (PARK) lamps, air conditioning blower and rear win- pressing the brake pedal.
Page 151: Turbocharger Operation
Starting and driving Turbocharger operation Turbocharger For vehicles with Twin Clutch SST, do not operate the gearshift lever or the accelerator The turbocharger increases engine power by push- E00611200038 pedal for approximately 1 second until the ing large amounts of air into the engine’s cylinders. engine stops.
Page 152: Clutch Pedal Operation
Starting and driving Clutch pedal operation Manual transmission* NOTE If either of the following occurs, we recom- E00611300039 E00602000421 Observe the following cautions when using the The shift pattern is shown on the gearshift lever mend you to have the clutch inspected. clutch pedal.
Page 153 Starting and driving If it is hard to shift into 1 , depress the clutch pedal again; the shift will then be eas- ier to make. To shift into reverse from 5 gear, move the gearshift lever to the “N” (Neutral) position, and then shift it into reverse.
Page 154 Starting and driving Possible driving speed E00610800763 Avoid shifting down at high speed, as this may cause excessive engine speed (the tachometer needle into the red zone) and damage the engine. Shift point Speed limit 60 km/h (37 mph) gear 90 km/h (56 mph) gear 120 km/h (74 mph)
Page 155: Twin Clutch Sst (Sport Shift Transmission)
Starting and driving Twin Clutch SST The gearshift lever (A) has 2 gates; the main shift gate (B) and the manual shift gate (C). (Sport Shift Transmission)* E00620900086 The Twin Clutch SST is a transmission that, through integrated control of the engine and trans- mission, is able to achieve both the smooth shifting of an automatic transmission and the acceleration and fuel economy close to a manual transmission.
Page 156 Starting and driving When the gearshift lever is operated while In addition, when the vehicle is driven with the The pull-ring (D) must be pulled up the Twin Clutch SST fluid temperature is gearshift lever in the “D” (DRIVE) position, the while the brake pedal is depressed to low, the time required to shift to the selected forward gear number is shown.
Page 157 “P” (PARK) or “R” (REVERSE) position curs repeatedly, have the vehicle checked by a Twin Clutch SST control mode or you will lose engine braking. MITSUBISHI MOTORS Authorized Service Point On a gradient the engine should be star- E00621300205 as soon as possible.
Page 158 Starting and driving NOTE Twin Clutch SST control mode switch Twin Clutch SST Characteristic E00621400192 Damage to your vehicle caused by racing control mode When the ignition switch is set to the “ON” posi- and/or driving on closed circuit tracks will Control mode for normal tion, operate the Twin Clutch SST control mode not be covered under warranty.
Page 159 Starting and driving Manual shift To shift from “S-Sport” mode to “Sport” mode CAUTION E00621600208 Using the gearshift lever (A) or the shift paddles To shift from “Sport” mode to “Normal” mode Sudden engine braking and rapid accel- (B), shifting can be performed manually. While the vehicle is stopped or being driven, push eration can cause the vehicle to skid.
Page 160 Starting and driving NOTE Shifting using the gearshift lever Shifting using the shift paddles After manual shifting is selected using the E00621700023 E00621800138 gearshift lever, shifting up and down can al- Selecting manual shifting Selecting manual shifting so be performed using the shift paddles. While the vehicle is stopped or being driven, move While the vehicle is stopped or being driven with the gearshift lever from the “D”...
Page 161 Starting and driving Shifting up Returning to “D” range operation Manual shift display Each time the + (SHIFT UP) shift paddle is pulled, When the gearshift lever is in the “D” (DRIVE) E00623500113 In manual shift, the currently selected gear is dis- the transmission shifts up 1 gear.
Page 162 MITSUBISHI MOTORS Authorized while traveling even if the accelerator 2. Place the gearshift lever in the “P” (PARK) Service Point.
Page 163 Starting and driving Uphill/downhill driving CAUTION CAUTION E00622200168 DRIVING UPHILL Use the gearshift lever in the correct shift • If the vehicle is continuously driven at The Twin Clutch SST may not upshift to a higher position in accordance with driving con- low speeds using the tendency of the shift position if the computer determines the cur- ditions.
Page 164 Starting and driving For longer waiting periods with the engine running, NOTE CAUTION place the gearshift lever in the “N” (NEUTRAL) On a slope, be sure to apply the parking position and apply the parking brake, while holding brake before moving the gearshift lever to •...
Page 165: Full-Time 4Wd
Starting and driving Full-time 4WD Refer to “Check engine warning lamp” on page CAUTION 3-34 and follow the appropriate measures. E00604900192 Full-time 4WD vehicles are propelled by engine When the Twin Clutch SST fluid temper- When the gearshift lever position display is not power distributed constantly and appropriately to ature is high, the engine idle speed when showing...
Page 166: Cautions On Handling Of 4-Wheel Drive Vehicles
Starting and driving Cautions on handling of 4-wheel CAUTION CAUTION drive vehicles Always use tyres of the same size, same Do not tow 4WD vehicles with the front E00606800687 type, and same brand, and which have no or rear wheels on the ground (Type A or Tyres and wheels wear differences.
Page 167: S-Awc (Super-All Wheel Control)
Starting and driving S-AWC (Super-All Wheel CAUTION CAUTION Control) Be sure to use tyres that are the same Control of the braking force does not en- E00622600032 specified size, type, and brand, and have hance the stopping performance of the S-AWC is an integrated vehicle dynamics control no difference in the amount of wear for vehicle, therefore, pay careful attention...
Page 168 Starting and driving Vehicles with steering wheel audio remote con- In addition, when the control mode is changed, the S-AWC control Operation trol switches selected mode appears on the interrupt display mode Each time the switch is pushed, the control mode screen of the information screen in the multi-infor- GRAVEL Use this control mode when...
Page 169 Starting and driving S-AWC warning display Display example NOTE The S-AWC operation status is displayed. If the ambient temperature drops and the vis- E00623200093 When there is a malfunction in the system, the cosity of the AWC control fluid increases, warning display will appear on the information the warning may be displayed.
Page 170: Anti-Lock Brake System (Abs)
Starting and driving Anti-lock brake system (ABS) The ABS can be used after the vehicle has Under normal conditions, the ABS warning lamp reached a speed over approximately 10 km/h only comes on when the ignition switch is turned E00607101046 (6 mph).
Page 171: Active Stability Control (Asc)
Starting and driving Active stability control (ASC) After driving on icy roads If the ABS warning lamp/display and brake warn- ing lamp/display illuminate at the same time E00618800091 E00616700139 After driving on snow or icy roads, remove any The Active Stability Control (ASC) takes overall Warning lamp snow and ice which may have be left around the control of the anti-lock brake system, traction con-...
