GUIDANCE MARINE RadaScan View Installer's Manual

Hide thumbs Also See for RadaScan View:
Table of Contents

Advertisement

Quick Links

®
RadaScan
View Installer's Guide
www.guidance.eu.com
Guidance Marine Ltd, 5 Tiber Way, Meridian Business Park, Leicester LE19 1QP, UK
www.marine.direct
T: +44 116 229 2600 E: sales@guidance.eu.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RadaScan View and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GUIDANCE MARINE RadaScan View

Summary of Contents for GUIDANCE MARINE RadaScan View

  • Page 1 ® RadaScan View Installer’s Guide www.guidance.eu.com Guidance Marine Ltd, 5 Tiber Way, Meridian Business Park, Leicester LE19 1QP, UK www.marine.direct T: +44 116 229 2600 E: sales@guidance.eu.com...
  • Page 2 Copyright © 2016 Guidance Marine Limited. All Rights Reserved. Copyright in the whole and every part of this document belongs to Guidance Marine Limited (the “Owner”) and may not be used, sold, transferred, copied or reproduced in whole or in part in any manner or form or in or on any media to any person other than in accordance with the terms of the Owner’s Agreement or otherwise without the prior written consent of the Owner.
  • Page 3 Document History Document Number Changes Issue Date 94-0492-4-A First release of RadaScan View Installer's Guide 02/03/2016...

  • Page 4: Table Of Contents

    Sensor Information Display ..................24 Installing the Sensor Software .................. 26 Installing the Marine Processor Installing RadaScan View Client Software onto a Type 3 Marine Processor ....28 Installing RadaScan View Client Software onto other Types of Computer ....29...

  • Page 5: Introduction

    Introduction This section provides an introduction and overview of the RadaScan View system. It contains the following pages: • Welcome (page 6) • System Overview (page 7) • Important Safety Notes (page 8) • Serial Numbers and Software Versions (page 9) FCC ID: VYMRADASCAN THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

  • Page 6: Welcome

    Installing the Sensor Hardware and Software section on page 10 describes where to mount the RadaScan View sensor on the vessel, and how to connect it to the RadaScan View marine processor and the vessel’s DP system. It also explains how to upgrade the sensor software, if required.

  • Page 7: System Overview

    The RSI is used for system configuration and replaces the Service Access mode of the Dashboard reduced size and weight of the RadaScan View sensor allows it to be used on smaller vessels or Console in earlier versions of the RadaScan system.

  • Page 8: Important Safety Notes

    Important Safety Notes Non-ionising Radiation The RadaScan View sensor emits non-ionising radiation with an output power of 1 Watt when transmitting. This equipment should be treated with the same safety precautions as other marine radar devices. ALWAYS keep a minimum safe distance of 1 metre from the dome when the unit is operational.

  • Page 9: Serial Numbers And Software Versions

    Serial Numbers and Software Version Numbers are used to identify the hardware configuration and product revision of each RadaScan View sensor. They will be requested by Guidance Marine in the event of an application service or support call to the company.

  • Page 10: Installing The Sensor Hardware And Software

    Installing the Sensor Hardware and Software This section explains where and how to mount the RadaScan View Sensor on the vessel. It contains the following pages: • Mounting the Sensor (page 11) ƒ Avoiding Other Sources of Radiation (page 12) ƒ...

  • Page 11: Mounting The Sensor

    The sensor’s mounting position depends on the application for which it is used. If your particular application does not match the ones covered in this manual, please contact Guidance Marine and your DP supplier to ensure that the RadaScan View and DP systems are configured correctly. •...

  • Page 12: Avoiding Other Sources Of Radiation

    X-Band Radar View Wherever possible, the RadaScan View Sensor should not be installed at the same vertical level as an X-band radar or Artemis sensor. If vertical separation of the two systems is impossible, they must be shielded from one another with a metal screen.

