- Page 1 Oxygen Analyzer Manual Model 201LC AMI, Costa Mesa, CA...
-
Page 2: Table Of Contents
Contents Preface The AMI story Caution Address Model 201LC Series Oxygen Analyzer Introduction Features: Oxygen sensor: Sensor Warranty: Instrument Warranty: Installation and Operation Receiving the analyzer Installation. Location: Connect gas and power lines: Interconnections: Alarm connections: Output connections: Serial connections:... - Page 3 Emergency and first aid procedures Handling information Sensor type T2 Product Identification Physical and chemical data Physical hazards Health hazard data Emergency and first aid procedures Handling information Glossary of Terms Index AMI Analyzer Manual Contents • • • • ii...
-
Page 4: Preface
5,728,289 and 6,675,629; the sensors have a patent pending. AMI specializes in oxygen analysis only , so as not to dilute its expertise by trying to cover too many other fields. As a result AMI analyzers are more advanced and have more features than competitive models. -
Page 5: Model 201Lc Series Oxygen Analyzer
Model 201LC Series Oxygen Analyzer Introduction The Advanced Micro Instrument Oxygen Analyzer Model 201LC provides the latest in low-cost high precision oxygen measurement. This manual covers software version 1.0. Features: • Compact size • High accuracy and fast response •... -
Page 6: Oxygen Sensor
The span calibration may be performed using standard span gases or ambient air. Unlike competitive sensors, the AMI sensor is made using a high capacity metallic body that provides long life with about twice the active ingredients of conventional sensors, but without compromised come-down time. -
Page 7: Installation And Operation
Although the unit is RFI protected, do not to mount it close to sources of electrical interference such as large transformers, motor start contactors, relays etc. Also avoid subjecting it to significant vibration. AMI Analyzer Manual Installation and Operation • • • •... -
Page 8: Connect Gas And Power Lines
Power connections: The 201LC is designed to be operated from a 24V power supply only. Use a suitable wall adapter, or other kind of stable DC power supply. Make sure the ground is connected to a real ground – otherwise you may experience AMI Analyzer Manual Installation and Operation •... -
Page 9: Interconnections
RFI interference. Interconnections: Figure 2. Back panel of the 201LC. Alarm connections: The alarm connections are single pole double throw relays, i.e. Form C contacts. They are normally preset to operate as high alarms, failsafe, with no alarm delay, though they can be supplied with other settings. By failsafe is meant that the relays are powered when NOT in alarm, so that if power fails, they indicate an alarm condition. -
Page 10: Sample Handling
Cell block 2001LC Figure 3 Flow Schematic of the 201LC The analyzer expects to get a sample of gas at a pressure between 1 and 40psig. A built-in needle valve and flowmeter allow the user to control flow to 1SCFH with any pressure within this range. Higher pressure applications, or varying pressure applications, will need a regulator to control pressure. -
Page 11: Sensor Installation
According to the option programmed into the unit, it will display the percentage output ranges allowed as shown above. AMI Analyzer Manual Installation and Operation • • • •... -
Page 12: Change Output Range
Calibration (Spanning) The model 201LC may be calibrated using air as the span gas, or else using a lower level gas closer to the measurement range. It is not necessary to zero the analyzer. Spanning is normally performed somewhere between once a month and once every three months, depending on the level of accuracy required. - Page 13 5. After a few seconds, the SPAN flag will go off and the new calibration value will be stored. 6. Using the external valve, allow sample gas to flow again. AMI Analyzer Manual Installation and Operation • • • •...
- Page 14 Alarm Functionality: The model 201LC series has two alarms, with two associated relays. Normally, these are set to operate as high alarms (they go into alarm if the oxygen level goes above the set point), and to close their associated relays upon alarm. Their time delay is set to zero, and they do not latch (unless specifically requested otherwise).