Page 172 Starting and driving Stability control function NOTE CAUTION An operation noise may be emitted from the E00619100017 The stability control function is designed to help engine compartment in the following situa- Be sure to turn ON the ASC for normal the driver maintain control of the vehicle on slip- tions.
Page 173: Braking
Starting and driving Braking If the “ASC OFF” switch is continuously When a compact spare tyre has been put on pressed after the ASC has been turned OFF your vehicle, the gripping ability of the tyre E00607001508 or the ASC and the braking control of AYC will be lower, making it more likely that the All the parts of the brake system are critical to have been turned off, an erroneous operation...
Page 174: Brake Assist System
Starting and driving Brake assist system WARNING WARNING E00627000480 The brake assist system is a device assisting drivers If the power assist is lost or if either Do not leave any objects near the brake who cannot depress the brake pedal firmly when it brake hydraulic system stops working pedal or let a floor mat slide under it;...
Page 175: Power Steering System
Starting and driving Power steering system Cruise control* When the brake assist system is in use, you may feel as if the depressed brake pedal is E00607400417 E00609101170 soft, the pedal moves in small motions in The power steering system operates while the en- Cruise control is an automatic speed control system conjunction with the sound of the ABS oper- gine is running.
Page 176 Starting and driving Cruise control switches To activate 2. Confirm that the Twin Clutch SST control mode is set to “Normal” (on vehicles with E00624100044 E00609301231 1. With the ignition switch in the “ON” posi- Twin Clutch SST). Refer to “Twin Clutch tion, press the “ON OFF”...
Page 177 Starting and driving “ACC RES” switch Accelerator pedal When you reach your desired speed, release the Press and hold the “ACC RES” switch (C) while While driving at the set speed, use the accelerator switch. Your new cruising speed is now set. driving at the set speed, and your speed will then pedal to reach your desired speed and then press gradually increase.
Page 178 Starting and driving Brake pedal To temporarily decrease the speed Depress the brake pedal. While driving at the set speed, use the brake pedal, Depress the brake pedal to decrease the speed. To which disengages the cruise control, then press the return to the previously set speed, press the “ACC “COAST SET”...
Page 179: Cargo Loads
The “ON OFF” switch is pressed. the cruise control and have your vehicle The ignition switch is turned OFF. Use a roof carrier that properly fits your inspected by a MITSUBISHI MOTORS vehicle. “CRUISE” indication lamp is turned OFF. Authorized Service Point.
Page 180 CAUTION to be used have a special shape. For details, recommend consult MITSUBISHI MOTORS Authorized Service Make sure that the weight of the luggage Point. does not exceed the allowable roof load. If the allowable roof load is exceeded, this Roof carrier mounting brackets may cause damage to the vehicle.
Page 181: Rear-View Camera
Starting and driving Rear-view camera* NOTE Location of rear-view camera To prevent wind noise or reduction in fuel The rear-view camera (A) is built-in to the trunk E00618400534 economy, remove the roof carrier when not lid. The rear-view camera is a system that shows the in use.
Page 182 Starting and driving • Low light (nighttime) • When the light of the sun or the light from a vehicle’s headlamps shines direct- ly into the lens If the camera is hot and is then cooled by rain or a car wash, the lens can mist up. This phenomenon does not indicate a malfunc- tion.
Page 183: Trailer Towing
Starting and driving Trailer towing • When the rear of the vehicle is weighed The reference lines for distance and vehicle down with the weight of passengers and width are intended to indicate the distance to E00610000244 luggage in the vehicle. a flat object such as a level, flat road surface.
Page 184 OCZE14E3...
Page 185 For pleasant driving Ventilators..................5-02 Storage spaces................5-62 Automatic air conditioning............5-04 Cup holder..................5-64 Important operation tips for the air conditioning......5-08 Bottle holder................. 5-65 Air purifier..................5-09 Assist grip..................5-65 LW/MW/FM radio/CD player*............5-09 Coat hook..................5-66 Handling of Discs................. 5-12 Audio Files (MP3/WMA/AAC)........... 5-13 Important Points on Safety for the Customer.......
Page 186: Ventilators
For pleasant driving Ventilators NOTE To close the ventilator, move the knob (A) to the inside as far as possible. The cool air from the ventilators may appear E00700100777 as a mist. This is due to moist air being suddenly Left Right cooled by the air conditioning.
Page 187 For pleasant driving Changing the mode selection Foot/Face position Foot position Air flows to the upper part of the passenger com- Air flows mainly to the leg area. E00700301330 To change the position and amount of air flowing partment, and flows to the leg area. from the ventilators, turn the mode selection dial.
Page 188: Automatic Air Conditioning
For pleasant driving Automatic air conditioning NOTE With the mode selection dial between the E00702400367 “ ” and “ ” positions, air flows mainly to The air conditioning can only be used while the en- the leg area. With the mode selection dial be- gine is running.
Page 189 For pleasant driving Temperature control dial The settings described above are the factory set- CAUTION tings. The air selection and air conditioning E00703000399 Turn the temperature control dial clockwise or an- switches can be customised (function setting Normally, use the outside position to keep ticlockwise.
Page 190 For pleasant driving Enable automatic air control: A sound will be made every time you push the NOTE If the mode selection dial or blower speed switch. If a problem is detected in the air condition- selection dial is turned to the “AUTO” posi- ing system, the air conditioning operation in- tion, the air selection switch is also control- dication lamp (A) blinks.
Page 191 For pleasant driving When the setting is changed, a sound is emit- 1. Set the blower speed selection dial to the If the blower speed selection dial, air condi- ted and the indication lamp flashes. “AUTO” position. tioning switch, mode selection dial, or air se- •...
Page 192: Important Operation Tips For The Air Conditioning
For pleasant driving Important operation tips for the For ordinary demisting For quick demisting Use this setting to keep the windscreen and door air conditioning windows clear of mist, and to keep the leg area E00708300603 heated. Park the vehicle in the shade. Parking in the hot sun will make the vehicle inside extremely hot, and it will require more time to cool the interior.
Page 193: Air Purifier
For pleasant driving Air purifier LW/MW/FM radio/CD player* It is recommended that the refrigerant be recovered and recycled for further use. E00708400473 E00708502335 An air filter has been incorporated into this air con- The audio system can only be used when the igni- During a long period of disuse ditioning so that dirt and dust are cleaned from the tion switch or the operation mode is in ON or...
