Guide to controls and connectors

All of Contour's controls are touch sensitive. Tap or hold a fi nger on the button you want to use.
Top panel
Standby
Tap to switch
between on and
standby
Front panel
Home
Tap to return
to the audio
source screen
Rear connectors
20V DC input
Input for mains
adapter
Aux In
3.5 mm
connection
for auxiliary
devices
4
Volume down
Tap or hold to
lower volume
Context-sensitive buttons
Active buttons are lit and the
function is displayed on-screen
above the button
20
Composite
Headphones
Phono video output
3.5 mm socket
from a docked iPod/
for headphones
iPhone. Connect to a
TV or monitor
Volume up Mute
Tap or hold to Tap to mute
raise volume
Back
Tap to go back
one step
Component/S-Video
3.5mm video output from a
docked iPod/iPhone. (PURE
Choice accessory cables
available separately.)
Navigation buttons
Tap to navigate and
select menu options
Mini USB
For software
updates and
optional PURE
Ethernet adapter
