A105 Series
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Mio MioCARE+ A105 Series

Summary of Contents for Mio MioCARE+ A105 Series

  • Page 1 A105 Series User Manual...

  • Page 2: Knowing Your Device

    Welcome Thank you for purchasing a Mio product. This Quick Start Guide guides you through the successful setup of your device and familiarizes you with the basic skills of using the device. Knowing your device 1. LED indicator 1 (Barcode reader status) 2.

  • Page 3: Getting Started

    Getting started Charging the battery Your device has an internal battery that may not be fully charged when you purchase it. You should charge the battery for at least 8 hours before you start using it for the very first time. To charge the battery, plug the home charger cable into the Micro-USB connector on the bottom of your device and the mains power charger into the power socket.

  • Page 4: Performing The Initial Start-Up

    Performing the initial start-up 1. Press and hold the POWER button until the device turns on. 2. The Home screen will be displayed and the device is in Lock mode by default. 3. To unlock the device, drag the Lock icon ( ) to the right.

  • Page 5: Installing The Memory Card

    5 minutes (water volume: 10 litres per minute, Pressure: 80-100kPa). Mio guarantees this grade provided the battery door and all jack covers are properly and securely closed. This device is not IPX7/IPX8 grade; immersion in water or water-pressure such as washing the unit with running water may cause damage to the unit and voids warranty.

  • Page 6: Operating Basics

    Operating basics Using the POWER button • Turning on the device Press and hold the POWER button until the device turns on. • Switching on/off the screen Your device will automatically switch off the screen after 1 minute (by default) of inactivity. You can manually switch off the screen by pressing the POWER button briefly.

  • Page 7: Navigating On The Screen

    Navigating on the screen To operate your device, touch the screen with your fingertip. You can perform the following actions: • Tap Touch the screen once with your fingertip to open items or select onscreen buttons or options. • Tap and hold Tap and hold on the desired item to open the pop-up menu that contains the available options for the item.

  • Page 8: Home Screen

    Home screen The Home screen is your starting place for tasks, providing quick access to frequently used applications and settings. Tip: To display the Home screen, tap the HOME button at any time. Status Bar Shortcuts/widgets Desktop All Applications button Quick Launcher Soft keys: BACK...

  • Page 9: Customising Your Device

    Customising your device You can customize the device through the Settings menu, including personalising the Home screen, changing the display and sound settings, configuring the connection settings, and more. Accessing the Settings menu From the desktop, do one of the following to access the Settings menu: •...
  • Page 10 4. When your device is connected to a wireless network, the WLAN icon ( ) will appear in the Status Bar indicating the signal strength (number of bands that light up). The next time your device connects to a previously accessed secured wireless network, you will not be prompted to enter the WEP key again, unless you reset your device to its factory default settings.

  • Page 11: Configuring The Barcode Reader

    Configuring the barcode reader From the desktop, do one of the following to access the Barcode reader configuration utility: • Tap the All Applications button ( ) > Barcode Reader Config. • Tap from the Quick Launcher. By using the configuration utility, you can: •...

  • Page 12: Federal Communication Commission Interference Statement

    For more information Support For initial support, contact your IT department or your local authorized dealer. Occasionally, Mio may offer free system updates to improve user experience. Please regularly check the website http://miocare.mio.com/ for more information. Federal Communication Commission Interference Statement Note: For regulatory identification purposes, MioCARE A105 is assigned a model number of N406.

  • Page 13: Industry Canada Statement

    The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only. RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves.
  • Page 14 Radiation Exposure Statement: The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available.
  • Page 15 Disclaimer Specifications and documents are subject to change without notice. Mio Technology does not warrant this document is error-free. Mio Technology assumes no liability for damage incurred directly or indirectly from errors, omissions, or discrepancies between the device and the documents.