Page 194 For pleasant driving Important Points on Usage Trademarks by the developer to meet Apple performance standards. E00735500023 E00735800026 Product names and other proper names are iPhone, iPod, iPod classic, iPod nano, and iPod/iPhone Playback Function* the trademarks or registered trademarks of iPod touch are trademarks of Apple Inc., reg- This product supports audio playback from their respective owners.
Page 195 For pleasant driving 5th generation 5th generation (video) (video) 6th generation 5th generation 4th generation (video) (video camera) 3rd generation 2nd generation 1st generation (video) (aluminium) 5-11 OCZE14E3...
Page 196: Handling Of Discs
For pleasant driving Handling of Discs Important Points on Storage When not using discs, ensure these are kept E00735900027 This explains care that should be taken in the han- in cases, and stored out of direct sunlight. dling of discs. If discs are not going to be used for a long period of time, remove these from the prod- Important Points on Handling...
Page 197: Audio Files (Mp3/Wma/Aac)
For pleasant driving Type Size Maximum playback time Comments CD-R/RW 12 cm — •Disc containing MP3 files Audio Files (MP3/WMA/AAC) Discs That May Not Be Played Back Playback of other than standard CDs is not Playback of discs other than those described guaranteed.
Page 198 For pleasant driving Files larger than 2GB in size cannot be You can create a folder structure as in Genre - Ar- CAUTION played back. tist - Album - Track (MP3/WMA/AAC format au- dio files) for management of tracks. Do not append the file extensions “.mp3”, Data Formats That Can Be Played “.wma”, or “.m4a”, to other than Back...
Page 199 For pleasant driving Name Specification Explanation Maximum 64 bytes (for Unicode, 32 characters), files/folders with file/folder names longer than this will not be displayed File name and folder name restrictions or played back. The recommended file system is FAT32. USB supported formats 1 partition only : Do not include other than MP3/WMA/AAC files.
Page 200 For pleasant driving CAUTION Item Details Item Details Sampling Maximum 64 characters MPEG4 8/11.025/12/16/22.05/2 WMA supports digital rights manage- frequency number of 4/32/44.1/48 ment (DRM). This product cannot play [kHz] characters that MPEG2 8/11.025/12/16/22.05/2 back WMA files protected using this sys- can be indica- 4/32/44.1/48 tem.
Page 201: Important Points On Safety For The Customer
For pleasant driving Important Points on Safety for Operation Keys WARNING the Customer E00737100023 Turn the Power ON/ OFF In the event of abnormalities occurring E00737000035 E00737200024 when foreign objects or water enter the This product features a number of pictorial indica- 1.
Page 202 For pleasant driving Push the disc in a certain amount, and the product will pull the disc in, and playback will start. 2. Press the key. This will eject the disc from the product, so remove the disc. CAUTION When replacing discs, first ensure that the vehicle is stopped in an area in which Turn the PWR/VOL key clockwise to in- stopping is permitted.
Page 203 For pleasant driving Explanation of Buttons E00737500069 This explains names and functions of each part. 8- DISP key Switch the content of the display. Use to eject a disc. 9- PTY/SCAN key 2- 3 key/4 For audio, play scan playback; for radio, search PTY. For audio, rewind/fast forward.
Page 204 For pleasant driving key/ /SEL key For audio, select audio track/file; for radio, perform automatic station se- Adjust audio quality and select items. lection. For radio, manually select stations. 16- MENU key Switch to Menu mode. ® Requires a separately-purchased Bluetooth-capable audio device in equipment by type (vehicles with a Bluetooth 2.0 interface).
Page 205: Listen To Radio
For pleasant driving Listen to Radio Steering wheel audio remote control switches* E00737700032 This explains how to listen to FM, MW, and LW CD or MP3 E00737600099 radio broadcasts. iPod or USB device Bluetooth Audio To Listen to the Radio FM1, 2, 3 Press the RADIO key to switch the band.
Page 206: Listen To Dab
For pleasant driving Listen to DAB* PTY Search 2. Hold down any of the keys from the 1RPT key to the 6 key. Select PTY (program content), and automatically E00739100014 This explains how to listen to DAB. scan for stations. A “Beep”...
Page 207: Listen To Traffic Messages
For pleasant driving Listen to Traffic Messages Register the Service 1. Press the PTY/SCAN key. This switches to the PTY selection mode. Register the service in advance, and select this at a E00739200015 2. Turn the /SEL key to select PTY. This explains how to listen to traffic messages.
Page 208: Listen To Cds
For pleasant driving Listen to CDs 2. When not in MW or LW mode, press the TP Selecting a track, ejecting, fast forwarding, key. or rewinding will cancel. E00737800059 “TP” disappears from the display, and stand- This explains how to listen to audio CDs (CD- Random Playback (RDM) by mode will be cancelled.
Page 209: Listen To Mp3S
For pleasant driving Listen to MP3s Scan Playback (SCAN) Repeat playback of the track currently being Press the SCAN key. E00737900034 played. This explains how to listen to audio files on a disc. Play the first 10 seconds of each of the tracks in the folder currently being played in order.
Page 210: Listen To An Ipod
For pleasant driving Listen to an iPod Regarding how to connect the iPod/iPhone, If an iPod/iPhone does not operate correctly, refer to “How to connect an iPod” on page then remove the iPod/iPhone from the prod- E00738000045 5-56. uct, reset, then reconnect. By connecting commercially-available iPod/iPhone When connecting the iPod/iPhone, use a devices to this product, you can play back tracks on...
Page 211: Listen To Audio Files On A Usb Device
For pleasant driving Listen to Audio Files on a USB NOTE While the track is selected, press the 6 Pressing again will cancel. key to return to the previous operation. Device While the track is selected, hold down the 6 E00736500062 Album Shuffle Playback key to cancel track search mode.
Page 212 For pleasant driving NOTE Regarding details of types of files that can be Depending on the type of USB device, usage played back in equipment by type (vehicles may not be possible, or functions that can be Pressing again will cancel. ®...
Page 213: Listen To Bluetooth Audio
For pleasant driving Listen to Bluetooth Audio* If there is no operation for 10 seconds after Play the first 10 seconds of each of the tracks on selecting the folder, then track search mode E00736700077 the whole USB device in order. will be cancelled.
Page 214 For pleasant driving NOTE NOTE Bluetooth audio device specifications and settings may mean that connection is not Pressing again will cancel. Hold down the 5 key to pause. possible, or result in differences in operation Press the 6 key to stop. or display.
