Set up your 10-inch LCD
USER GUIDE FOR TS SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Monitech TS SERIES

Summary of Contents for Monitech TS SERIES

  • Page 1 Set up your 10-inch LCD USER GUIDE FOR TS SERIES...
  • Page 2 WARRANTY. PLEASE RETURN TO MONITECH FOR REPAIRS. 1. Secure a video signal. After mounting your new Monitech LCD into the control panel and attaching the video and power cables, the monitor will power up automatically. It should also start receiving the video signal from your machine. If you are getting no video signal, your screen will be blue.
  • Page 3 2. Start with the 3-button menu. Now that you have your video signal, use the 3 buttons on the back of the LCD to optimize the video for your specific machine. IMPORTANT: ignore the top 5 buttons for now. Press MENU to open the menu. Press MENU again to select an item.
  • Page 4 3. Size your video image. Focus on the first five settings. Don’t worry about brightness or contrast yet. H POSITION (HORIZONTAL) The default value is 00. The range is -99 to +99. WIDTH This is a very useful setting: use it to adjust the width of the video on your screen.
  • Page 5 SCANNING Defaults to Progressive and rarely needs adjustment. RESOLUTION Defaults to 800x600. If the video still won’t fit on the screen after adjusting the WIDTH setting, change the resolution to 640x480. EXIT + SAVE The menu will exit and save automatically after 20 seconds. If you are in a hurry, you can select this item manually.
  • Page 6  To adjust brightness and contrast press the up  down buttons. Press MENU three times for other options. You probably will never need these adjustments. To exit, press MENU until it goes away. Video connector This picture shows the value for six pins on the video connector at the back of the monitor.
  • Page 7 Tips to optimize your image My screen is blue. This means the LCD is getting no video signal from the machine. Reseat the video connector and secure it. I cannot see a right or left edge of the image. In the 3-button menu, select WIDTH and adjust down until you can see the right edge of your video.
  • Page 8 All rights reserved. No parts of this manual may be reproduced in any form without the express written permission of Monitech. Monitech makes no representations or warranties with respect to the contents of this User Manual. In addition, information contained herein is subject to change without notice.
