Page 1
MZX1002 MIXER ZONE MZX1002 MIXER ZONE USER MANUAL...
Page 2
All rights reserved by Music & Lights S.r.l. No part of this instruction manual may be reproduced in any form or by any means for any commercial use. In order to improve the quality of products, Music&Lights S.r.l. reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
1. 1 Features 2 Operating elements and connections 2. 1 Front Panels 2. 2 Rear Panels 2. 3 Connections 2. 4 Block diagrams 2. 5 Specifications 3 General criteria for installation of sound systems Packing content: • MZX1002 • User manual...
MZX1002 WARNING! Before carrying out any operations with the unit, carefully read this instruction manual, and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instruction • The products referred to in this manual conform to the European Community Directives and are there- fore marked with .
MZX1002 - 1 - INTRODUCTION 1.1 - Features • Versatile function and compact size • 6 Channels MIC input with XLR jack • 10 Channels LINE input with 1/4” phone jack • 4 Channels LINE input with RCA jack • 3 Band EQ control on every MIC channels •...
6. OUTPUT CHANNEL SELECTORS These selectors allow each input signal through out to selected output channel. This function is in MZX1002 only. 7. PFL SWITCHES This switch allows you to monitor the pre-fader signal of input channel through headphone output.
MZX1002 2.2 - Rear Panels MZX1002 MIXER ZONE FUSE: T125mAL/250V ~ AC INPUT 230V 50/60 Hz, 16W Fig.3 1. DC 24V INPUT AND LINK OUTPUT Device will be supplied DC 24V through input terminal and supply to other device through link output terminal.
MZX1002 2.3 - Connections M&L products are wired to reflect accepted wiring practices used throughout the world. Balanced XLR connectors are wired as described: Pin #1 Shield Pin #2 Positive Pine #3 Negative Balanced 1/4” TRS connectors are wired as described:...
Page 9
MZX1002 2.3 - Connections CONNECTOR AND CABLE CONFIGURATIONS REMOTE DEVICE REMOTE SIDE OF CABLE DESCRIPTION CABLE (Connector Type) White(Red)/HIGH Black/LOW A. XLR** Shield/GND (XLR) Floating or Balanced low impedance: most professional equipment line in and line out, microphones. White(Red)/HIGH Black/LOW B.
Page 10
MZX1002 2.3 - Connections MZX1002 MIXER ZONE FUSE: T125mAL/250V ~ AC INPUT 100 ~ 240vAC 50/60 Hz, 16W MICROPHONE EMERGENCY PANEL MICROPHONE POWER AMPLIFIER SY-A360 PO WER AMPLIFIE R POWER CASSETTE DECK CD PLAYER TUNER SPEAKERS Fig.6...
MZX1002 - GENERAL CRITERIA FOR INSTALLATION OF SOUND SYSTEMS Introduction This guide represents a quick introduction to the criteria for the installation of a sound system at constant voltage or constant impedance. A sound system must be made by qualified personnel only, who must evaluate the needs of the user and the...