Page 215: Display Indicator
For pleasant driving Display Indicator E00738100033 This explains content of the display indicator. 5-31 OCZE14E3...
Page 216 For pleasant driving Change the Display Mode NOTE NOTE If there is no text information to display, If there is no text information to display, E00738500037 You can change the content of the display indica- then “NO TITLE” is displayed. then “NO TITLE”...
Page 217: Audio Quality And Volume Balance Adjustment
For pleasant driving Audio Quality and Volume System Settings Turn counter-clock- Turn clockwise just- wise Balance Adjustment E00738300051 Change system settings such as product time. ment E00738200021 1. Press the MENU key. items Change audio quality settings. 2. Press the /SEL key to select settings OFF, LOW MID, HIGH...
Page 218 For pleasant driving Settings con- Settings con- Settings con- Settings name Settings value Settings name Settings value Settings name Settings value tent tent tent L-BAND Set used broad- REG OFF Automatically FRANCAIS Set the display cast band to track the local language for 1452 to 1490 station for the...
Page 219 For pleasant driving NOTE Settings con- Settings value Settings content Settings name Settings value Cancel functions such as the mobile phone tent Do not use mobile phone “dial lock”, and connect while on the stand- PHONE OFF CT OFF Do not update voice cut-in.
Page 220 For pleasant driving Settings Settings name Settings content value PHONE IN set- PHONE During mobile tings IN-L phone voice cut- in, output sound from the left front speaker. HFM voice lan- ENGLISH Change the hands guage settings free module voice FRENCH language.
Page 221: Troubleshooting
Turn the power OFF and wait a short while. If the problem per- USB BUS PWR There is high or low electrical current or voltage. sists, consult a MITSUBISHI MOTORS Authorized Service LSI ERROR There is an internal malfunction for some reason.
Page 222 ERROR DC An abnormal direct voltage has been sent to the speakers. Turn the power OFF and wait a short while. If the problem persists, consult a MITSUBISHI MOTORS Authorized Serv- ice Point. If You Think Something Is Not Working Properly...
Page 223: Antenna
Turn the pole (A) anticlockwise. E00764600013 You have acquired a device that includes software licensed by MITSUBISHI MOTORS CORPORA- TION from JOHNSON CONTROLS Inc (the auto- motive experience business unit), and their subse- quent 3 party suppliers. For a complete list of...
Page 224: Bluetooth ® 2.0 Interface
® Although the Bluetooth 2.0 interface al- MITSUBISHI MOTORS website. lows you to make hands-free calls, if you Please read and agree on the “Warning about choose to use the cellular phone while Links to the Web Sites of Other Companies”...
Page 225 For pleasant driving 1- Volume up button • To establish a three-way call in such sit- NOTE 2- Volume down button uations, press the SPEECH button to en- If a cellular phone is brought close to the mi- 3- SPEECH button ter voice recognition mode and then say crophone, it may create noise in the voice on 4- PICK-UP button...
Page 226 For pleasant driving Selecting the Language If you say “Help” when the system is waiting for a Security function 1. Press the SPEECH button. voice command input, the system will tell you a list E00760500144 It is possible to use a password as a security func- 2.
Page 227 If you do not start the speaker enrollment “Cancel” to quit the voice input mode and Speaker enrollment process within 3 minutes after pressing the then check with a MITSUBISHI MOTORS E00727500213 SPEECH button, the speaker enrollment Authorized Service Point.
Page 228 For pleasant driving 5. The voice guide will prompt for phrase 1. 2. Say “Voice training”. ® If multiple paired Bluetooth devices are available Repeat the corresponding phrase listed in ta- 3. If you have completed a speaker enrollment in the vehicle, the cellular phone or music player ble “Enrollment Commands”...
Page 229 For pleasant driving NOTE 9. The voice guide will say “Pairing complete,” ® for instructions.” Enter in the Bluetooth If 7 devices have already been paired, the after which a beep will be played and the vice the 4-digit number you have registered voice guide will say “Maximum devices pairing process will end.
Page 230 For pleasant driving NOTE NOTE 5. The selected music player will be connected You can connect to a phone at any time by If the device deletion process fails for some ® to the Bluetooth 2.0 interface. pressing the SPEECH button and saying the reason, the voice guide will say “Delete The voice guide will say “<device tag>...
Page 231 For pleasant driving You can change the device tag by pressing 6. The voice guide will say “New name, NOTE and releasing the SPEECH button and then please.” Say the name you want to register as The hands-free calls might not be operated saying “Edit”...
Page 232 For pleasant driving The maximum supported telephone number Answer “No,” the name of the next matching If the name you selected has matching data length is as follows: person will be uttered by the voice guide. in the mobile phone book but no telephone •...
Page 233 For pleasant driving For example, if during a call you need to simulate Switching between hands-free mode and private You can register a desired name as a name for any the pressing of a phone button as a response to an phone book entry registered in the vehicle phone mode automated system, press the SPEECH button and...
Page 234 For pleasant driving NOTE NOTE 3. The voice guide will say “Select one of the When the confirmation function is on, the following: new entry, edit number, edit When the confirmation function is on, after voice guide will say “<Location>. Is this cor- name, list names, delete, erase all, or import repeating the telephone number you have rect?”...
Page 235 For pleasant driving NOTE 10. The voice guide will say “Would you like to 5. The voice guide will say “Home, work, mo- import another contact?” bile or other?” Select and say the location ® If the Bluetooth 2.0 interface cannot recog- Answer “Yes”...
Page 236 For pleasant driving NOTE 1. Press the SPEECH button. 4. Bluetooth ® 2.0 interface will read out the en- 2. Say “Phone book.” Say “List names,” and the names registered tries in the phone book in order. 3. The voice guide will say “Select one of the in the phone book will be read out in order.
Page 237 For pleasant driving Erasing the phone book The maximum supported telephone number You can delete all registered information from the length is 19 digits. Any telephone number of ® The Bluetooth 2.0 interface automatically con- vehicle phone book. 20 digits or more will be truncated to the verts from text to voice the names registered in the 1.
Page 238 For pleasant driving If you press the HANG-UP button or press and hold the SPEECH button during the data transfer, the transfer will be cancelled and the system will return to the main menu. If an error occurs during the data transfer, all transfer will be cancelled and the voice guide will say “Unable to complete the phone book import”...
Page 239 For pleasant driving Enrollment commands E00732400210 Phrase English French Spanish Italian German Dutch Portuguese Russian 1 123456789 123456789 123456789 123456789 123456789 123456789 123456789 123456789 2 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212 888 555 1212...