  • Page 13: Operating Area Astern (E.g. Psv)

    Mounting the Sensor (continued) Operating Area Astern (e.g. PSV) Mount the RadaScan View sensor with its connection panel facing towards the vessel’s bow. (Connection panel faces away from the operating area). The sensor’s position (Bow and Starboard Offsets) and orientation (Bearing Offset) must be set up in the RadaScan Service Interface.

  • Page 14: Operating Area Forward (E.g. Shuttle Tanker)

    Mounting the Sensor (continued) Operating Area Forward (e.g. Shuttle Tanker) Mount the RadaScan View sensor with its connection panel facing towards the vessel’s stern. (Connection panel faces away from the operating area). The sensor’s position (Bow and Starboard Offsets) and orientation (Bearing Offset) must be set up in the RadaScan Service Interface.

  • Page 15: Operating Area To Port Or Starboard (E.g. Track And Follow)

    Mounting the Sensor (continued) Operating Area to Port or Starboard (e.g. Track and Follow) Mount the RadaScan View sensor with its connection panel facing inboard, towards the vessel’s centre line. (Connection panel faces away from the operating area). The sensor’s position (Bow and Starboard Offsets) and orientation (Bearing Offset) must be set up in the RadaScan Service Interface.

  • Page 16: Sensor Dimensions

    Sensor Dimensions 240mm Mounting Holes 240mm 410mm Ø 500mm Side View 4XM8 MOUNTING HOLES Bottom View...

  • Page 17: Mounting Template

    Mounting Template NOT TO SCALE Ensure that any custom-made plinth is flat, rigid and horizontal, able to support 25kg and to receive four M8 mounting bolts. Mounting Plate Four 9mm holes (to take M8 bolts) Edge of 240mm Radome 240mm 500mm...

  • Page 18: Universal Mounting Bracket

    Universal Mounting Bracket The Universal Mounting Bracket (Part No. 20-0120-1) can be used to mount the RadaScan View sensor to a handrail or other suitable railing. Ensure that the railing is strong enough to support the combined weight of the sensor and bracket.

  • Page 19: Sensor Connections-Direct

    Sensor Connections—Direct The RadaScan View sensor installation should include a double-pole disconnect device in the mains input wiring. RS422 Link To Connect the Sensor: 9600 baud Remove the radome and connection panel. 8 bits 1 stop bit Radome Feed the cables through the glands on the connection panel.

  • Page 20: Sensor Connections-Separate Connection Box

    Sensor Connections—Separate Connection Box The RadaScan View sensor installation should include a double-pole disconnect device in the mains input wiring. CAUTION Fuse Rating: Double Pole/ 2 x 250V T1.6A RS422 Link Lid and (5 x 20mm) Neutral Fusing. 9600 baud...

  • Page 21: Cable Routing Diagram - Direct Connection

    Marine Processor the Sensor to the Marine Processor Monitor Cable should not exceed 90 metres in length. Power Adaptor Monitor Power Please contact Guidance Marine if Cable Marine Processor longer distances are required. Power Cable DP System UPS Ethernet Ethernet Cable...

  • Page 22: Cable Routing Diagram - Separate Connection Box

    Marine Processor the Sensor to the Marine Processor Monitor Cable should not exceed 90 metres in length. Power Adaptor Monitor Power Please contact Guidance Marine if Cable longer distances are required. Marine Processor Power Cable Connection DP System UPS Ethernet...

  • Page 23: Cable Routing Diagrams - Processor And Monitor Options

    Cable Routing Diagrams - Processor and Monitor Options Alternative Processor and Monitor Options Any of the following configurations may be used (see pages 21, 22) Hatteland Hatteland Desktop Touchscreen Panel PC Monitor Monitor Monitor Cable Monitor Cable Marine Processor Marine Processor Power Cable Power Power...

