I
NSTALLING AN
Installing an Optional
SFP Transceiver into the Switch
8
9
2 0
2 1

Figure 3-5 Inserting an SFP Transceiver into a Slot

The switch supports the following optional transceivers:

Table 3-1 Optional Transcievers

1000BASE-SX (SMCBGSLCX1)
1000BASE-LX (SMCBGLLCX1)
1000BASE-ZX (SMCBGZLCX1)
To install an SFP transceiver, do the following:
1. Consider network and cabling requirements to select an appropriate
transceiver type. Refer to "Connectivity Rules" on page 4-6.
2. Insert the transceiver with the optical connector facing outward and
the slot connector facing down. Note that SFP transceivers are keyed
so they can only be installed in one orientation.
3. Slide the transceiver into the slot until it clicks into place.
O
PTIONAL
9
1 0
1 1
1 2
2 2
2 3
2 4
SFP
SFP T
RANSCEIVER INTO THE
2 1
2 2
2 3
2 4
S
WITCH
3-7