Page 240: Usb Input Terminal
For pleasant driving USB input terminal* 3. Connect a commercially available USB con- CAUTION nector cable (C) to the USB memory device E00761900060 (B). You can connect your USB memory device or Keep the lid of the glove box closed while iPod* to play music files stored in the USB memo- driving the vehicle.
Page 241 For pleasant driving 3. Connect the Dock connector (C) to the iPod CAUTION Model name Condition (B). iPod nano (second gen- F/W Ver.1.1.2 or later Keep the lid of the glove box closed while eration) driving the vehicle. A lid or the contents Models other than USB Digital audio...
Page 242: Sun Visors
For pleasant driving Sun visors Card holder File specifications E00762400017 E00732000098 E00711200521 You can play music files of the following specifi- Cards can be slipped into the holder (A) on the cations that are saved in a USB memory device or back of the sun visor.
Page 243: Ashtray
For pleasant driving Ashtray* Cigarette lighter* Mounting position for moveable ash- tray E00711400855 E00711501299 The cigarette lighter can be used while the ignition The moveable ashtray can be fitted at the indicated switch is in the “ON” or “ACC” position. positions.
Page 244: Accessory Socket
30 seconds of being push- ed in. Pull it out and have the problem correc- ted at MITSUBISHI MOTORS Author- ized Service Point. When the cigarette lighter socket is used as a power source for an electric appli- ance, be sure that the electric appliance 1- Front room &...
Page 245 It goes E00712300516 The room lamp can be turned on by sliding the MITSUBISHI MOTORS Authorized Service off about 15 seconds after all room lamp switch. Point. doors are closed. However, the lamp goes off im-...
Page 246: Storage Spaces
2 ( ) - justed. details, please consult door is opened. E00713101462 MITSUBISHI MOTORS Authorized Service It goes off about 15 seconds after Point. all doors are closed. CAUTION However, the lamp goes off imme- diately in the following cases: 3 (OFF) - The lamp goes off.
Page 247 For pleasant driving Card holder Lower box There is a card holder on the inside of the glove box. 1- Glove box 2- Front console boxes 3- Floor console box 4- Luggage floor boxes NOTE Do not use the front console boxes as an ash- Glove box NOTE tray.
Page 248: Cup Holder
For pleasant driving Cup holder Tissue holder Except for vehicles equipped with spare tyre The tissue holder (B) is located on the back of the E00714501098 floor console box lid. CAUTION Do not drink beverages while driving the vehicle; doing so could distract you and result in an accident.
Page 249: Bottle Holder
For pleasant driving Bottle holder Assist grip For the rear seat E00716900376 E00718200142 E00732800083 In order to use the cup holder, allow the armrest These grips are to support the body by hand while (A) to drop down. seated in the vehicle. CAUTION Do not drink beverages while driving the vehicle;...
Page 250: Coat Hook
For pleasant driving Coat hook E00725600281 There is a coat hook on the rear seat assist grip of the driver’s side. WARNING Do not put a hanger or any heavy or pointed object on the coat hook. If the curtain airbag was activated, any such item could be propelled away with great force and could prevent the curtain air- bag from inflating correctly.
Page 251 For emergencies If the vehicle breaks down............6-02 Emergency starting............... 6-02 Engine overheating............... 6-04 Tools, jack and tyre repair kit............6-05 How to change a tyre..............6-12 Towing..................6-17 Operation under adverse driving conditions.........6-19 OCZE14E3...
Page 252: If The Vehicle Breaks Down
For emergencies If the vehicle breaks down Emergency starting 2. Set the parking brake firmly on each vehicle. Put an A/T or Twin Clutch SST in “P” E00800101195 E00800502196 (PARK) or a M/T in “N” (Neutral). Turn off If the vehicle breaks down on the road, move it to If the engine cannot be started because the battery the ignition switch.
Page 253 For emergencies 5. Connect one end of one jumper cable to the WARNING WARNING positive (+) terminal of the joint terminal (B), and the other end to the positive (+) ter- When connecting the jumper cable, do sure have MITSUBISHI minal of the booster battery (C).
Page 254: Engine Overheating
For emergencies Engine overheating NOTE If the vehicle is put in motion without fully E00800602748 charging the battery, it might cause the loss When the engine is overheating, the information of smooth engine operation and the anti-lock screen in the multi-information display will be in- brake warning lamp to illuminate.
Page 255: Tools, Jack And Tyre Repair Kit
For emergencies Tools, jack and tyre repair kit 4. When the bar graph in the engine coolant WARNING temperature warning display in the multi-in- E00800901223 formation display drops, stop the engine. If there is none, make sure that the en- Storage gine has cooled down before removing The tools, jack and tyre repair kit are stowed in the...
Page 256 For emergencies Jack Tyre repair kit* Vehicles with tyre repair kit E00802000306 E00802200425 Before removing the jack, lift up the luggage floor This kit enables emergency repair of a small punc- board. ture in the tread area of a tyre that has run over a nail, screw, or similar object.
Page 257 For emergencies Use the tyre sealant only at ambient tempera- CAUTION tures of -30 °C to + 60 °C. Effect an emergency repair without pulling The tyre sealant can cause health damage out the object (nail, screw, etc.) that is stuck if swallowed.
Page 258 For emergencies CAUTION If you shake the bottle after screwing on the hose, sealant may spray out of the hose. 8. Take the valve cap (F) off the tyre valve (G), then press the valve remover (H) onto the valve as illustrated. Allow all of the air in the tyre to escape.
Page 259 For emergencies 11. Holding the sealant bottle upside-down, Fit the valve insert (I) into the valve (G), and 14. Place the compressor (M) with its air pres- squeeze it again and again to inject all of the screw the valve insert securely into place us- sure gauge (N) on top.
Page 260 Drive with The surface of the compressor will get great care to a MITSUBISHI MOTORS Au- great care. Do not exceed a speed of 80 km/h hot while the compressor is running. Do (50 mph).
Page 261 80 km/h (50 mph). Observe local speed lim- MITSUBISHI MOTORS Authorized Service MITSUBISHI MOTORS Authorized its. Point or another specialist. Note that a proper Service Point or another specialist. Oth-...
Page 262: How To Change A Tyre
For emergencies How to change a tyre WARNING CAUTION E00801202464 Before changing a tyre, first stop your vehicle in a Be sure to apply chocks or blocks to the The pressure should be periodically safe, flat location. correct tyre when jacking up the vehicle. checked and maintained at the specified 1.