  • Page 24: Sensor Information Display

    Sensor Information Display Information Display Messages When the sensor has been powered up, the Sensor Information Display shows the sensor’s status and network details. The display automatically cycles through the screens listed on the right. The Each line of the Information Display is 20 characters in width. Messages that are wider than this display cannot be paused.
  • Page 25 Second Stage boot Second Stage boot Booting via Ethernet Booting via Ethernet Ver: 4.0.2.155 Ver: 4.0.2.155 Cause: Missing SD card. Action: Contact Guidance Marine. Operating System Operating System Operating System Operating System SD card Error SD card Error Ver: 4.0.2.155 Ver: 4.0.2.155...

  • Page 26: Installing The Sensor Software

    Installing the Sensor Software Your RadaScan View sensor will have been shipped from Guidance Marine with software already installed. However, it may be necessary from time to time to upgrade the software with a newer version. Upgrade the Sensor Software: Locate the RadaScan.Installer.Remote.exe file on the USB memory stick on which it...

  • Page 27: Installing The Marine Processor

    Installing the Marine Processor Before setting up the RadaScan View client computer(s), refer to the relevant installation sheet(s) for dimensions and connection information: For a Type 3 Marine Processor: • 94-0465-4 Type 3 Marine Processor and Display Installation Sheet For a Hatteland Panel PC: •...

  • Page 28: Installing Radascan View Client Software Onto A Type 3 Marine Processor

    Installing RadaScan View Client Software onto a Type 3 Marine Processor This section explains how to install the RadaScan View client software onto a Type 3 Marine Processor. If this Marine Processor has been supplied by Guidance Marine, it will have been shipped with the client software already installed.

  • Page 29: Installing Radascan View Client Software Onto Other Types Of Computer

    Installing RadaScan View Client Software onto other Types of Computer This section explains how to install the RadaScan View client software onto a computer running Windows 7 that does not have a File-Based Write Filter. This PC should have the following installed: •...
  • Page 30 Configuring the RadaScan View System This section contains the following pages: • Using the RadaScan Service Interface (page 31) • Network Communication Settings (page 32) • Vessel Definition (page 34) • Blanking Zone (page 38) • DP Feed Configuration (page 39) •...

  • Page 31: Using The Radascan Service Interface

    In Command Indicator – This red block symbol is visible when the RSI is In Command mode. The RadaScan Service Interface (RSI) is a tool for configuring the RadaScan View system. Status Display – Indicates the current status of the system, e.g. “System Running Normally” or “System Suspended”.

  • Page 32: Network Communication Settings

    Network Communication Settings The Network Config tab of the RSI is used to view and amend the RSI’s record of the sensor’s To Modify the Dashboard’s Record of the Sensor’s Network IP Address network IP address and also to remotely amend the address on board the sensor. Click on the Guidance button to open the Guidance Home menu.
  • Page 33 Network Communication Settings (continued) To Remotely Modify the Sensor’s On-Board Network IP Address Ensure that the RSI is in command and that no tracking is in progress. Click on the Network Config tab of the RSI. Click on the Edit button in the Sensor On-Board Network Configuration section. Amend the Sensor Address as required.

  • Page 34: Vessel Definition

    Vessel Breadth: The width or beam of the vessel in metres. • Click on Apply to save the changes or on Cancel to discard. Bow Offset: Distance from the centre of the RadaScan View sensor to the vessel’s bow, in metres. •...
  • Page 35 Vessel Definition (continued) Bow and Starboard Offsets Enter the correct Bow and Starboard Offset values on the Vessel tab (See Vessel Definition on page 34) Starboard Offset Bow Offset RadaScan View Sensor Port Side Starboard Side...
  • Page 36 Connection panel facing starboard, 90° Sensor perpendicular to vessel centre-line. Bearing Offset = 90° Operating Vessel Centre-line Area 0° RadaScan View Sensor Sensor Facing Aft Connection panel facing forward, Connection Sensor parallel with vessel centre-line. Panel Bearing Offset = 0°...
  • Page 37 Vessel Definition (continued) Reset, Import and Export of Vessel Definition The Vessel Definition can be reset to factory defaults, imported from an XML or CTF file or exported to an XML file. To Reset to Factory Defaults: Ensure that no target tracking is in progress. Click on the Take Command button if the RSI is not already in command mode.

