Quick guide to controls and connectors

Top panel
Standby Volume down
Tap to switch Tap or hold to
between on and lower volume
standby
4
Volume up Mute
Tap or hold to Tap to mute
raise volume
Front panel
Home
Tap to return
to the audio
source screen
Context-sensitive buttons
Active buttons are lit and the
function is displayed on-screen
above the button
Navigation buttons
Tap to navigate and
select menu options
Back
Tap to go back
one step
Rear connectors
20V DC input
Input for mains
adapter
20 V DC Aux In
Aux In Headphones
3.5 mm 3.5 mm socket
connection for stereo
for auxiliary headphones
devices
Mini USB
For software
updates and
optional PURE
Video Out
Ethernet adapter
Component
Composite
/S-Video
Composite Component/S-Video
Phono video output 3.5mm video output from a
from a docked iPod/ docked iPod/iPhone. (PURE
iPhone. Connect to a Choice accessory cables
TV or monitor available separately.)