- Page 15 Maintenance and troubleshooting Maintenance: The model 201LC is virtually maintenance free other than for periodic calibration and occasional sensor replacement. Periodic Calibration: The analyzer should be calibrated about once every month to obtain the best accuracy. The sensor typically declines in sensitivity by about 1% per month, so a monthly calibration is usually satisfactory.
- Page 16 Refer to the MSDS to learn about potential hazards and corrective actions in case of any accident. O ring Cell block Electrodes Sensor Electrodes Cell block front Sensor Membrane Down Figure 4. Inserting sensor in cell block AMI Analyzer Manual Maintenance and troubleshooting • • • •...
- Page 17 15. Let the reading come down to a low level, and then if desired, calibrate it using a span gas. O rings The O rings used are all Buna N type. Replacements are available from AMI . The following lists all the O rings used in the model 201LC Series.
- Page 18 10 psig and leak check all the fittings and tubing including the sensor block penetrations such as the sensor wire seals (nylon plugs and epoxy seals on the top of the cell block). NOTE: Be careful not to get soap solution on the PC board! AMI Analyzer Manual Maintenance and troubleshooting • • • •...
- Page 19 20.9% oxygen. Manufactured air often does not! Still no correct operation 1. Call AMI at 714 848 5533, and ask for Technical assistance. 2. Or contact us by email at sales@AMIO2.com. AMI Analyzer Manual...
- Page 20 The AMI analyzer is not designed as a primary safety device, that is to say it is not to be used as the primary means of assuring personnel safety. In particular it is not designed to act as a medical instrument, monitoring breathing air for correct oxygen concentration, and should not be used as such when it is the only safety device on the gas system.
- Page 21 The sensor body is made of metal and glass-epoxy GR4 circuit board material, with a Mylar covering. It contains the following substances: Common name Formula Concentration CAS number Potassium hydroxide 15%; 1-5ml 1310-58-3 solution 15% Lead pure, 3-20 g 7439-92-1 AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 22 Aluminum, organic materials, acid chlorides, acid Incompatibilities: anhydrides, magnesium, copper. Avoid contact with acids and hydrogen peroxide > 52% Hazardous decomposition byproducts: Toxic fumes Hazardous polymerization: Will not occur AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 23 IARC: lead is classified as a class 2B carcinogen - Carcinogenity: possibly carcinogenic to humans. Lead is a chemical known to the state of California to Other health hazards: cause birth defects or other reproductive harm. AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 24 Advanced Micro Instruments. shall not be held liable for any damage arising out of using or abusing this product. AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 25 The sensor body is made of metal and glass-epoxy GR4 circuit board material, with a Mylar covering. It contains the following substances: Common name Formula Concentration CAS number Acetic acid 5% w/v 64-19-7 Potassium acetate 5% w/v 127-08-2 Lead Pure 7439-92-1 AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 26 The contents of the sensor are not flammable. There are no fire or explosion hazards associated with the sensor. Potential for reactivity: The sensor is stable under normal conditions of use. Avoid contact between the sensor electrolyte and strong acids and oxidizing agents. AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 27 Ingestion: medical attention. Do not administer liquids to an unconscious person. Liquid inhalation is unlikely. If it occurs, move to fresh Inhalation: air and seek immediate medical attention. AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 28 Advanced Micro Instruments. shall not be held liable for any damage arising out of using or abusing this product. AMI Analyzer Manual Material safety data sheets (MSDS) • • • •...
- Page 29 A type of mounting where the analyzer is inserted into a vertical panel so that the face plate is visible on the panel, while the body of the analyzer extends behind it. AMI Analyzer Manual Glossary of Terms • • • •...
- Page 30 Trace Low levels of, in this case, oxygen. This term is used to describe unwanted levels of oxygen as a contaminant, typically in the low ppm levels. AMI Analyzer Manual Glossary of Terms • • • •...
- Page 31 Index Address of AMI, 1 No output alarm indication, 16 Alarm connections, 6 No voltage or current output to recording device, 16 Alarm functionality, 11 O rings, 14 Alarm set points, 9 Output connections, 6 Analyzer does not power up, 15...