  • Page 38: Blanking Zone

    Blanking Zone A Blanking Zone can be used to mask the segment of the scan rotation that is obscured by the vessel’s superstructure. The start and end of the zone can be set to any positions around the circle to the nearest degree. Generally, once the blanking zone has been set, it will not need to be changed.

  • Page 39: Dp Feed Configuration

    DP Feed Configuration The RadaScan View system provides positional data messages to your vessel’s DP (Dynamic DP Feed Behaviour Positioning) system and the format and behaviour of this output stream needs to meet the The DP Feed Behaviour options are two tick-boxes available on the DP Feed pane in Service requirements of the DP system.
  • Page 40 DP Feed Configuration (continued) For MDL Standard, MDL Multi-Target and Kongsberg Standard DP formats: Keep Feed Allow Zero Output when target is visible but not tracked Enabled Strings Null data (gaps in data string)   Null data (gaps in data string) ...

  • Page 41: Information Tabs

    Dashboard Alarms pane which gives start and stop times on The Clients Tab one line. This lists each Dashboard currently connected to the RadaScan View sensor, in addition to the RSI itself. It gives the command mode and computer name of each.
  • Page 42 Information Tabs (continued) The About Tab This contains version information for the RSI and sensor, the serial number of the sensor, contact details for Guidance Marine Ltd and a button for opening an on-screen copy of this Installer’s Guide.
  • Page 43 Installing Responders This section explains how to install and maintain RadaScan View Responders. It contains the following pages: • Responder Overview (page 44) • Positioning Responders (page 46) • Mounting Responders (page 47) • Charging Responders (page 49) • Operating Responders...

  • Page 44: Responder Overview

    Responder Overview Series 2 and 3 Responders can be used with RadaScan and RadaScan View systems. One or more Responders should be mounted on the target platform or vessel. The following models of RadaScan Series 2 Responder are no longer available but may be encountered in the field.
  • Page 45 Responders are not intended to be repaired by the user. They must only be repaired or serviced by Guidance Marine, or by an approved service representative of Guidance Marine, in accordance with This scheme makes it easier for the RadaScan View system to separate the signal from one the applicable code of practice.

  • Page 46: Positioning Responders

    The location, range and orientation of the Responders in relation to the Sensor have a significant effect on the tracking performance of the RadaScan View system, and hence on the quality of the position data sent to the DP system.

  • Page 47: Mounting Responders

    The swivel bracket (Part No. 21-0328-1) should be used to point bottom of the mounting plate. (See below). the responder towards the RadaScan View Vessel’s working area. It can be mounted on either a horizontal or vertical bar: Rotate the responder backwards until it is held in place by its magnet against the mounting plate.
  • Page 48 Mounting Responders (continued) Mounting a Primary Cell Responder with a Primary Cell Pack: Lanyard attachment points Responder Swivel- bracket with 2 x U-bolts Primary cell pack bracket (Part No. 21-0340-1) with 2 x thumb screws Primary Cell Pack (Part No. 21-0314-1 for Series 2 or 21-0375-1 for Series 3) Bracket tail to provide additional support...

  • Page 49: Charging Responders

    Charging Responders The rechargeable responder should be fully charged before use. A full charge takes approximately 24 hours. DO NOT charge responders in an explosive atmosphere or other hazardous environment. The responder should be switched off while charging. To Charge the Responder: Note: Only use the supplied charger.

