1.
INTRODUCTION
The SmartWave LF Tool is a handheld device designed to provoke data transmissions from
SmartWave sensors. The tool can be used to assist the installer during:
New Installations – programming sensor ID numbers & vehicle configuration into the
•
receiver
Sensor Replacement - programming new sensor ID numbers into the receiver
•
Installation Verification (without moving vehicle)
•
NOTE: The SmartWave LF Tool is compatible with SmartWave low and high pressure
commercial sensors ONLY.
2.
OVERVIEW
Learn LED
Initiate LED
Low Battery LED
On/Off & Mode
Select Button
Initiate/Learn Button
710.0089 Rev. 1.1
Transmission End
SmartWave LF Tool User Manual
Battery Cover
3
