Audio Visual Furniture MC1000-S Assembly And Mounting Instructions

Note: If you cannot understand these instructions or are concerned about safety of the installation
Contact a qualified contractor or contact AVFI at 1-877-834-3876.
Confirm all hardware is included before you begin assembly.
Not all hardware supplied will be used depending on the manufacturer of your display/s.
Supplied Parts:
MC1000
Cart (1)
Hardware
Bags

Supplied Hardware:

M8 x 20
5/16 Carriage
(4)

Tools required:

Not Included
288 Don Hillock Drive, Aurora, Ontario L4G 0G9
Toll Free: 1-877-834-3876
MC1000-S
Assembly and Mounting Instructions
Thank you for purchasing AVFI's MC1000 Metal Cart.
This product was designed for video conferencing applications
and is suitable for single TV configurations.
Handles (2)
TV
Hardware Bag
Lock
Washer (4)
Bolt (4)
AUDIO VISUAL FURNITURE INTERNATIONAL
TV Bracket (2)
Spine
Assembly (1)
Cam Plate (1)
Cam Bracket (1)
Camera
Hardware
Bag
5/16 Nut (4)
9/16" Wrench
or Socket
Fax: 1-905-751-1488 Local: 905-751-1459
Cam Arm (1)
Tube Bracket (2)
Tube (1)
M8 x 12
M6 x 30
(2)
(1)
M8 Hex Key
(1)
1/2" Wrench
or Socket
www.video-furn.com
Page 1
of 7
M6 x 12
(1)
M6 Hex Key
(1)
