Specifications Of The Tw Alpha Plus; Intended Use; Technical Specifications - SI Analytics TW alpha plus Operating Manual

1

Specifications of the TW alpha plus

1.1

Intended Use

Der Titrations-Probenwechsler ermöglicht die Durchführung von Serien-Titrationen mit automatischem
Probenwechsel. Er ist einsetzbar für alle Proben, die in einem offenen Becherglas durchgeführt werden
können. Mit einem dafür geeigneten Titrierkopf lassen sich CSB-Titrationen in den genormten
Reaktionsgefäßen nach DIN 38 409, Teil 41 direkt durchführen. Der Probenwechsler wird über die
RS-232-C-Schnittstellen vom Computer bzw. von Titratoren gesteuert. Er besitzt einen eingebauten
Magnetrührer.
1.2

Technical specifications

Translation of the legally binding German version
CE sign: EMC compatibility according to the Council Directive: 2014/35/EU
applied harmonized standards: EN 61 010-1-1:2010
Low-voltage directive according to the Council Directive 2014/30/EU
Testing basis EN 61 326, Part 1
Country of origin: Made in Germany
Automatic TW alpha plus Titration Sample Changer with interchangeable sample plates.
Sample plates for 12, 24 beaker glasses or 24 COD reaction vessels according to DIN 38 409, Part 41.
48-type plates available as special make.
Stroke height: 270 mm, at delivery ex-factory limited to 130 mm
Beaker glasses for sample plates with 12 samples
(* = preferred shape):
250 ml with muzzle, low shape
400 ml with muzzle, high shape
400 ml with muzzle, high shape
Beaker glasses for sample plates with 16 samples
(* = preferred shape):
100 ml with muzzle, low shape
150 ml with muzzle, low shape
250 ml with muzzle, high shape
250 ml without muzzle, high shape
Beaker glasses for sample plates with 24 samples
(* = preferred shape):
50 ml with muzzle, high shape
50 ml without muzzle, high shape
Materials:
Device: Casing made of two-component- coated ALU, steel sheet, and epoxy resin
Sample plate: Stainless steel and ABS
Dimensions:
Device: 143 x 620 x 475 mm (W x H x D)
Sample plates: Diameter 450 mm, H = 65 mm (for beaker glasses)
H = 110 mm (for COD reaction vessels according to DIN 38 409, Part 41)
Connection values:
220 V, 30 VA
110 V, 30 VA
Weight
Device: approx. 10.3 kg
Sample plate: with 12 beaker glasses 250 ml:
with 16 beaker glasses 150 ml:
with 24 beaker glasses 50 ml:
with 24 reaction vessels:
approx 2.7 kg
approx. 2.6 kg
approx 2.4 kg
approx. 6.3 kg
(Release: 08. november 2018)
Order number
21 106 36*
21 116 41
21 117 41
Order number
21 106 24
21 106 29*
21 116 36
21 117 36
Order number
21 116 17*
21 117 17
