AstroJet
2650P-2800P
Quick Start Guide
Step 1
Unpack Printer and Accessories
Place Printer on a stable surface at least 12"
from any walls. Save packaging material.
Attach Side Media Guides, Rear Media Support
and Rear Media Guide.
Step 2
Connect Power to Printer
1. Main power switch is turned OFF.
2. Plug power cord into Printer receptacle.
3. Plug other end into 115-220 Volt AC, 50/60 Hz.
grounded outlet.
DO NOT TURN POWER SWITCH ON YET
Connect Printer to Computer
Printer has both USB and Parallel Ports.
(Located on Side Cover as shown.)
USB Cable Users: Plug USB cable from computer into Printer's
USB port.
Parallel Cable Users: Plug Parallel Printer Cable from computer
into Printer's Parallel Port. Latch two locking clips.
Page 1
Advertisement
Related Manuals for Astro Machine AstroJet 2650P
Summary of Contents for Astro Machine AstroJet 2650P
-
Page 1: Quick Start Guide
AstroJet 2650P-2800P Quick Start Guide Step 1 Unpack Printer and Accessories Place Printer on a stable surface at least 12” from any walls. Save packaging material. Attach Side Media Guides, Rear Media Support and Rear Media Guide. Step 2 Connect Power to Printer 1. - Page 2 Step 4 Step 3 Setting Up Feed Install Inkjet Cartridges 1. Release Separator Locking Levers (located on 2650P holds up to 6 Inkjet Cartridges. operator’s side of Feeder), raise Separators an 2800P holds up to 8 Inket Cartridges. lock in position. Move Side Guides to outermost 1.
- Page 3 6. Feed one piece of media through Printer. Adjust Step 5 two Exit Guides to ride on media. NOTE: To prevent smearing, make sure Exit Guides do not track over any printed Install Print Driver information. Load “Printer Drivers” CD into computer's CD/DVD drive.
- Page 4 “Found New Hardware” box appears in lower right-hand corner of screen. Step 6 To install Accessories and for Printer set-up or operation, please refer to “AstroJet 2650P-2800P Printer Operator Manual” supplied with Printer. 630 Lively Blvd. Elk Grove Village, IL 60007...
