3. Getting Started and Basic Operation

Ordering Options

1) Order an extra unit as receiver.
2) Order extra shutter cables to control different cameras.
3) Order 3 or more units to take advantage of zones and relay mode.

Battery Installation

Tp2 uses 2 AA batteries, which can last up to 80
hours. To insert the battery, open the battery hatch
by following the arrow's direction, then insert the
battery according to the +/- icons, then close the
battery hatch.
Note:
Turn off before removing batteries.

Modes

1) TX/RX - When using unit as flash trigger,
camera remote transmitter and camera remote
receiver.
2) RX - When using unit as flash receiver.

Channel Setting

TP2 has 6 channels. Set all to the same channels
and corresponding zone (Refer to P10 to set).
Note:
Short press CH/RL button to switch channel.
5
AP-013II II 2.4G
Friday, May 31, 2013 2:07:58 PM
-2013 LOGO

Test Triggering

Local Test (Uses 1pcs TP2)
Press TEST button of unit on the flash (this unit
should be set to RX) to trigger the flash.
Remote Control Test (Uses 2pcsTP2)
Press TEST button of unit in your hand (this unit
should be set to TX/RX) to trigger the flash on
another receiver (this unit should be set to RX).
6
