- Page 1 Shock absorber support DGEA-...-YSR (en) Operating instructions 8103902 2018-12b [8103904]...
- Page 2 Information on environmentally sound usage Text designations: • Activities that may be carried out in any order 1. Activities that should be carried out in the order stated – General lists è Result of an action/References to more detailed information Festo DGEA-...-YSR 2018-12b...
- Page 3 DGEA-...-YSR Shock absorber support type DGEA-...-YSREnglish For all available product documentation è www.festo.com/pk Operating parts and connections Shock absorber Lock nut Shock absorber support Fastening screws Sliding blocks Fig. 1 Festo DGEA-...-YSR 2018-12b English...
-
Page 4: Conditions Of Use
2. Push the cantilever arm out of the end position by the dimension Y. DGEA-... Dimension Y [mm] Shock absorber stroke + 13.5 mm Shock absorber stroke + 2 mm Fig. 2 Shock absorber stroke + 2 mm Festo DGEA-...-YSR 2018-12b English... - Page 5 5. Place the DGEA-...-YSR over the sliding blocks at the same time observing mini mum dimension L. DGEA-... L [mm] Fig. 4 6. Fasten the shock absorber support together with the shock absorber with contact to the drive head. Festo DGEA-...-YSR 2018-12b English...
- Page 6 During the test run of the axis: Check whether the shock absorber main tains the two dimensions as shown in Figs. 6 and 7, even during operation. >0 Fig. 6 DGEA-25/40: > 0 mm DGEA-18: > 16 mm Fig. 7 Festo DGEA-...-YSR 2018-12b English...
-
Page 7: Operation
Check whether the shock absorber support is displaced or is no longer fitted asymmetrically. In this case it is necessary to reposition the shock absorber support. We recommend that you check whether the profile cover is correctly seated. Hard knocking may damage the cover connection. Festo DGEA-...-YSR 2018-12b English... -
Page 8: Technical Specifications
Type Shock absorber YSR-... Sliding block HMV-... HMBN-... Technical specifications Type DGEA-18-...-YSR DGEA-25-...-YSR DGEA-40-...-YSR Weight of the shock 322 g 523 g 1190 g absorber support (without shock absorber, nuts and fastening elements) Materials Zinc-coated steel Festo DGEA-...-YSR 2018-12b English... - Page 9 DGEA-...-YSR Festo DGEA-...-YSR 2018-12b...
- Page 10 Copyright: Festo AG & Co. KG Ruiter Straße 82 73734 Esslingen Germany Phone: +49 711 347-0 Fax: +49 711 347-2144 E-mail: Reproduction, distribution or sale of this document or communica service_international@festo.com tion of its contents to others without express authorization is prohibited.
