Intellitec Battery Disconnect BD0 Service Manual page 9

BATTERY DISCO
Trouble Shooting
Problem
House Relay won't
disengage, BD0 &
BD1 MODELS
ONLY
Trouble Shooting
Problem
House indicator light on
panel remains on although
relay is off. BD0 & BD1
MODELS ONLY
INTELLITEC
Possible
Cause/Solution
With an assistant, press and hold momentary
switch, at the same time check for voltage across
the coil terminals (+ on the "S" terminal and
STEP 11
ground on the "I" terminal), If 0 volts go to step
12. If voltage is 10.5 VDC or larger between the
"S" & "I" terminals, replace relay.
Remove battery disconnect panel from cabinet /
console and with a multi-meter set on DC voltage,
measure between the red wire at pin # 3 and the
STEP 12
black wire on pin # 6. The voltage should read the
same approximate value as the batteries. If not
replace harness, refer to PARTS LINK#1 (page 7).
If the voltage reading is the same go to step 13.
With a multi-meter set on DC voltage, measure
between the red wire at pin # 3 and the white wire
on pin #4 while the switch is depressed. The
STEP 13
voltage should read the same approximate value as
the batteries. If not replace disconnect panel, refer
to PARTS LINK # 2 (page 7). If the reading is the
same go to step 14.
With a multi-meter set on DC voltage, measure
between the black wire at pin # 6 and the brown
wire on pin # 1 while the switch is pressed. The
STEP 14
voltage should read the same approximate value as
the batteries. If not replace disconnect panel, refer
to PARTS LINK # 2 (page 7).
Possible
Cause/Solution
Is coach plugged in, unplug coach and retest
Is engine running, turn engine off and retest
STEP 15
If the panel fails one or both retests then go to step
16.
9