Page 263 For emergencies CAUTION CAUTION Do not use tyre chains with your compact Do not install more than one compact spare wheel. Because the diameter is dif- spare wheel at the same time. ferent from that of a standard type, the tyre chain will not fit properly.
Page 264 For emergencies 3. Rotate the jack by hand until the flange por- WARNING tion (B) fits in the groove (C) at the top of the jack. Stop jacking up the vehicle as soon as the tyre is raised off the ground. It is danger- ous to raise the vehicle any higher.
Page 265 For emergencies Tighten the wheel nuts until the flang- CAUTION es of the wheel nuts touch the wheel and the wheel is not loose. Never apply oil to either the wheel bolts or the nuts, or they will tighten too much. NOTE Flange nuts can be temporarily used on the steel spare wheel, but return to the original...
Page 266 For emergencies (Achieved by applying a force of 350 to 2. To store the flat tyre or spare wheel, fit the 420 N at the end of the wheel nut wrench installation clamp (A) by turning it clock- supplied with the vehicle.) wise.
Page 267: Towing
If towing is necessary, we recommend you to have This vehicle must not be towed by a tow it done by your MITSUBISHI MOTORS Author- Type A truck using sling lift type equipment ized Service Point or a commercial tow truck serv- (Type A) as illustrated.
Page 268 For emergencies 2. Cover the tip of the jack bar with a cloth, CAUTION CAUTION then use it to remove the cover (A) that is lo- cated on the front bumper. Do not tow the vehicle with the rope at an When the engine is not running, the excessive diagonal angle.
Page 269: Operation Under Adverse Driving Conditions
For emergencies Operation under adverse driving Depressing the brake pedal during travel on CAUTION snowy or icy roads may cause tyre slippage conditions and skidding. When traction between the When towing or being towed down a long E00801702573 tyres and the road is reduced the wheels may slope, the brakes may overheat reducing skid and the vehicle cannot readily be On a flooded road...
Page 270 For emergencies CAUTION The vehicle’s body, bumper, muffler and other parts may be damaged if the vehi- cle is: • driven over a step (for example, at the entrance or exit of a parking lot); • parked too closely against a kerb or parking block, or by the side of a road with kerbstones;...
Page 271 Vehicle care Vehicle care precautions...............7-02 Cleaning the interior of your vehicle..........7-02 Cleaning the exterior of your vehicle........... 7-03 OCZE14E3...
Page 272 Vehicle care Vehicle care precautions Cleaning the interior of your NOTE Do not use cleaners, conditioners, and pro- vehicle E00900100900 In order to maintain the value of your vehicle, it is tectants containing silicones or wax. E00900200552 necessary to perform regular maintenance using the Such products, when applied to the instru- After cleaning the interior of your vehicle with wa- proper procedures.
Page 273 Vehicle care Cleaning the exterior of your NOTE CAUTION If genuine leather is wet with water or is vehicle washed in water, wipe off water as quickly When washing the under side of your ve- E00900700111 as possible with a dry, soft cloth. If left hicle or wheel, be careful not to injure If the following is left on your vehicle, it may damp, mildew may grow.
Page 274 Vehicle care CAUTION CAUTION CAUTION • Maintain a distance of approx. 50 cm • As your vehicle has rain sensor wip- Waxes containing high abrasive com- or more between the vehicle body and ers, place the wiper switch lever in the pounds should not be used.
Page 275 Vehicle care Cleaning plastic parts 2. Use neutral detergent on any dirt that cannot NOTE be removed easily with water. To clean the inside of the rear window, al- E00901300752 Use a sponge or chamois leather. Rinse off the neutral detergent after washing ways use a soft cloth and wipe the window If a car wax adheres on a grey or black rough sur- the wheel.
Page 276 OCZE14E3...
Page 277 Maintenance Service precautions...............8-02 Catalytic converter................8-02 Bonnet...................8-03 Engine oil..................8-04 Engine coolant................8-05 AWC control fluid................ 8-06 Washer fluid................. 8-07 Brake fluid/Clutch fluid*..............8-07 Power steering fluid..............8-08 Battery..................8-08 Tyres..................... 8-09 Parking brake break-in..............8-13 Wiper blade rubber replacement...........8-14 General maintenance..............8-14 For cold and snowy weather............8-15 Fusible links..................8-15 Fuses.....................
Page 278: Service Precautions
Maintenance Service precautions Catalytic converter WARNING E01000101051 E01000201137 Adequate care of your vehicle at regular intervals For ordinary use, there are no particular precau- When checking or servicing the inside of serves to preserve the value and appearance as long tions except that unleaded petrol should be used.
Page 279: Bonnet
Maintenance Bonnet E01000302441 CAUTION To avoid the risk of being burned, do not touch the air outlets (A) and air scoop (B) on the bonnet when the engine compart- ment is hot (when the engine is running or immediately after the vehicle has been driven).
Page 280: Engine Oil
Maintenance Engine oil CAUTION CAUTION E01000402859 After inserting the support bar into the Before driving, make sure that the bon- To check and refill engine oil slot, make sure the bar supports the bon- net is securely locked. An incompletely net securely from falling down on to your locked bonnet can suddenly open while head or body.
Page 281: Engine Coolant
Maintenance Engine coolant 7. If the oil level is below the specified limit, Select engine oil of the proper SAE viscosity remove the cap located on the cylinder head number according to the atmospheric tem- E01000502124 cover and add enough oil to raise the level to perature.
Page 282: Awc Control Fluid
Do not top up with water only. Use “MITSUBISHI MOTORS GENUINE SUPER LONG LIFE COOLANT PREMIUM” or equiva- During cold weather lent*. The engine coolant mixture used at the factory pro-...
Page 283: Washer Fluid
Maintenance Washer fluid Brake fluid/Clutch fluid* If the level is low, replenish the container with washer fluid. E01000700773 E01000800556 The brake fluid and the clutch fluid share the reser- Windscreen washer voir tank. The windscreen washer fluid reservoir is in the To check the fluid level trunk.
Page 284: Power Steering Fluid
“MAX” Do not mix or add different brand of Be sure to have a MITSUBISHI MOTORS Au- and “MIN” level markings on the fluid reservoir brake fluid to prevent chemical reaction. thorized Service Point check the battery.
Page 285: Tyres
We recommended you have the battery and charg- could cause it to overheat and be dam- loss of control or blow out of the tyres ing system checked by a MITSUBISHI MOTORS aged. which can result in a collision with seri-...