  • Page 50: Operating Responders

    When a primary cell responder is switched on and the green light does not flash at all, replace the primary cell. The batteries within the primary cell may be replaced, but this must only be done in an ATEX safe environment, using batteries supplied by Guidance Marine or authorised partners.
  • Page 51 Appendices This section contains the following appendices: • (page 52) International Standards Compliance • Part Numbers (page 53) • DP Message Types (page 54) • UPS and Cable Specifications (page 58) • Installation Checklist (page 59) • Index (page 61)

  • Page 52: International Standards Compliance

    Radio Licensing Department N-1331 FORNEBU NORWAY Tel: +47 22 77 43 50 Fax: +47 22 42 70 72 Web: www.maritimradio.no Use of the RadaScan View system in the United States of America is authorised by the Federal Communications Commission. FCC ID: VYMRADASCAN.

  • Page 53: Part Numbers

    Part Number Component Part Number RadaScan View Sensor 20-0174-0 Series 2 Universal Mounting Bracket 20-0120-1 Responder (Rechargeable) 20-0108-1 Guidance Marine System Level USB 180-0011-4 Responder (Rechargeable) 20-0108-L-1 Operator’s Guide 94-0491-4 Primary Cell Responder 20-0138-1 Installer’s Guide 94-0492-4 Primary Cell Pack...

  • Page 54: Dp Message Types

    [A] available; [V] void • • HHHH HHHH status word in hexadecimal. Up to 16 bits defined by Guidance Marine in a separate status word in hexadecimal. Up to 16 bits defined by Guidance Marine in a separate specifications document specifications document. •...
  • Page 55 DP Message Types (Continued) MT Custom DP String The MT Custom DP String adopts NMEA0183 conventions with a minimum length of 63 and maximum length of 80 characters. It provides the same type of information for both CyScan and RadaScan sensors, including range and bearing to all tracked responders (similar to the MDL Multi-Target format). It also provides quality information.
  • Page 56 DP Message Types (Continued) Rolls-Royce Custom DP String The Rolls-Royce Custom DP String adopts NMEA0183 conventions with a minimum length of 82 characters and maximum length of 101 characters. It provides the same type of information for both CyScan and RadaScan sensors, including range and bearing to all tracked responders (similar to the MDL multi-responder format). It also provides quality information.
  • Page 57 DP Message Types (Continued) Kongsberg Standard MDL Standard A 9 character string in BCD format. A 19 character string delimited only by <CR> and <LF> with bearing measured bow clockwise. BB BB B0 RR RR RR 00 00 FF Character Index Description Format Sequence...

  • Page 58: Ups And Cable Specifications

    Nominal Current draw at 230V = 0.26A RMS The RadaScan View UPS should be able to run on back-up power for at least the same duration as that specified for the DP System UPS. The power cable to the RadaScan View Sensor must be rated to withstand the maximum current output of the UPS.

  • Page 59: Installation Checklist

    There is enough free space to accommodate Dashboard data logging. and connectors. PDF Reader Click on the F1 button and check that the RadaScan View Operator’s Guide Dashboard The Sensor is connected correctly to the Marine Processor using the approved can be viewed.
  • Page 60 The network connection between the Sensor and the Dashboard is OK. radios systems. Connection Ensure that the RadaScan View system dœs not suffer any loss of signal quality. Sensor –DP The DP system can receive a message string from the Sensor.

  • Page 61: Index

    Sensor 11 Clients Tab Template 17 Federal Communications Commission 52 Configuring MT Custom DP String 55 FPGA Version 24 RadaScan View System 30 Fuse Rating 19, 20 Connections Console PC 27 NMEA Primary 54 Connection Status Indicators 24 NMEA Raw 54...
  • Page 62 Cable 58 Product Label 9 UPS 58 PSV 13 Standards 52 Starboard Offset 34, 35 Static Hazard 45 RadaScan View Sensor 7 Status Indicators 24 RadaScan Service Interface 7, 31 System Overview 7 Radio Licence 52 Responder 7 Charging 49...
