Getting started

Power
You can power the device using the supplied AC power
supply, but if you plan to use a battery we recommend you
fully charge before use.
Choosing the right battery for your application
Standby mode
2600mAh - 3hrs
Battery time
(Based on 7.4V)
5200mAh - 6hrs
7800mAh - 12hrs
We recommend using Atomos NP-F series batteries.
4 Shinobi - Quick Start Guide
Monitor mode
2600mAh - 1.5hrs
5200mAh - 3hrs
7800mAh - 6hrs

Connect and power-up

Battery / Battery Eliminator
Shinobi has a single battery slot. To connect a compatible
battery, place the battery in front of the retaining lug, align
with the connectors and slide the battery into the lock
position.
To connect the supplied Battery Eliminator, follow the same
procedure and lock battery into position.
Touching the Battery icon in the top right of your screen will
allow you to accurately see remaining battery life. Refer to
the User Manual for more information.