Page 286 Maintenance Tyre inflation pressures E01001402869 Normal loading Above 160 km/h (99 mph) Item Tyre size Front Rear Front Rear 2.2 bar (32 psi) {220 2.0 bar (29 psi) {200 2.5 bar (36 psi) {250 2.3 bar (33 psi) {230 Normal tyre 245/40R18 93Y kPa} kPa}...
Page 287 Maintenance Wheel condition Tyre rotation CAUTION E01001800579 E01001901492 Tyre wear varies with vehicle conditions, road sur- Always use tyres of the same size, same face conditions and individual driver’s driving hab- type, and same brand, and which have no its. To equalize the wear and help extend tyre life, wear differences.
Page 288 Maintenance When rotating tyres, check for uneven wear and CAUTION CAUTION damage. Abnormal wear is usually caused by in- correct tyre pressure, improper wheel alignment, A compact spare tyre can be fitted tem- Avoid the combined use of different types out of balance wheel, or severe braking.
Page 289: Parking Brake Break-In
Before fitting tyre chains, we recommend you to cient or whenever the parking brake linings and/or If one of the rear wheels has punctured, consult a MITSUBISHI MOTORS Authorized discs are replaced, in order to assure the best brake replace it with one of the front wheels Service Point.
Page 290: Wiper Blade Rubber Replacement
Maintenance Wiper blade rubber replacement General maintenance 4. Insert the wiper blade into the arm, starting with the opposite end of the blade from the E01008200093 E01002700504 stopper. Make sure the hook (B) is fitted cor- 1. Lift the wiper arm off the windscreen. Fuel, engine coolant, oil and exhaust rectly in the grooves in the blade.
Page 291: For Cold And Snowy Weather
Maintenance For cold and snowy weather Fusible links Hinges and latches lubrication Check all latches and hinges, and, if necessary, E01002800257 E01002900580 The fusible links will melt to prevent a fire if a have them lubricated. Ventilation slots large current attempts to flow through certain elec- trical systems.
Page 292: Fuses
Maintenance Fuses 1. Open the fuse lid and pull to remove it. WARNING E01003002117 When changing fuses, do not damage the Fuse block location driver’s knee airbag harness or acciden- To prevent damage to the electrical system due to tally strike the airbag area with hard ob- shortcircuiting or overloading, each individual cir- jects.
Page 293 Maintenance Passenger compartment (RHD vehicles) 2. Move the rod (A) on the left side of the 4. Remove the glove box fastener, and then re- The fuse blocks in the passenger compartment are glove box to the left side of the box. move the glove box.
Page 294 Maintenance Fuse load capacity Passenger compartment fuse location (LHD) Passenger compartment fuse location (RHD) E01007700567 The fuse capacity and the names of electrical sys- Main fuse block tems protected by the fuses are indicated on the in- side of the fuse lid (LHD vehicles), the inside of Main fuse block Sub fuse block the glove box (RHD vehicles) and inside of the...
Page 295 Maintenance Engine compartment fuse location table Capaci- Capaci- Symbol Electrical system Symbol Electrical system ties ties Engine compartment fuse location Rear window de- Door locks 20 A 30 A mister Radio 15 A Heated door mir- 7.5 A Control unit relay 7.5 A AC power supply 15 A...
Page 296 Maintenance Sym- Sym- Sym- Electrical system paci- Electrical system paci- Electrical system paci- ties ties ties Bending Horn 10 A Radiator fan motor 40 A lamps (Adap- 30 A tive Front Alternator 7.5 A Discharge lighting Sys- Audio system amp 30 A Headlamp washer 20 A...
Page 297 Maintenance CAUTION Capacity Colour 15 A Blue If the newly inserted fuse blows again af- 20 A Yellow ter a short time, we recommend you to have the electrical system checked to find 25 A Natural (White) the cause and rectify it. Green (fuse type)/ Never use a fuse with a capacity larger 30 A...
Page 298: Replacement Of Lamp Bulbs
When replacing a bulb, wait for it to cool bulb for the side turn-signal lamp. sufficiently before touching it. You could Check with a MITSUBISHI MOTORS Au- otherwise be burnt. thorized Service Point when the lamp needs 1- Front turn-signal lamps: 21 W (WY21W) to be repaired or replaced.
Page 299 11- Tail lamps: 5 W (W5W) To avoid the risk of an electric shock, 12- Stop and tail lamps: 21/5 W (W21/5W) contact a MITSUBISHI MOTORS Au- 13- Rear turn-signal lamps: 21 W (W21W) thorized Service Point whenever repair or replacement is necessary.
Page 300 Maintenance 4. While pressing the tab (D), remove the bulb 3. Turn the socket (E) anticlockwise to remove (E). Position lamps E01003700501 1. To create enough work space, turn the steer- ing wheel all the way in the direction oppo- 5.
Page 301 Maintenance Front turn-signal lamps Front fog lamps 3. Remove the bulb by pulling it out. E01003801017 E01004000859 1. Remove the clips (A) and clips (B), then re- 1. Remove the clips (A) and clips (B), then turn move the duct (C) and the upper cover (D). up the cover (C).
Page 302 Maintenance 3. Turn the bulb (F) anticlockwise to remove it. 2. Remove the lamp unit in the rear direction. Rear combination lamps E01004201177 4. To install the bulb, perform the removal 3. Remove the socket and bulb assemblies by Stop and tail lamps and rear turn-signal lamps steps in reverse.
Page 303 Maintenance 4. Remove the bulb by pulling it out. Remove the clips (A) by prying with a 3. Remove the bulb by pulling it out. straight blade (or minus) screwdriver, and re- move the cover (B). Reversing lamp and rear fog Tail lamp lamp 5.
Page 304 Maintenance NOTE 2. Remove the socket and bulb assembly to- 1. Insert a straight blade (or minus) screwdriver gether by turning it anticlockwise. with a cloth over its tip into the notch of the When mounting the lens, align the tab (B) to lamp assembly.
Page 305 Maintenance Trunk room lamp 2. While holding down the tab (A), pull out the bulb. E01005300237 1. Pull both clips (A) away from the centre as shown and remove the lamp unit. Then re- move the bulb by pulling out. 3.
Page 306 OCZE14E3...
Page 307 Specifications Vehicle labeling................9-02 Vehicle dimensions...............9-04 Vehicle performance..............9-05 Vehicle weight................9-06 Engine specifications..............9-07 Electrical system................9-08 Tyres and wheels................9-09 Fuel consumption................. 9-10 Refill capacities................9-11 OCZE14E3...
Page 308: Vehicle Labeling
Specifications Vehicle labeling Vehicle information code plate Please use this number when ordering replacement parts. The vehicle information code plate is riveted as E01100101863 shown in the illustration. Vehicle identification number The vehicle identification number is stamped as shown in the illustration. 1- Model code 2- Engine model code 3- Transmission model code...
Page 309 Specifications Vehicle identification number plate (RHD vehicles only) The vehicle identification number is stamped on the plate riveted to the left front corner of the vehi- cle body. It is visible from outside of the vehicle through the windscreen. Engine number The engine number is stamped on the engine cylin- der block as shown in the illustration.
Page 310: Vehicle Dimensions
Specifications Vehicle dimensions E01100201460 Front track 1,545 mm Overall width 1,810 mm Front overhang 920 mm Wheel base 2,650 mm Rear overhang 935 mm Overall length 4,505 mm Ground clearance (unladen) 140 mm Overall height (unladen) 1,480 mm Rear track 1,545 mm Body 6.2 m...
Page 311: Vehicle Performance
Specifications Vehicle performance E01100300813 Item Twin Clutch SST Maximum speed 240 km/h (149 mph) 242 km/h (150 mph) 9-05 OCZE14E3...
Page 312: Vehicle Weight
Specifications Vehicle weight E01100405747 Item Twin Clutch SST Kerb weight Without optional parts 1,560 kg 1,615 kg 1,600 kg (LHD) 1,605 kg (RHD) With full optional parts 1,592 kg 1,625 kg 1,635 kg (LHD) 1,640 kg (RHD) Maximum gross vehicle weight 2,040 kg Maximum axle weight Front...
Page 313: Engine Specifications
Specifications Engine specifications E01100601552 Engine model 4B11 No. of cylinders 4 in line Total displacement 1,998 cc Bore 86.0 mm Stroke 86.0 mm Camshaft Double overhead Mixture preparation Electronic injection Maximum output (EEC net) 217 kW/6,500 r/min Maximum torque (EEC net) 366 Nm/3,500 r/min 9-07 OCZE14E3...
Page 314: Electrical System
Specifications Electrical system E01100802160 Voltage 12 V Type (JIS) S65D26L Battery Capacity (5HR) 44 Ah Alternator capacity 130 A Spark plug type DILKR8B6 9-08 OCZE14E3...
Page 315: Tyres And Wheels
Specifications Tyres and wheels E01100902376 Tyre 245/40R18 93Y Wheel Size 18x8 1/2 JJ Offset 38 mm 9-09 OCZE14E3...
Page 316: Fuel Consumption
Specifications Fuel consumption E01101100805 Combined Urban conditions Extra-urban conditions Fuel consump- Fuel consump- Fuel consump- Model Item (g/km) (g/km) (g/km) tion tion tion (L/100 km) (L/100 km) (L/100 km) 10.5 14.6 Twin Clutch SST 10.1 13.9 Twin Clutch SST 10.4 14.4 NOTE The values shown above apply to a vehicle on which optional equipment has not been fitted.
Page 317: Refill Capacities
Specifications Refill capacities E01101304658 Item Quantity Lubricants 7.5 litres MITSUBISHI MOTORS GENUINE SUPER LONG Engine coolant {includes 0.65 litre in the reserve LIFE COOLANT PREMIUM or equivalent tank} MITSUBISHI MOTORS GENUINE PSF Power steering fluid As required (Power Steering Fluid) Oil pan 4.8 litres...
Page 318 MITSUBISHI MOTORS GENUINE NEW MULTI Manual transmission oil 2.5 litres GEAR OIL API classification GL-3, SAE 75W-80 Transfer oil 0.8 litre MITSUBISHI MOTORS GENUINE LSD gear oil 1.0 litre AWC control fluid MITSUBISHI MOTORS GENUINE ATF SP III {includes hydraulic piping} For differential mechanism 0.55 litre...
Page 319 Alphabetical index AWC control fluid 8-06,9-11 Cigarette lighter 5-59 AYC (Active yaw control system) 4-29 Cleaning Exterior of your vehicle 7-03 Fluid 9-11 Interior of your vehicle 7-02 Accessory (Installation) 04 Clutch Accessory socket 5-60 Clutch pedal operation 4-14 ACD (Active centre differential system) 4-29 Fluid 8-07,9-11 Active stability control (ASC) 4-33 Coat hook 5-66...
Page 320 Alphabetical index Electric window control 1-34 Front fog lamps Head restraints 2-05 Lock switch 1-35 Bulb capacity 8-22 Headlamp levelling Timer function 1-35 Indication lamp 3-33 Automatic headlamp levelling 3-40 Electrical system 9-08 Replacement 8-25 Headlamp washer switch 3-47 Electronic immobilizer (Anti-theft starting sys- Front fog lamp Headlamps tem) 1-03...
Page 321 Alphabetical index Jump starting (Emergency starting) 6-02 Manual transmission oil 9-11 Rear window demister switch 3-47 Transfer oil 9-11 Rear-view camera 4-43 Operation under adverse driving conditions 6-19 Rear-view mirror Outside rear-view mirrors 4-07 Inside rear-view mirror 4-06 Overheating 6-04 Outside 4-07 Keyless entry system 1-04,1-19 Refill capacities 9-11...
Page 322 Alphabetical index Side turn-signal lamp Tools 6-06 Used engine oils safety instructions and disposal Bulb capacity 8-22 Storage 6-05 information 05 Snow tyres 8-12 Towing 6-17 Spark plug 9-08 Transfer oil 9-11 Specifications 9-02 Transmission Speedometer 3-02 Manual transmission 4-14 Vanity mirror 5-58 Sport Shift Transmission (SST) Twin Clutch SST (Sport Shift Transmis-...
Page 323 Declaration of Conformity OCZE14E3...
Page 324 Declaration of Conformity OCZE14E3...
Page 325 Declaration of Conformity OCZE14E3...
Page 326 Declaration of Conformity OCZE14E3...
Page 327 Declaration of Conformity OCZE14E3...
Page 328 OCZE14E3...
Page 329 OCZE14E3...
Page 330 OCZE14E3...

Mitsubishi MOTORS LANCER EVOLUTION Owner's Manual

General Information

Locking and Unlocking

Seat and Seat Belts

Section 4

Section 5

Section 6

For Emergencies

Maintenance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi MOTORS LANCER EVOLUTION

Summary of Contents for Mitsubishi MOTORS LANCER EVOLUTION

Table of Contents
